ديفرانسيل عقب هايلوكس 2001-2002-2003-2004

در
دسته بندی ها: لوازم گیربکس و جلوبندی هایلوکس, لوازم یدکی تویوتا, لوازم یدکی هایلوکس
41101 CARRIER SUB-ASSY, DIFFERENTIAL, REAR
41101-35170  كله گاوي عقب 1 $586.30
41110 ديفرانسيل عقب
41110-26440 FINAL GEAR RATIO=43:10=4.300 1 $1,945.94
41110-3D040 FINAL GEAR RATIO=43:10=4.300, W(LSD) 1 $3,023.02
41114 BOLT, REAR DIFFERENTIAL BEARING CAP
90105-12053 4 $2.17
41115 RING, DIFFERENTIAL OIL STORAGE
41115-35010 1 $4.55
41201 كرانويل پنيون عقب
41201-80104 FINAL GEAR RATIO=43:10=4.300 1 $1,122.26
41201A BEARING, TAPERED ROLLER (FOR REAR DRIVE PINION REAR)
90366-35087  بلبرينگ داخلي پنيون ديفرانسيل عقب 1 $163.37
41201B BEARING, TAPERED ROLLER (FOR REAR DRIVE PINION FRONT)
90366-30067  بلبرينگ بيروني پنيون ديفرانسيل عقب 1 $106.67
41201C SEAL, OIL (FOR REAR DIFFERENTIAL CARRIER)
90311-38047  كاسه نمد پنيون ديفرانسيل عقب 1 $10.71
41201D WASHER, PLATE (FOR REAR DIFFERENTIAL DRIVE PINION)
90201-35497 T=1.70 1 $4.19
90201-35498 T=1.73 1 $4.19
90201-35499 T=1.76 1 $4.19
90201-35500 T=1.79 1 $4.19
90201-35501 T=1.82 1 $4.19
90201-35502 T=1.85 1 $4.19
90201-35503 T=1.88 1 $4.19
90201-35504 T=1.91 1 $4.19
90201-35505 T=1.94 1 $4.19
90201-35506 T=1.97 1 $4.19
90201-35507 T=2.00 1 $4.19
90201-35508 T=2.03 1 $4.19
90201-35509 T=2.06 1 $4.19
90201-35510 T=2.09 1 $4.19
90201-35511 T=2.12 1 $4.19
90201-35512 T=2.15 1 $4.19
90201-35513 T=2.18 1 $4.19
90201-35514 T=2.21 1 $4.19
90201-35515 T=2.24, MARK 01 1 $4.19
90201-35516 T=2.27, MARK 02 1 $4.19
90201-35517 T=2.30, MARK 03 1 $4.19
90201-35518 T=2.33, MARK 04 1 $4.19
41204 FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR
41204-35080  فلنچ ديفرانسيل عقب 1 $108.88
41204B NUT (FOR REAR DRIVE PINION)
90179-20018 OD=37 1 $3.72
41214 SLINGER, REAR DIFFERENTIAL DRIVE PINION OIL
41214-26010 1 $11.74
41222 PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK
41222-35020 5 $3.68
41222A BOLT (FOR REAR DIFFERENTIAL RING GEAR SET)
90101-11353 10 $1.23
41231 SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING
41231-24010 1 $19.61
41252 DEFLECTOR, DUST (FOR REAR DIFFERENTIAL)
41252-35040 1 $11.27
41301A BEARING(FOR REAR DIFFERENTIAL CASE)
90366-50007  بلبرينگ داخلي ديفرانسيل 2 $98.76
41302 CASE SUB-ASSY, REAR DIFFERENTIAL
41302-35040 W(LSD) 1 $396.32
41311-60060 1 $457.44
41315 NUT, REAR DIFFERENTIAL BEARING ADJUSTING
41315-35020 2 $16.53
41316 LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT
41316-35010 2 $2.02
41331 GEAR, REAR DIFFERENTIAL SIDE
41331-35011  دنده دشلي ديفرانسيل عقب 2 $116.79
41341 PINION, REAR DIFFERENTIAL
41341-35020 دنده پنيون ديفرانسيل عقب 2 $67.33
41342 SHAFT, REAR DIFFERENTIAL PINION
41342-39610 1 $22.26
41343 PIN, REAR DIFFERENTIAL PINION SHAFT
Not applicable
41351 WASHER, REAR DIFFERENTIAL PINION THRUST
41351-30052 2 $2.21
41351-30060 W(LSD) 4 $3.04
41361 WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1
41361-35160 T=1.8, W(LSD) 6 $11.98
41361-35290 T=1.70, MARK N 2 $11.98
41361-40021 T=1.6 2 $23.76
41362-40021 T=1.7 2 $23.76
41363-40021 T=1.8 2 $23.76
91611-60814 *** STD. PART $0.95
