دسته: لوازم یدکی هایلوکس

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی تویوتا, لوازم یدکی هایلوکس
04311 لوازم پمپ كلاچ بالا
04311-26070 1 $42.94
31402 مخزن پمپ كلاچ بالا
31402-35120 1 $54.56
31410 پمپ كلاچ بالا
31410-60571 1 $159.99
31415 GASKET, CLUTCH MASTER CYLINDER
31415-10010 1 $1.58
31417 GROMMET, CLUTCH RESERVOIR
31417-35010 1 $2.81
31426 FLOAT, CLUTCH MASTER CYLINDER RESERVOIR
31426-30011 1 $4.19
31440P CAP ASSY, CLUTCH MASTER CYLINDER RESERVOIR FILLER
31405-35020 1 درب پمپ كلاچ بالا
31451 ROD, CLUTCH MASTER CYLINDER PUSH
31451-35080 1 $14.67
31453 CLEVIS, CLUTCH MASTER CYLINDER PUSH ROD
31404-28020 1 $72.71
31454 CLUTCH MASTER CYLINDER
31454-16010 1 $4.63
31490F ACCUMULATOR ASSY, MASTER CYLINDER
31490-60100 1 $97.10
31490G GASKET(FOR CLUTCH MASTER CYLINDER ACCUMULATOR)
90430-16005

411

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
17111 MANIFOLD, INTAKE
17111-75070 1 منيفولد هوا
17111A PLUG, NO.1
96411-43500 2 $5.61
17111B PLUG, NO.2
90341-10009 1 $3.32
17111S GASKET(FOR MANIFOLD PLUG)
90430-09005 1 $0.79
17125 STAY, SURGE TANK, NO.1
17125-75030 1 $32.30
17129 TANK, INTAKE AIR SURGE
17109-75030 1 $569.10
17129A UNION, NO.1
90406-06002 1 $1.27
17129F PLUG, INTAKE MANIFOLD SUCTION HOLE
90345-51025 1 $3.44
17141 منيفولد دود
17141-75080 1 $428.81
17141F GASKET(FOR EXHAUST MANIFOLD PLATE)
25634-75010 1 $14.51
17148 PLATE, EXHAUST MANIFOLD(FOR EGR INLET)
17148-41010 1 $12.69
17152 BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE)
90116-10149 3 $2.13
17159 BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD)
90116-10163 6 $8.54
17167 INSULATOR, EXHAUST MANIFOLD HEAT, NO.1
17167-75100 1 $92.67
17173 GASKET, EXHAUST MANIFOLD TO HEAD
17173-75020 1 $37.70
17176 GASKET, AIR SURGE TANK TO INTAKE MANIFOLD
17176-75010 1 $8.34
17177 GASKET, INTAKE MANIFOLD TO HEAD, NO.1
17177-75030 1 $12.10
25617C PLATE, EGR HOLE COVER
25617-74020 1 $3.80
25628B GASKET, EGR INLET
25628-75010

369

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
22210 BODY ASSY, THROTTLE
22210-75260  دريچه سوخت 1 $1,254.39
22215 GASKET, THROTTLE BODY COVER
22215-7A680 1 $4.51
22270 VALVE ASSY, IDLE SPEED CONTROL(FOR THLOTTLE BODY)
22270-75050 1 $440.32
22271 GASKET, THROTTLE BODY
22271-75020 1 $2.69
23250 INJECTOR ASSY, FUEL
23209-79145  سوزن انژكتور 4 $288.74
23250B RING, O(FOR FUEL INJECTOR)
90301-07024 4 $3.01
23270 DAMPER ASSY, FUEL PRESSURE PULSATION
23207-46010 1 $77.69
23270B GASKET(FOR PULSATION DAMPER HOSE)
23279-74010 2 $1.46
23273C HOSE, FUEL, NO.2
23273-75090 1 $17.55
23273D CLIP(FOR FUEL HOSE NO.2)
96135-51100 2 $2.69
23280 REGULATOR ASSY, FUEL PRESSURE
23280-75020  فشار شكن بنزين 1 $152.06
23280E RING, O(FOR FUEL PRESSURE REGULATOR)
90301-07024 1 $3.01
23291 INSULATOR, INJECTOR VIBRATION
23291-73010 4 $9.49
23300P FILTER, FUEL(FOR EFI)
23300-75110 1 $47.04
23801P PIPE SUB-ASSY, FUEL, NO.1
23801-75080 1 $66.78
23801W CLIP, FUEL TUBE CONNECTOR
90923-07010 1 $2.65
23803B PIPE SUB-ASSY, FUEL, NO.3
23803-75040 1 $25.94
23807 PIPE SUB-ASSY, FUEL DELIVERY
23807-75021  ريل سوخت 1 $83.94
23811C HOSE, FUEL(FOR FUEL PIPE TO PRESSURE REGULATOR)
90445-12290 CUT HOSE TO LENGTH AS SPECIFIED IN REMARKS, L=120 1 $4.67
23811D CLIP, HOSE(FOR FUEL HOSE)
96135-51100 2 $2.69
23841B CLAMP, FUEL PIPE, NO.1(FOR EFI)
90469-12012

438

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
15100B
15188-75021 1 $7.35
15102 ROTOR SET, OIL PUMP
15103-75020  دنده اويل پمپ 1 $59.42
15104 STRAINER SUB-ASSY, OIL
15104-75080  توري اويل پمپ 1 $102.72
15115 COVER, OIL PUMP
15115-75020  كاور سيني اويل پمپ 1 $40.25
15131 VALVE, OIL PUMP RELIEF
15131-24010 1 $6.17
15132 SPRING, OIL PUMP RELIEF VALVE
15132-75020 NO.1 1 $3.04
15132-75021 NO.2 1 $3.04
15135 RETAINER, OIL PUMP RELIEF VALVE
15135-75040 1 $1.94
15147 GASKET, OIL STRAINER
15147-75020 1 $1.78
90179-08040 *** STD. PART $1.38
91641-C0814 *** STD. PART $1.03
93220-16014 *** STD. PART $0.83
96151-01500 *** STD. PART $2.69

351

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
11496-75011 *** STD. PART $2.29
13063 GEAR SUB-ASSY, BALANCESHAFT DRIVE
Not applicable
13506 زنجير موتور بلند
13506-75020 1 $116.67
13507 زنجير موتور كوتاه
Not applicable
13511 CAMSHAFT
13501-75040  ميل سوپاپ 1 $409.98
13511A PIN, STRAIGHT(FOR CAMSHAFT KNOCK)
90250-06068 L=11, OD=6 1 $1.34
13512 CAMSHAFT, NO.2
13502-75010  ميل سوپاپ 2 1 $409.98
13512A PIN, STRAIGHT NO.2(FOR CAMSHAFT KNOCK)
90250-05030 L=9, OD=5 1 $1.15
13516 JET, OIL
13516-75030 1 $9.09
13523 GEAR OR SPROCKET, CAMSHAFT TIMING
13523-75010  دنده تايم ميل سوپاپ 1 $33.61
13529 GEAR, CAMSHAFT SUB
13529-74900  دنده ميل سوپاپ 1 $66.07
13529A WASHER, WAVE(FOR CAMSHAFT SUB GEAR)
90206-42001 1 $1.34
13529B RISHAFT SNAP(FOR CAMSHAFT SUB GEAR)
90520-41004 1 $3.68
13540 TENSIONER ASSY, CHAIN , NO.1
13540-75020  زنجير سفت كن 1 $39.38
13540C GASKET(FOR CHAIN TENSIONER)
13552-75010 1 $2.89
13550 TENSIONER ASSY, CHAIN, NO.2
Not applicable
13554 DAMPER, CHAIN VIBRATION, NO.4
Not applicable
13559
13559-75020  بالشتك زنجير 1 $47.40
13561 DAMPER, CHAIN VIBRATION, NO.1
13561-75020  بالشتك زنجير 1 $64.41
13562 DAMPER, CHAIN VIBRATION, NO.2
Not applicable
13563 DAMPER, CHAIN VIBRATION, NO.3
Not applicable
13579 WASHER, CAMSHAFT TIMING GEAR BOLT
13579-74010 1 $4.74
13597 SPROCKET, CRANKSHAFT TIMING, NO.2
Not applicable
13633A GEAR, BALANCESHAFT DRIVEN, NO.2
Not applicable
13636 SHAFT, BALANCESHAFT DRIVE GEAR
Not applicable
13711 VALVE, INTAKE
13711-75070  سوپاپ هوا 8 $59.03
13711A SEAL OR RING , O(FOR VALVE STEM OIL)
90913-02090 NO.1 8 $5.85
90913-02103 NO.2 8 $9.61
13711B SPRING, COMPRESSION(FOR INNER)
90501-31017 16 $7.71
13715 VALVE, EXHAUST
13715-76030  سوپاپ دود 8 $74.75
13734 SEAT, VALVE SPRING
90201-18015 16 $0.55
13741 RETAINER, VALVE SPRING
13741-46020 16 $3.99
13741A LOCK, VALVE SPRING RETAINER
90913-03021 32 $2.93
13751 LIFTER, VALVE
13751-74020  استكان تايپيت 16 $19.85
13753  شيم سوپاپ
13753-74010 T=2.50 16 $10.56
13753-74030 T=2.55 16 $10.56
13753-74050 T=2.60 16 $10.56
13753-74070 T=2.65 16 $10.56
13753-74090 T=2.70 16 $10.56
13753-74110 T=2.75 16 $10.56
13753-74130 T=2.80 16 $10.56
13753-74150 T=2.85 16 $10.56
13753-74170 T=2.90 16 $10.56
13753-74190 T=2.95 16 $10.56
13753-74210 T=3.00 16 $10.56
13753-74230 T=3.05 16 $10.56
13753-74250 T=3.10 16 $10.56
13753-74270 T=3.15 16 $10.56
13753-74290 T=3.20 16 $10.56
13753-74310 T=3.25 16 $10.56
13753-74330 T=3.30 16 $10.56
90105-08143 *** STD. PART $1.54
90105-08323 *** STD. PART $1.07
90105-12261 *** STD. PART $3.99
90109-08181 *** STD. PART $9.96
90109-08238 *** STD. PART $1.54
90116-08367 *** STD. PART $1.15
90126-08015 *** STD. PART $3.56
90179-08040 *** STD. PART $1.38
90250-05027 *** STD. PART $1.07
91641-80818 *** STD. PART $1.03
91641-H0820 *** STD. PART $1.07
91641-K0816 *** STD. PART $1.03

400

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
11011 WASHER SET, CRANKSHAFT THRUST
11011-75010 بغل ياتاقان 1 $59.82
11702 ياتاقان ثابت 025
11704-75021 U/S 0.25 1 $134.79
11711 ياتاقان ثابت استاندارد
11071-75021-01 REFER TO REPAIR MANUAL, MARK 1, NO.2 3 $22.48
11071-75021-02 REFER TO REPAIR MANUAL, MARK 2, NO.2 3 $22.48
11071-75021-03 REFER TO REPAIR MANUAL, MARK 3, NO.2 3 $22.48
11701-75021-01 REFER TO REPAIR MANUAL, MARK 1, NO.1 2 $22.22
11701-75021-02 REFER TO REPAIR MANUAL, MARK 2, NO.1 2 $22.22
11701-75021-03 REFER TO REPAIR MANUAL, MARK 3, NO.1 2 $22.22
11991 WASHER, BALANCESHAFT THRUST
Not applicable
11992 WASHER, BALANCESHAFT THRUST, NO.2
Not applicable
13011 رينگ موتور استاندارد
13011-75090 STD 1 $208.44
13013-75090 O/S 0.50 1 $250.34
13041 ياتاقان متحرك استاندارد
13041-75021-04 REFER TO REPAIR MANUAL, MARK 4 4 $18.82
13041-75021-05 REFER TO REPAIR MANUAL, MARK 5 4 $18.82
13041-75021-06 REFER TO REPAIR MANUAL, MARK 6 4 $18.82
13101 پيستون
13101-75041 STD 4 $111.91
13103-75041 O/S 0.50 4 $133.93
13101A
90521-28003 8 $0.79
13201 ROD SUB-ASSY, CONNECTING
13201-79205  شاطون 4 $180.97
13201A BUSH(FOR CONNECTING ROD SMALL END)
90999-73129  بوش شاطون 4 $16.57
13202 ياتاقان متحرك 025
13204-75021 U/S 0.25 1 $90.23
13265 BOLT, CONNECTING ROD
13265-75030  پيچ شاطون 8 $5.22
13265A NUT, HEXAGON(FOR CONNECTING ROD BOLT)
90179-09009 8 $1.07
13405 FLYWHEEL SUB-ASSY
13405-75040  فلايويل 1 $386.87
13405A PIN, STRAIGHT(FOR FLYWHEEL)
90250-08054 L=23, OD=8 3 $1.34
13405B BOLT, FLYWHEEL SET
90910-02116 10 $3.20
13411 CRANKSHAFT
13411-75020  ميل لنگ 1 $1,262.31
13453
13453-20010 1 $152.06
13471 PULLEY, CRANKSHAFT
13408-75030  پولي سر ميل لنگ 1 $247.98
13471A KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET)
90280-05005 1 $1.30
13471C BOLT(FOR CRANKSHAFT PULLEY SET)
90105-16041 1 $7.04
13471P SPACER(FOR CRANKSHAFT PULLEY)
Not applicable
13477 PULLEY, CRANKSHAFT, NO.2
88451-26050 1 $98.05
13521 GEAR OR SPROCKET, CRANKSHAFT TIMING
13521-75010  دنده سر ميل لنگ 1 $60.69
13521A KEY(FOR CRANKSHAFT TIMING GEAR)
90280-05005 1 $1.30
13621 BALANCESHAFT, NO.1
بالانسر 1
13622 BALANCESHAFT, NO.2
بالانسر 2
13632 GEAR, BALANCESHAFT DRIVEN, NO.1
Not applicable
13635 SPACER, BALANCESHAFT THRUST
Not applicable
19315A ROTOR, CRANK POSITION SENSOR
19315-75010  دنده موقعيت ميل لنگ 1 $28.27
90105-08323 *** STD. PART $1.07
90281-03001 *** STD. PART $0.51
91511-80820 *** STD. PART $1.03
91611-60814 *** STD. PART $0.95

381

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
12311 BRACKET, ENGINE MOUNTING, FRONT NO.1 RH
12311-75080  بست دسته موتور راست 1 $60.29
12315 BRACKET, ENGINE MOUNTING, FRONT NO.1 LH
12315-75070  بست دسته موتور چپ 1 $72.71
12361 INSULATOR, ENGINE MOUNTING, FRONT
12361-35090  دسته موتور جلو 2 $80.62
12371 INSULATOR, ENGINE MOUNTING, REAR NO.1
12371-75070  دسته موتور عقب 1 $96.75
12381 STABILIZER, ENGINE MOUNTING
12381-75020 1 $23.21
12382 STABILIZER, ENGINE MOUNTING, LH
12382-75020 1 $27.68
12511 BRACKET, ALTERNATOR, NO.1
12511-75041  بست دينام 1 $59.82
90105-10123 *** STD. PART $2.77
90105-10266 *** STD. PART $1.54
90119-08028 *** STD. PART

386

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
11301 CASE SUB-ASSY, TIMING GEAR
11301-75021  اويل پمپ 1 $481.88
11301C كاسه نمد سر ميل لنگ
90311-48020 KOYO 1 $14.00
11301K SENSOR, CRANK POSITION
90919-05016  سنسور موقعيت ميل لنگ 1 $159.53
11328 GASKET, TIMING GEAR  COVER
11328-75021 1 $12.65
11329 GASKET, TIMING GEAR REAR COVER
11329-75021 1 $12.65
11354 SEAL, FLYWHEEL HOUSING DUST
11354-75010 1 $15.62
11355 PLATE, REAR END
11355-75010 1 $29.77
11361 COVER, FLYWHEEL HOUSING UNDER
11361-75020 1 $25.38
11381 RETAINER, ENGINE REAR OIL SEAL
11381-75010 1 $51.52
11381A SEAL, ENGINE REAR OIL
90311-88005  كاسه نمد ته ميل لنگ 1 $50.33
11444E PLUG, HOLE
11444-75020 1 $1.70
12282 HANGER, ENGINE, NO.2
12282-75020 X $17.28
16192-71010 *** STD. PART $2.81
19529-75010 *** STD. PART $2.06
90105-08020 *** STD. PART $1.38
90105-08030 *** STD. PART $1.11
90105-08076 *** STD. PART $1.11
90105-10380 *** STD. PART $2.25
90105-10403 *** STD. PART $1.90
90116-08337 *** STD. PART $3.04
90119-08A72 *** STD. PART $1.03
90179-08040 *** STD. PART $1.38
91511-J0820 *** STD. PART $1.07
91512-B1020 *** STD. PART $1.07
91611-60618 *** STD. PART $1.38
91641-80835 *** STD. PART $1.03
91641-C0814 *** STD. PART $1.03
94151-80800 *** STD. PART $0.99

338

دسته بندی ها: لوازم موتوری هایلوکس, لوازم یدکی هایلوکس
11101 HEAD SUB-ASSY, CYLINDER
11101-79295  سرسيلندر 1 $1,787.28
11101A BOLT(FOR CYLINDER HEAD SET)
90910-02091  پيچ سر سيلندر 10 $8.42
11101B WASHER, PLATE(FOR CYLINDER HEAD SET)
90201-12222 10 $1.34
11101E SENSOR, CAM POSITION
سنسور ميل سوپاپ
11115 GASKET, CYLINDER HEAD
11115-75031  واشر سرسيلندر 1 $77.31
11116A PLUG, TIGHT, NO.1
96411-62800 1 $6.29
11117E PLUG, W/HEAD STRAIGHT SCREW, NO.1
90341-27006 3 $10.44
11117H GASKET(FOR WATER HOLE)
90430-27005 3 $2.69
11122 گايد سوپاپ هوا
11122-16010 STD 8 $13.05
11123-16010 O/S 0.05 8 $13.05
11126 گايد سوپاپ دود
11126-50050 STD 8 $10.95
11127-50050 O/S 0.05 8 $10.95
11131 SEAT, INTAKE VALVE
11131-75040 STD 8 $10.32
11132-75040 O/S 0.03 8 $10.32
11135 SEAT, EXHAUST VALVE
11135-76030 STD 8 $11.66
11136-76030 O/S 0.03 8 $11.66
11151A
90253-10006 L=7, OD=10 4 $1.11
11159A BOLT(FOR HEAD TO CAMSHAFT BEARING CAP)
90119-07009 20 $1.11
11181 PLATE, CYLINDER HEAD, REAR
11181-75021 1 $9.49
11182 GASKET, CYLINDER HEAD REAR PLATE
11182-75010 1 $3.12
11183 PLUG, SEMICIRCULAR
11183-50010 2 $10.56
11193 GASKET, SPARK PLUG TUBE
11193-15010 4 $11.90
11201 COVER SUB-ASSY, CYLINDER HEAD
11201-75040  درب سوپاپ 1 $333.57
11201B WASHER, SEAL(FOR CYLINDER HEAD COVER)
90210-07001 10 $2.69
11201H BOLT(FOR CYLINDER HEAD COVER)
91511-J0625  پيچ درب سوپاپ 10 $0.79
11213 GASKET, CYLINDER HEAD COVER
11213-75030  واشر درب سوپاپ 1 $26.68
12108 CAP SUB-ASSY, OIL FILLER
12180-65011  درب روغن 1 $17.67
12108A GASKET(FOR OIL FILLER CAP)
90430-37140 1 $1.58
90105-08076 *** STD. PART $1.11
90105-08339 *** STD. PART $1.03
90339-36001 *** STD. PART $3.20
91511-A0612 *** STD. PART $0.79

361

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
04483 SHACKLE KIT, REAR SPRING
04483-0K030 2 $151.51
48046 SEAT SUB-ASSY, SPRING U BOLT, RH
48046-0K020 1 $79.39
48046A BOLT, U(FOR REAR SPRING)
90117-T0002 L=170 4 $32.62
48047 SEAT SUB-ASSY, SPRING U BOLT, LH
48046-0K020 1 $79.39
48210A BUSH(FOR REAR SPRING SHACKLE UPPER)
90385-T0009 4 $5.38
48210G BUSH(FOR REAR SPRING SHACKLE LOWER)
90385-T0010 4 $4.35
48306 BUMPER SUB-ASSY, REAR SPRING
48306-0K010 2 $37.80
48530 کمک عقب راست
48531-09550 MARK 48531-0K140 1 $50.19
48530B WASHER, REAR SHOCK ABSORBER CUSHION, NO.1
90948-T3001 4 $6.29
48530C WASHER, REAR SHOCK ABSORBER CUSHION, NO.2
90948-T3002 4 $7.20
48530H BUSH, REAR SHOCK ABSORBER
90385-T0004 8 $2.41
48540 کمک عقب چپ
48541-09110 MARK 48541-0K010 1
90105-T0128 *** STD. PART $1.50
90105-T0146 *** STD. PART
90178-T0027 *** STD. PART $1.58
90178-T0033 *** STD. PART
90178-T0034 *** STD. PART $1.58
90178-T0061 *** STD. PART $1.58
90201-T0006 *** STD. PART
90201-T0012 *** STD. PART

diag_1rsmvq0

372

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
48131 SPRING, FRONT COIL, RH
48131-0K770 1 $133.46
48132 SPRING, FRONT COIL, LH
48131-0K770 1 $133.46
48304 BUMPER SUB-ASSY, FRONT SPRING, NO.1
48304-0K040 2 $39.46
48510 کمک جلو راست
48510-09J10 MARK 48510-0K410 1 $226.83
48510B RETAINER, CUSHION, NO.1(FOR FRONT SHOCK ABSORBER)
90948-T2003 2 $8.11
48510J CUSHION, FRONT SHOCK ABSORBER, NO.1
90948-T1001 2 $7.20
48510Q RETAINER, CUSHION, NO.3(FOR FRONT SHOCK ABSORBER)
90948-T2004 2 $13.68
48520 کمک جلو چپ
48510-09J10 MARK 48510-0K410 1 $226.83
48603 SUPPORT SUB-ASSY, FRONT SUSPENSION, RH
48609-0K040 1 $89.12
48603A NUT(FOR FRONT SUSPENSION SUPPORT)
90178-T0050 6 $1.34
48603D NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER RH)
90178-T0048 1 $1.50
48609 SUPPORT SUB-ASSY, FRONT SUSPENSION, LH
48609-0K040 1 $89.12
48609E NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER LH)
90178-T0048 1 $1.50
48680A NUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER)
94188-01241 2 $1.34
48810 LINK ASSY, FRONT STABILIZER, LH
48810-0K010  سیبک موجگیر جلو چپ 1 $154.31
48811 BAR, STABILIZER, FRONT
48811-0K050 1 $400.19
48815 BUSH, FRONT STABILIZER BAR, NO.1
48815-0K010 2 $19.73
48820B LINK ASSY, FRONT STABILIZER, RH
48820-0K030  سیبک موجگیر جلو راست 1 $154.31
48824 BRACKET, STABILIZER, FRONT
48824-0K010 2 $28.11
90119-T0242 *** STD. PART $4.94
90119-T0245 *** STD. PART $1.50
90178-T0041 *** STD. PART $1.27

diag_1rsmvq0

403

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
3211 سگدست راست
43211-0K030 ABS (ANTI-LOCK BRAKE SYSTEM)-WITH 1 $521.45
43211-0K040 1 $521.45
43212 سگدست چپ
43212-0K030 ABS (ANTI-LOCK BRAKE SYSTEM)-WITH 1 $521.45
43212-0K040 1 $521.45
43310B RING, SET (FOR DUST COVER)
90580-10001 2 $1.19
43330K JOINT ASSY, LOWER BALL, FRONT RH
43330-09510  سیبک طبق پایین راست 1 $79.85
43330L NUT, CASTLE (FOR FRONT LOWER BALL JOINT RH)
90171-T0003 1 $1.58
43340A JOINT ASSY, LOWER BALL, FRONT LH
43330-09510  سیبک طبق پایین چپ 1 $79.85
43340B NUT, CASTLE (FOR FRONT LOWER BALL JOINT LH)
90171-T0003 1 $1.58
43350 JOINT ASSY, FRONT UPPER BALL, RH
43310-09015  سیبک طبق بالا راست 1 $79.85
43350A NUT (FOR FRONT UPPER BALL JOINT RH)
90171-T0001 1 $1.58
43350B RING, SNAP (FOR FRONT UPPER BALL JOINT RH)
90520-T0029 1 $4.03
43360 JOINT ASSY, FRONT UPPER BALL, LH
43310-09015  سیبک طبق بالا چپ 1 $79.85
43360A NUT (FOR FRONT UPPER BALL JOINT LH)
90171-T0001 1 $1.58
43360B RING, SNAP (FOR FRONT UPPER BALL JOINT LH)
90520-T0029 1 $4.03
48068 ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 RH
48068-0K040  طبق پایین راست 1 $442.42
48068G NUT(FOR FRONT SUSPENSION LOWER ARM NO.1 RH)
90178-T0081 2 $1.94
48068M BOLT(FOR FRONT SUSPENSION LOWER ARM NO.2 RH)
90105-16053 2 $3.95
48069 ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 LH
48069-0K040  طبق پایین چپ 1 $442.42
48069C NUT(FOR FRONT SUSPENSION LOWER ARM NO.1 LH)
90178-T0081 2 $1.94
48069H BOLT(FOR FRONT SUSPENSION LOWER ARM NO.2 LH)
90105-16053 2 $3.95
48190 CAM ASSY, CAMBER ADJUST
48190-0K010  پیچ طبق 2 $17.08
48190A CAM ASSY, CAMBER ADJUST, NO.2
48190-0K030  پیچ طبق 2 $17.08
48198 CAM, CAMBER ADJUST, NO.2
48198-0K010  مهره طبق 4 $10.56
48610 ARM ASSY, FRONT SUSPENSION UPPER, RH
48610-0K040  طبق بالا راست 1 $407.39
48610F BOLT(FOR FRONT SUSPENSION UPPER ARM RH)
90105-T0114 1 $13.48
48610G NUT(FOR FRONT SUSPENSION UPPER ARM RH)
90178-T0027 1 $1.58
48625 ATTACHMENT, FRONT LOWER BALL JOINT, RH
48625-0K020 1 $86.51
48626 ATTACHMENT, FRONT LOWER BALL JOINT, LH
48626-0K020 1 $86.51
48630 ARM ASSY, FRONT SUSPENSION, UPPER LH
48630-0K040  طبق بالا چپ 1 $407.39
48630B BOLT(FOR FRONT SUSPENSION UPPER ARM LH)
90105-T0114 1 $13.48
48630C NUT(FOR FRONT SUSPENSION UPPER ARM LH)
90178-T0027 1 $1.58
48631A RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM RH)
90948-T2007 2 $20.28
48631C RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM LH)
90948-T2007 2 $20.28
48632A BUSH, FRONT SUSPENSION UPPER ARM, RH
48632-0K040  بوش طبق بالا راست 2
48632B BUSH, FRONT SUSPENSION UPPER ARM, LH
48632-0K040  بوش طبق بالا چپ 2
48654E BUSH, FRONT LOWER ARM, NO.1 RH
48654-0K040  بوش طبق پایین راست 1
48654F BUSH, FRONT LOWER ARM, NO.1 LH
48654-0K040  بوش طبق پایین چپ 1
48655D BUSH, FRONT LOWER ARM, NO.2 RH
48655-0K040  بوش طبق پایین راست2 1
48655E BUSH, FRONT LOWER ARM, NO.2 LH
48655-0K040  بوش طبق پایین چپ2 1
90252-03015 *** STD. PART

diag_1rsmvq0

408

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
47043 PLATE SUB-ASSY, BRAKE BACKING, REAR RH
47043-0K050 1 $93.86
47043C BOLT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING)
90114-10002 *10-1.25PX37-18.5 8 $1.94
90114-T0006 *10-1.25PX41-18 8 $1.70
47043F NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING)
90178-T0077 8
47044 PLATE SUB-ASSY, BRAKE BACKING, REAR LH
47044-0K050 1 $110.47
47547R PLUG, BLEEDER(FOR DRUM BRAKE, REAR)
Not applicable
47548R CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR)
31478-0K010 2 $3.60
47550 CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER)
47550-09070  سیلندر چرخ عقب راست 1 $85.42
47550C SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER)
Not applicable
47570 CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER)
47550-09070  سیلندر چرخ عقب چپ 1 $85.42
47601 LEVER SUB-ASSY, PARKING BRAKE SHOE, RH(FOR REAR BRAKE)
Not applicable
47601C WASHER, C(FOR REAR BRAKE)
Not applicable
47602 LEVER SUB-ASSY, PARKING BRAKE SHOE, LH (FOR REAR BRAKE)
Not applicable
47623C PIN, PARKING BRAKE LEVER
Not applicable
47643A LEVER, REAR BRAKE AUTOMATIC ADJUST, RH
47643-0K050 1 $11.11
47644A LEVER, REAR BRAKE AUTOMATIC ADJUST, LH
47644-0K050 1 $11.11
90016-AA602 *** STD. PART $2.21
90069-31011 *** STD. PART $1.58

diag_1oedwv6 diag_1rsmvq0

04474 CYLINDER KIT, REAR WHEEL
Not applicable
04495 لنت عقب
04495-0K120 MARK NSA LN508 1 $110.00
04906 CUP KIT, REAR WHEEL CYLINDER
Not applicable
04941 SPRING KIT, REAR BRAKE SHOE HOLD DOWN
04941-0K030 1 $12.97
04942 SPRING KIT, REAR BRAKE
04942-0K130  فنر لنت 1 $21.35
04943A STRUT KIT, REAR BRAKE
04943-0K030  پیچ ریگلاژ 1 $88.68
04949 PLUG KIT, REAR BRAKE
04949-0K030



403

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
04465 لنت جلو
04465-0K020 MARK ADVICS PS558H 1 $113.34
04479 CYLINDER KIT, DISC BRAKE, FRONT
04478-0K130  لوازم سیلندر چرخ جلو 1 $103.89
04945 SHIM KIT, ANTI SQUEAL, FRONT
04945-0K150  شیم لنت 1 $83.46
04947 FITTING KIT, DISC BRAKE, FRONT
04947-60080 1 $32.62
31478B CAP, BLEEDER PLUG(FOR FRONT DISC BRAKE)
31478-30010 2 $2.21
47547B PLUG, BLEEDER(FOR FRONT DISC BRAKE)
47547-20030 2 $7.27
47710A BOLT, HEXAGON(FOR FRONT DISC BRAKE CALIPER)
90105-12175 *12-1.25PX35-27 4 $2.53
47730 CYLINDER ASSY, FRONT DISC BRAKE, RH
47730-0K061  سیلندر چرخ جلو راست 1 $604.28
47731 PISTON, FRONT DISC BRAKE
47731-0K060  پیستون سیلندر چرخ جلو 8 $24.75
47748A CLIP(FOR FRONT DISC BRAKE ANTI-RATTLE)
90468-12015 2 $3.20
47748B PIN, W/HOLE(FOR FRONT DISC BRAKE ANTI-RATTLE)
90240-06014 4 $2.53
47750 CYLINDER ASSY, DISC BRAKE, LH
47750-0K061  سیلندر چرخ جلو چپ 1 $604.28
47781 COVER, DISC BRAKE DUST, FRONT RH
47781-0K031 1 $65.20
47782 COVER, DISC BRAKE DUST, FRONT LH
47782-0K031 1 $65.20
 diag_1oedwv6
396

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
04444 VALVE KIT, BOOSTER CONTROL
Not applicable
44610 BOOSTER ASSY, BRAKE
44610-0K020  بوستر ترمز 1 $860.36
44696 GROMMET, CHECK VALVE
90080-48050 1 $1.58
44730 VALVE ASSY, VACUUM CHECK(FOR BRAKE)
44730-22150 1 $40.33
44730C CLIP(FOR VACUUM HOSE)
90466-T0019 2 $2.02
44773F HOSE, UNION TO CHECK VALVE
44773-0K010 1 $42.94
44785 GASKET, BRAKE BOOSTER
44785-17010 1 $3.48
47262A NUT, MASTER CYLINDER PUSH ROD CLEVIS LOCK
94120-41000 1 $0.91
47264D CLEVIS, BRAKE MASTER CYLINDER PUSH ROD
47264-0K010 1 $5.97
47381K BRACKET, BRAKE BOOSTER TUBE CLAMP
47381-0K010 1 $11.23
90178-T0067 *** STD. PART $1.27

diag_1oedwv6

399

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
04493 CYLINDER KIT, BRAKE MASTER
04493-0K010  لوازم پمپ ترمز 1 $95.41
47201 CYLINDER SUB-ASSY, BRAKE MASTER
47201-0K040  پمپ ترمز 1 $360.54
47201B RING, O(FOR BRAKE MASTER CYLINDER)
90016-AH901 1 $3.40
47202 RESERVOIR SUB-ASSY, BRAKE MASTER CYLINDER
47220-0K020  مخزن پمپ ترمز 1 $128.26
47210J GASKET(FOR MASTER CYLINDER)
90430-06104 1 $0.91
47210T BOLT(FOR BRAKE MASTER CYLINDER)
90109-06077 1 $2.69
47230 CAP ASSY, BRAKE MASTER CYLINDER RESERVOIR FILLER
47230-0K010  درب مخزن پمپ ترمز 1 $22.18
47255 GROMMET, MASTER CYLINDER RESERVOIR
47255-16010 2 $11.74
47287 LABEL, BRAKE FLUID INFORMATION
47287-20010 1 $2.41
47299 STRAINER, BRAKE MASTER CYLINDER RESERVOIR
47299-0K010 1 $4.59
90016-AB602 *** STD. PART $1.11
90016-AC701 *** STD. PART $1.19
90179-08204 *** STD. PART $1.11

diag_1oedwv6

391

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
44200 LINK ASSY, POWER STEERING
44200-0K040  جعبه فرمان 1 $1,959.69
44418A TUBE, STEERING RIGHT TURN PRESSURE
44418-0K150 1
44419A TUBE, STEERING LEFT TURN PRESSURE
44419-0K150 1
45046 END SUB-ASSY, TIE ROD, RH
45046-09281  سیبک فرمان راست 1 $67.72
45046A NUT, CASTLE(FOR TIE ROD END)
90171-T0002 2 $1.34
45047 END SUB-ASSY, TIE ROD, LH
45046-09281  سیبک فرمان چپ 1 $67.72
45503 END SUB-ASSY, STEERING RACK
45503-09321  قرقری فرمان 2 $183.85
45503B WASHER, CLAW(FOR STEERING RACK END)
90214-T0001 OD=43 2 $2.73
45535 BOOT, STEERING RACK, NO.1
45535-0K010  گردگیر جعبه فرمان 1 $23.80
45535B CLIP(FOR STEERING RACK BOOT)
90466-T0004 2 $2.02
45535D CLAMP(FOR STEERING RACK BOOT NO.1)
90460-T0001 1 $6.84
45536 BOOT, STEERING RACK, NO.2
45536-0K010  گردگیر جعبه فرمان 1 $23.80
45536A CLAMP(FOR STEERING RACK BOOT NO.2)
90460-T0001 1 $6.84
90119-T0133 *** STD. PART $5.85
90170-15001 *** STD. PART $2.13
90170-T0006 *** STD. PART
90178-T0021 *** STD. PART $1.27
95381-03225 *** STD. PART $0.91

diag_1oedwv6

388

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
44327A GASKET, PRESSURE PORT, NO.1
44327-30030 1 $2.97
44406 TUBE SUB-ASSY, RETURN
44406-0K120  شلنگ هیدرولیک 1 $270.43
44410A BOLT, UNION(FOR PRESSURE FEED TUBE)
96341-41603 1 $10.40
44411 HOSE, PRESSURE FEED
44411-0K090  شلنگ هیدرولیک 1 $238.01
44416 TUBE, RETURN(FOR STEERING GEAR OUTLET)
44416-0K010 1 $20.32
90119-T0061 *** STD. PART $0.99
90466-T0002 *** STD. PART $2.73
90949-T1002 *** STD. PART $2.61
 diag_1oedwv6



369

دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی هایلوکس
04446 GASKET KIT, POWER STEERING PUMP
04446-06110 1 $32.58
44305 CAP SUB-ASSY, VANE PUMP OIL RESERVOIR
44305-22060  درب مخزن پمپ هیدرولیک 1 $29.77
44306 RESERVOIR SUB-ASSY, VANE PUMP OIL
44306-0K010  مخزن پمپ هیدرولیک 1 $228.17
44308 UNION SUB-ASSY, PRESSURE PORT
44308-0K040 1
44313 ROTOR, VANE PUMP
44313-09030 1
44320 PUMP ASSY, VANE
44310-0K030  پمپ هیدرولیک 1 $1,042.59
44330 VALVE ASSY, FLOW CONTROL
44330-0K010 MARK A 1
44330-0K020 MARK B 1
44330-0K030 MARK C 1
44330-0K040 MARK D 1
44330-0K050 MARK E 1
44330-0K060 MARK F 1
44330A SPRING, COMPRESSION(FOR FLOW CONTROL VALVE)
90501-T0001 1
44341 PLATE, VANE PUMP SIDE, FRONT
44341-06010 1
44362A RING, O(FOR VANE PUMP OIL RESERVOIR)
90080-30093 1
90080-10265 *** STD. PART
90080-11552 *** STD. PART $1.27
90119-T0196 *** STD. PART $2.21

diag_1oedwv6

441
