85910A | RELAY ASSY, CIRCUIT OPENING (FOR EFI) | ||
Not applicable | |||
89421 | SENSOR ASSY, VACUUM (FOR E.F.I.) | ||
Not applicable | |||
89422 | SENSOR, WATER TEMPERATURE (FOR E.F.I.) | ||
89422-33030 | 1 | مهره آب | |
89661 | COMPUTER, ENGINE CONTROL | ||
89661-33L61 | 1 | کامپیوتر موتور | |
89667 | BRACKET, ENGINE CONTROL COMPUTER | ||
89667-33150 | 1 | ||
89668 | BRACKET, ENGINE CONTROL COMPUTER, NO.2 | ||
89668-33230 | 1 |
دسته: لوازم یدکی ES
خطر عقب لکسوس ES250 مدل 2013-2014-2015
52562E | RETAINER, REAR BUMPER, UPPER RH | ||
52562-33050 | کشویی بالای سپر عقب عقب | 1 | |
52563D | RETAINER, REAR BUMPER, UPPER LH | ||
52563-33040 | کشویی بالای سپر عقب چپ | 1 | |
81496 | GUIDE, REAR COMBINATION LAMP | ||
81496-60010 | 2 | $1.54 | |
81496B | GUIDE, REAR LAMP | ||
81496-52020 | 2 | $1.07 | |
81550L | BULB, REAR TURN SIGNAL LAMP | ||
90981-15021 | 12V 21W, AMBER | 2 | $5.14 |
81550N | BULB, BACK UP LAMP | ||
90981-11059 | 12V 16W | 2 | $5.10 |
81550Q | BULB, REAR FOG LAMP, NO.1 | ||
Not applicable | |||
81551D | LENS & BODY, REAR COMBINATION LAMP, RH | ||
81551-33570 | خطر عقب روی گلگیر راست | 1 | |
81554 | GASKET, REAR COMBINATION LAMP BODY, RH | ||
81554-33560 | 1 | ||
81555 | SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, RH | ||
81555-33570 | 1 | ||
81558L | PROTECTOR, REAR COMBINATION LAMP, RH | ||
81558-24040 | 2 | $1.70 | |
81561D | LENS & BODY, REAR COMBINATION LAMP, LH | ||
81561-33570 | خطر عقب روی گلگیر چپ | 1 | |
81564 | GASKET, REAR COMBINATION LAMP BODY, LH | ||
81564-33560 | 1 | ||
81565 | SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, LH | ||
81555-33570 | 1 | ||
81568J | PROTECTOR, REAR COMBINATION LAMP, LH | ||
81558-24040 | 2 | $1.70 | |
81581C | LENS AND BODY, REAR LAMP, RH | ||
81581-33260 | خطر عقب روی درب صندوق راست | 1 | |
81584A | GASKET, REAR LAMP RH | ||
81584-33250 | 1 | ||
81585C | SOCKET & WIRE, REAR LAMP, RH | ||
81585-33260 | 1 | ||
81591B | LENS AND BODY, REAR LAMP, LH | ||
81591-33260 | خطر عقب روی درب صندوق چپ | 1 | |
81594A | GASKET, REAR LAMP LH | ||
81594-33240 | 1 | ||
81595 | SOCKET & WIRE, REAR LAMP, LH | ||
81585-33260 | 1 |
چراغ جلو لکسوس ES250 مدل 2013-2014-2015
81107 | COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, RH | ||
81107-33761 | کامپیوتر نور چراغ جلو راست | 1 | |
81108 | COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, LH | ||
81107-33761 | کامپیوتر نور چراغ جلو چپ | 1 | |
81110B | BULB(FOR HEADLAMP, NO.1) | ||
90981-13046 | 12V65W(SAE), 60W(ECE) | 2 | $30.56 |
81110L | BULB, DISCHARGE HEADLAMP | ||
90981-20024 | 42V 35W | 2 | |
81125 | CORD, HEADLAMP | ||
81125-33B40 | 2 | ||
81131B | HEAD LAMP LENS, RH | ||
81131-33B60 | شیشه چراغ جلو راست | 1 | |
81132B | GASKET, HEADLAMP LENS | ||
81132-50590 | 2 | ||
81134 | GASKET, HEADLAMP | ||
90075-68007 | X | $10.75 | |
81135 | UNIT ASSY, HEADLAMP, RH | ||
81145-33B60 | چراغ جلو راست | 1 | |
81139 | COVER, HEADLAMP SOCKET | ||
90075-65006 | 2 | $7.51 | |
81140A | UNIT ASSY, HEADLAMP DAYTIME RUNNING LIGHT, RH | ||
81140-33B40 | دی لایت راست | 1 | |
81144 | COVER, HEADLAMP, NO.1 | ||
81135-3A150 | 2 | $16.92 | |
81170 | UNIT ASSY, HEADLAMP DAYTIME RUNNING LIGHT, LH | ||
81170-33B40 | دی لایت چپ | 1 | |
81171B | HEAD LAMP LENS, LH | ||
81171-33B60 | شیشه چراغ جلو چپ | 1 | |
81175 | UNIT ASSY, HEADLAMP, LH | ||
81185-33B60 | چراغ جلو چپ | 1 | |
81193 | RETAINER, HEADLAMP PROTECTOR, UPPER RH | ||
81193-33080 | 1 | ||
81193B | RETAINER, HEADLAMP PROTECTOR, UPPER RH NO.2 | ||
81193-33090 | 1 | ||
81194 | RETAINER, HEADLAMP PROTECTOR, UPPER LH | ||
81194-33080 | 1 | ||
81194B | RETAINER, HEADLAMP PROTECTOR, UPPER LH NO.2 | ||
81194-33090 | 1 | ||
81195 | SCREW, HEADLAMP | ||
90075-02056 | 8 | ||
81510A | BULB, FRONT TURN SIGNAL & PARKING LAMP | ||
Not applicable | |||
81510C | BULB (FOR FRONT TURN SIGNAL LAMP) | ||
90981-15021 | 12V 21W, AMBER | 2 | $5.14 |
81515B | SOCKET, FRONT TURN SIGNAL LAMP | ||
90075-60028 | 2 | $9.92 | |
81710F | BULB, FRONT SIDE MAKER LAMP | ||
Not applicable | |||
85661 | MOTOR, HEADLAMP LEVELING, RH | ||
85661-12020 | موتور چراغ جلو راست | 1 | $215.95 |
85662 | MOTOR, HEADLAMP LEVELING, LH | ||
85661-12020 | موتور چراغ جلو چپ | 1 | $215.95 |
85669 | PACKING, HEADLAMP LEVELING MOTOR BASE | ||
90075-99120 | 2 | $3.64 |
آیینه لکسوس ES250 مدل 2013-2014-2015
87810 | MIRROR ASSY, INNER REAR VIEW | ||
87810-0WB10 | آیینه داخل | 1 | |
87834 | COVER, INNER REAR VIEW MIRROR STAY HOLDER | ||
87818-76010 | قاب روی دسته آیینه داخل | 1 | |
87910 | آیینه بغل راست | ||
87910-33B10-A0 | WHITE PEARL CS., 077 | 1 | |
87910-33B10-B0 | MERCURY GRAY MC., 1H9 | 1 | |
87910-33B10-B1 | PLATINUM SILVER ME., 1J4 | 1 | |
87910-33B10-C0 | BLACK, 212 | 1 | |
87910-33B10-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87910-33B10-D0 | RED MC.CS., 3R1 | 1 | |
87910-33B10-E0 | SLEEK ECRU ME., 4U7 | 1 | |
87910-33B10-E1 | FIRE AGATE M.M., 4V3 | 1 | |
87910-33B10-J0 | SILVERY BLUE ME., 8U9 | 1 | |
87910-33B10-J1 | LAPIS LAZULI MC., 8V3 | 1 | |
8791A | قاب آیینه راست | ||
8791A-76070-A0 | WHITE PEARL CS., 077 | 1 | |
8791A-76070-B1 | MERCURY GRAY MC., 1H9 | 1 | |
8791A-76070-B3 | PLATINUM SILVER ME., 1J4 | 1 | |
8791A-76070-C0 | BLACK, 212 , 2MH | 1 | |
8791A-76070-C2 | STARLIGHT BLACK GF., 217 | 1 | |
8791A-76070-D0 | RED MC.CS., 3R1 | 1 | |
8791A-76070-E0 | FIRE AGATE M.M., 4V3 | 1 | |
8791A-76070-E1 | SLEEK ECRU ME., 4U7 | 1 | |
8791A-76070-J1 | SILVERY BLUE ME., 8U9 | 1 | |
8791A-76070-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87931 | OUTER MIRROR, RH | ||
87931-33B10 | شیشه آیینه راست | 1 | |
87940 | آیینه بغل چپ | ||
87940-33B00-A0 | WHITE PEARL CS., 077 | 1 | |
87940-33B00-B0 | MERCURY GRAY MC., 1H9 | 1 | |
87940-33B00-B1 | PLATINUM SILVER ME., 1J4 | 1 | |
87940-33B00-C0 | BLACK, 212 | 1 | |
87940-33B00-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87940-33B00-D0 | RED MC.CS., 3R1 | 1 | |
87940-33B00-E0 | SLEEK ECRU ME., 4U7 | 1 | |
87940-33B00-E1 | FIRE AGATE M.M., 4V3 | 1 | |
87940-33B00-J0 | SILVERY BLUE ME., 8U9 | 1 | |
87940-33B00-J1 | LAPIS LAZULI MC., 8V3 | 1 | |
87946 | پایه و موتور تاشو آیینه بغل راست | ||
87908-33B00-A0 | WHITE PEARL CS., 077 | 1 | |
87908-33B00-B0 | MERCURY GRAY MC., 1H9 | 1 | |
87908-33B00-B1 | PLATINUM SILVER ME, 1J4 | 1 | |
87908-33B00-C0 | BLACK, 212 | 1 | |
87908-33B00-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87908-33B00-D0 | RED MC.CS., 3R1 | 1 | |
87908-33B00-E0 | SLEEK ECURU ME, 4U7 | 1 | |
87908-33B00-E1 | FIRE AGATE M.M., 4V3 | 1 | |
87908-33B00-J0 | SILVERY BLUE ME, 8U9 | 1 | |
87908-33B00-J1 | LAPIS LAZULI MC., 8V3 | 1 | |
8794A | قاب آیینه بغل چپ | ||
8794A-76070-A0 | WHITE PEARL CS., 077 | 1 | |
8794A-76070-B1 | MERCURY GRAY MC., 1H9 | 1 | |
8794A-76070-B3 | PLATINUM SILVER ME., 1J4 | 1 | |
8794A-76070-C0 | BLACK, 212 , 2MH | 1 | |
8794A-76070-C2 | STARLIGHT BLACK GF., 217 | 1 | |
8794A-76070-D0 | RED MC.CS., 3R1 | 1 | |
8794A-76070-E0 | FIRE AGATE M.M., 4V3 | 1 | |
8794A-76070-E1 | SLEEK ECRU ME., 4U7 | 1 | |
8794A-76070-J1 | SILVERY BLUE ME., 8U9 | 1 | |
8794A-76070-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87961 | MIRROR OUTER, LH | ||
87961-33B00 | شیشه آیینه چپ | 1 | |
87966 | پایه و موتور تاشو آیینه چپ | ||
87909-33A90-A0 | WHITE PEARL CS., 077 | 1 | |
87909-33A90-B0 | MERCURY GRAY MC., 1H9 | 1 | |
87909-33A90-B1 | PLATINUM SILVER ME, 1J4 | 1 | |
87909-33A90-C0 | BLACK, 212 | 1 | |
87909-33A90-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87909-33A90-D0 | RED MC.CS., 3R1 | 1 | |
87909-33A90-E0 | SLEEK ECURU ME, 4U7 | 1 | |
87909-33A90-E1 | FIRE AGATE M.M., 4V3 | 1 | |
87909-33A90-J0 | SILVERY BLUE ME, 8U9 | 1 | |
87909-33A90-J1 | LAPIS LAZULI MC., 8V3 |
رله و کامپیوتر لکسوس ES350 مدل 2008-2009-2010-2011-2012
82715-33B50 | *** STD. PART | $11.51 | |
82715-33G70 | *** STD. PART | ||
83530 | مهره روغن | ||
83530-28020 | DENSO | 1 | $38.43 |
83530-60020 | YAZAKI | 1 | $38.43 |
84540 | SWITCH ASSY, NEUTRAL START | ||
84540-33010 | 1 | $364.69 | |
87616-42020 | *** STD. PART | $3.52 | |
89465 | سنسور اکسیژن | ||
89465-33360 | LH | 1 | $249.08 |
89465-33420 | RH | 1 | $249.08 |
89467B | سنسور نسبت سوخت هوا | ||
89467-33170 | LH | 1 | $277.91 |
89467-33180 | RH | 1 | $277.91 |
89491 | SENSOR, ENGINE OIL LEVEL | ||
89491-48010 | سنسور درجه روغن | 1 | $459.10 |
89491A | GASKET, ENGINE OIL LEVEL SENSOR | ||
Not applicable | |||
89530C | COMPUTER ASSY, TRANSMISSION CONTROL | ||
89530-33090 | کامپیوتر گیربکس | 1 | |
89615 | SENSOR, KNOCK CONTROL | ||
89615-20090 | سنسور ضربه | 2 | $210.22 |
28300 | RELAY ASSY, STARTER | ||
28300-28010 | رله استارت | 1 | $73.14 |
28300D | RELAY, STARTER CUT | ||
90987-02027 | رله قطع کن استارت | 1 | $81.45 |
28371C | RELAY, IGNITION, NO.2 | ||
90987-02027 | رله استارت | 1 | $81.45 |
82600F | جعبه فیوز | ||
90982-09020 | 7.5A, MINI FUSE | X | $1.19 |
90982-09021 | 10A, MINI FUSE | X | $1.19 |
90982-09022 | 15A, MINI FUSE | X | $1.19 |
90982-09023 | 20A, MINI FUSE | X | $1.19 |
90982-09024 | 25A, MINI FUSE | X | $1.19 |
90982-09025 | 30A, MINI FUSE | X | $1.19 |
82616 | PULLER, FUSE | ||
82616-58010 | 1 | $3.48 | |
82620A | BLOCK ASSY, FUSIBLE LINK | ||
82620-07090 | جعبه فیوز | 1 | $24.24 |
82620B | BLOCK ASSY, FUSIBLE LINK | ||
82620-07080 | جعبه فیوز | 1 | $24.87 |
82662A | COVER, RELAY BLOCK, UPPER, NO.1 | ||
82662-33210 | درب بالای جعبه فیوز | 1 | $49.86 |
82663 | COVER, RELAY BLOCK, LOWER | ||
82663-33070 | درب پایینی حعبه فیوز | 1 | $51.99 |
82720 | BLOCK ASSY, ENGINE ROOM JUNCTION | ||
82720-33100 | جعبه فیوز داخل موتور | 1 | $254.22 |
82740 | BLOCK ASSY, ENGINE ROOM RELAY | ||
82740-33010 | جعبه فیوز داخل موتور | 1 | $92.67 |
82824L | PIN, SHORT | ||
82824-41010 | 1 | $4.43 | |
85912 | RELAY, DEFOGGER | ||
90987-04010 | رله پرژکتور | 1 | $77.69 |
85916L | RELAY, REAR FOG LAMP | ||
Not applicable | |||
85927 | RELAY, COOLING FAN | ||
90987-02025 | رله فن | 1 | $81.45 |
85927A | RELAY, COOLING FAN, NO.2 | ||
Not applicable | |||
85927B | RELAY, COOLING FAN, NO.3 | ||
Not applicable | |||
85934 | RELAY, MAGNET-CLUTCH | ||
90987-02028 | رله کلاچ کولر | 1 | $81.45 |
85942 | RELAY, HEADLAMP CLEANER CONTROL | ||
85942-30020 | رله چراغ شور | 1 | $229.31 |
89257 | COMPUTER, COOLING FAN | ||
89257-30070 | کامپیوتر فن | 1 | $352.67 |
28371 | RELAY, IGNITION, NO.1 | ||
90987-02025 | رله استارت | 1 | $81.45 |
81980 | FLASHER ASSY, TURN SIGNAL | ||
81980-30170 | رله فلشر | 1 | $83.11 |
82210J | فیوز | ||
90982-08283 | 30A, TERMINAL:FEMALE | X | $14.98 |
82600F | جعبه فیوز اتاق | ||
90982-09020 | 7.5A, MINI FUSE | X | $1.19 |
90982-09021 | 10A, MINI FUSE | X | $1.19 |
90982-09022 | 15A, MINI FUSE | X | $1.19 |
90982-09023 | 20A, MINI FUSE | X | $1.19 |
90982-09024 | 25A, MINI FUSE | X | $1.19 |
90982-09025 | 30A, MINI FUSE | X | $1.19 |
82672A | COVER, JUNCTION BLOCK | ||
82672-33330 | درب جعبه فیوز | 1 | |
82673A | BRACKET, JUNCTION BLOCK | ||
82673-33030 | 1 | $13.92 | |
82675B | TERMINAL, JUNCTION | ||
82675-44010 | 1 | $2.33 | |
82731 | BLOCK, DRIVER SIDE JUNCTION | ||
82730-33650 | جعبه فیوز سمت راننده | 1 | $851.51 |
84340 | SWITCH ASSY, STOP LAMP | ||
84340-69015 | مهره استپ لامپ | 1 | $45.51 |
84345 | ADJUSTER, STOP LAMP SWITCH MOUNTING | ||
84345-51010 | 1 | $5.10 | |
84550 | SWITCH ASSY, PARKING BRAKE | ||
84550-16060 | مهره چراغ پارک | 1 | $31.99 |
85916D | RELAY, FOG LAMP | ||
90987-02027 | رله پرژکتور | 1 | $81.45 |
85916N | RELAY, TAIL LAMP | ||
90987-02027 | رله خطر عقب | 1 | $81.45 |
85930G | RELAY, ACC | ||
90987-02025 | رله کولر | 1 | $81.45 |
85940 | RELAY ASSY, WINDSHIELD WIPER | ||
85940-33140 | رله تیغه برف پاک کن | 1 | $225.99 |
89111 | COMPUTER, NETWORK GATEWAY | ||
89111-33010 | کامپیئوتر شبکه | 1 | $432.02 |
89227 | COMPUTER, MULTIPLEX TILT & TELESCOPIC | ||
89227-33010 | 1 | $645.44 | |
89430 | COMPUTER ASSY, OUTER MIRROR CONTROL | ||
89430-33090 | کامپیوتر آیینه | 1 | $397.94 |
89940 | COMPUTER ASSY, HEADLAMP SWIVEL | ||
89940-33080 |
84119 | RHEOSTAT, LIGHT CONTROL | ||
84119-33140 | کلید تنظیم نور چراغ | 1 | $99.71 |
84150D | SWITCH ASSY, HEADLAMP CLEANER | ||
84150-30010 | کلید چراغ شور | 1 | $74.80 |
84150E | BULB, HEADLAMP CLEANER SWITCH | ||
90010-01096 | 14V 0.91W, W(CAP) | 1 | $5.38 |
84155 | SWITCH, HEADLAMP SWIVEL MAIN | ||
84155-48010 | 1 | $70.93 | |
84751 | SWITCH, SEAT HEATER | ||
84751-30180 | کلید گرم کن صندلی | 1 | $401.38 |
84751B | BULB, SEAT HEATER SWITCH | ||
90010-01109 | 14V 1.4W | 1 | $5.85 |
84770A | SWITCH ASSY, PRE-COLLISION SYSTEM CANCEL | ||
Not applicable | |||
84840 | SWITCH ASSY, LUGGAGE COMPARTMENT DOOR OPENING | ||
84840-33080 | کلید درب صندوق | 1 | $109.56 |
84840C | SWITCH ASSY, LUGGAGE DOOR OPENING, CANCEL | ||
84840-51020 | 1 | $64.80 | |
84870A | SWITCH ASSY, OUTER MIRROR | ||
84872-30020 | کلید تنظیم آیینه | 1 | $94.73 |
84870B | BULB, OUTER MIRROR SWITCH | ||
84999-10470 | 14V 1.12W | 1 | $8.90 |
84870C | CAP, OUTER MIRROR SWITCH BULB | ||
84998-10430 | 1 | $2.25 | |
84873A | SWITCH, RETRACTABLE OUTER MIRROR | ||
84873-30020 | کلید آیینه تاشو | 1 | $83.54 |
84873B | BULB, RETRACTABLE OUTER MIRROR SWITCH | ||
90010-01095 | 14V0.63W, W(GREEN CAP) | 1 | $5.38 |
84940D | SWITCH ASSY, REAR SUN SHADE | ||
84940-33030 | کلید پرده عقب | 1 | $74.80 |
84940E | BULB, REAR SUN SHADE | ||
90010-01117 | 14V 0.98W | 1 | $5.34 |
85500 | LIGHTER ASSY, CIGARETTE | ||
85500-24050 | دکمه فندک | 1 | $65.67 |
85500B | BULB, CIGARETTE LIGHTER | ||
90981-11018 | 12V 1.2W W/O SOCKET | 1 | $3.12 |
85500F | CAP, CIGARETTE LIGHTER BULB | ||
84998-10510 | 1 | $2.25 | |
85520 | KNOB AND ELEMENT ASSY, CIGARETTE LIGHTER | ||
85520-89101 | فندک | 1 | $27.08 |
85530E | SOCKET ASSY, POWER OUTLET, NO.3 | ||
85530-42010 | 1 | $41.20 | |
85535E | COVER, POWER OUTLET SOCKET, NO.2 | ||
85535-60100-C0 | BLACK | 1 | $8.82 |
85539B | LABEL, POWER OUTLET NOTICE, CENTER | ||
85539-60020 | 1 | $1.46 | |
89611 | SWITCH, PUSH START | ||
89611-30020 | 1 | $275.93 | |
84140 | SWITCH ASSY, HEADLAMP DIMMER | ||
84140-48140 | دسته راهنما | 1 | $197.29 |
84250A | SWITCH ASSY, STEERING PAD | ||
84250-33150-C0 | BLACK, TRIM2* | 1 | $283.28 |
84250-33150-E0 | ORCHID BROWN, TRIM0* | 1 | $283.28 |
84250-33150-J0 | DK.BLUE, TRIM1* | 1 | $283.28 |
84250-33190-C0 | AUDIO-NAVI, AM/FM, CST, 6CD CHANGER, BT, 8SPEAKER, BLACK, TRIM2* | 1 | $283.28 |
84250-33190-E0 | AUDIO-NAVI, AM/FM, CST, 6CD CHANGER, BT, 8SPEAKER, ORCHID BROWN, TRIM0* | 1 | $283.28 |
84250-33190-J0 | AUDIO-NAVI, AM/FM, CST, 6CD CHANGER, BT, 8SPEAKER, DK.BLUE, TRIM1* | 1 | $283.28 |
84306 | CABLE SUB-ASSY, SPIRAL | ||
84306-48030 | اسپیرال فرمان (فنر ساعتی) | 1 | $304.47 |
84650 | SWITCH ASSY, WINDSHIELD WIPER | ||
84652-33440 | دسته برف پاک کن | 1 | $184.04 |
89235A | SWITCH, TILT & TELESCOPIC | ||
89235-48010 | 1 | $64.80 | |
89245B | SENSOR, STEERING | ||
89245-52030 | سنسور زاویه فرمان | 1 | $440.32 |
90159-50199 | *** STD. PART |
84920 | SWITCH ASSY, POWER SEAT | ||
Not applicable | |||
84921A | KNOB, POWER SEAT SWITCH (FOR RECLINING) | ||
84921-53030-A0 | IVORY, TRIM0*, RH | 1 | $7.91 |
84921-53030-B3 | LT.GRAY, TRIM1*, RH | 1 | $7.91 |
84921-53030-C0 | BLACK, TRIM2*, RH | 1 | $7.91 |
84921-53040-A0 | IVORY, TRIM0*, LH | 1 | $7.91 |
84921-53040-B3 | LT.GRAY, TRIM1*, LH | 1 | $7.91 |
84921-53040-C0 | BLACK, TRIM2*, LH | 1 | $7.91 |
84921B | KNOB, POWER SEAT SWITCH (FOR SLIDE & VERTICAL) | ||
84921-53010-A0 | IVORY, TRIM0*, RH | 1 | $33.65 |
84921-53010-B3 | LT.GRAY, TRIM1*, RH | 1 | $33.65 |
84921-53010-C0 | BLACK, TRIM2*, RH | 1 | $33.65 |
84921-53020-A0 | IVORY, TRIM0*, LH | 1 | $33.65 |
84921-53020-B3 | LT.GRAY, TRIM1*, LH | 1 | $33.65 |
84921-53020-C0 | BLACK, TRIM2*, LH | 1 | $33.65 |
84922A | SWITCH, FRONT POWER SEAT(FOR LUMBAR) | ||
84920-30240-A0 | IVORY, TRIM0*, RH | 1 | $59.03 |
84920-30240-B3 | LT.GRAY, TRIM1*, RH | 1 | $64.56 |
84920-30240-C0 | BLACK, TRIM2*, RH | 1 | $64.56 |
84920-33050-A0 | IVORY, TRIM0*, LH | 1 | $85.48 |
84920-33050-B0 | LT.GRAY, TRIM1*, LH | 1 | $85.48 |
84920-33050-C0 | BLACK, TRIM2*, LH | 1 | $85.48 |
84922B | SWITCH, FRONT POWER SEAT, RH | ||
84070-33060 | 1 | $564.90 | |
84922C | SWITCH, FRONT POWER SEAT, LH | ||
84070-33030 | 1 | $618.20 | |
84928 | SWITCH, SEAT VARIABLE CUSHION | ||
84928-33010-A0 | IVORY, TRIM0* | 1 | $76.43 |
84928-33010-B0 | LT.GRAY, TRIM1* | 1 | $69.82 |
84928-33010-C0 | BLACK, TRIM2* | 1 | $69.82 |
90167-40044 | *** STD. PART | $0.87 | |
93560-54010 | *** STD. PART | $0.83 |
83320 | GAGE ASSY, FUEL SENDER | ||
83320-33110 | درجه داخل باک | 1 | $78.13 |
84233 | SWITCH ASSY, COURTESY LAMP (FOR FRONT DOOR) | ||
84231-53010 | 2 | $20.95 | |
84234 | SWITCH ASSY, COURTESY LAMP (FOR REAR DOOR) | ||
84231-53010 | 2 | $20.95 | |
84810 | SWITCH ASSY, POWER WINDOW REGULATOR | ||
84810-33110 | کلید شیشه بالابر شاگرد | 1 | $263.20 |
84810D | SWITCH ASSY, POWER WINDOW REGULATOR, REAR | ||
84810-33110 | کلید شیشه بالابر درب عقب | 2 | $263.20 |
84820 | MASTER SWITCH ASSY, POWER WINDOW REGULATOR | ||
84040-33070 | کلید شیشه بالابر راننده | 1 | $469.38 |
84927 | کلید حافظه صندلی | ||
84927-33060 | LH | 1 | $105.13 |
84927-33070 | RH | 1 | $105.13 |
84930 | SWITCH ASSY, DOOR CONTROL | ||
84930-33110 | 1 | $100.15 | |
85911A | RELAY, AUTO CURTAIN | ||
85911-50010 | 1 | $527.27 | |
89373 | SENSOR, LAMP FAILURE INDICATOR | ||
89373-33330 | 1 | $323.18 | |
89815 | COMPUTER, SEAT BELT CONTROL | ||
Not applicable | |||
90164-40103 | *** STD. PART | $0.83 | |
90901-48003 | *** STD. PART | $2.85 | |
91631-J0612 | *** STD. PART |
آیینه بغل لکسوس ES350 مدل 2010-2011-2012
87810 | MIRROR ASSY, INNER REAR VIEW | ||
87810-0W260 | آیینه داخل اتاق | 1 | $776.74 |
87834 | COVER, INNER REAR VIEW MIRROR STAY HOLDER | ||
87818-33010 | 1 | $17.59 | |
87908 | موتور آیینه سمت راست | ||
87908-33850-A0 | WHITE PEARL CS., 077 | 1 | |
87908-33850-B0 | DK.GRAY MC., 1G0 | 1 | |
87908-33850-B1 | SILVER M.M., 1G1 | 1 | |
87908-33850-B2 | MERCURY GRAY MC., 1H9 | 1 | |
87908-33850-C0 | BLACK, 212 | 1 | |
87908-33850-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87908-33850-D0 | RED MC.CS., 3R1 | 1 | |
87908-33850-E0 | SABLE M.M., 4T5 | 1 | |
87908-33850-E1 | SLEEK ECRU ME., 4U7 | 1 | |
87908-33850-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
87908-33850-J0 | DK.BLUE MC. CC., 8U0 | 1 | |
87908-33850-J1 | SILVERY BLUE ME., 8U9 | 1 | |
87908-33850-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87909 | موتور آیینه چپ | ||
87909-33850-A0 | WHITE PEARL CS., 077 | 1 | |
87909-33850-B0 | DK.GRAY MC., 1G0 | 1 | |
87909-33850-B1 | SILVER M.M., 1G1 | 1 | |
87909-33850-B2 | MERCURY GRAY MC., 1H9 | 1 | |
87909-33850-C0 | BLACK, 212 | 1 | |
87909-33850-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87909-33850-D0 | RED MC.CS., 3R1 | 1 | |
87909-33850-E0 | SABLE M.M., 4T5 | 1 | |
87909-33850-E1 | SLEEK ECRU ME., 4U7 | 1 | |
87909-33850-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
87909-33850-J0 | DK.BLUE MC. CC., 8U0 | 1 | |
87909-33850-J1 | SILVERY BLUE ME., 8U9 | 1 | |
87909-33850-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87910 | آیینه سمت راست | ||
87910-33860-A0 | WHITE PEARL CS., 077 | 1 | |
87910-33860-B0 | DK.GRAY MC., 1G0 | 1 | |
87910-33860-B1 | SILVER M.M., 1G1 | 1 | |
87910-33860-B2 | MERCURY GRAY MC., 1H9 | 1 | |
87910-33860-C0 | BLACK, 212 | 1 | |
87910-33860-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87910-33860-D0 | RED MC.CS., 3R1 | 1 | |
87910-33860-E0 | SABLE M.M., 4T5 | 1 | |
87910-33860-E1 | SLEEK ECRU ME., 4U7 | 1 | |
87910-33860-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
87910-33860-J0 | DK.BLUE MC. CC., 8U0 | 1 | |
87910-33860-J1 | SILVERY BLUE ME., 8U9 | 1 | |
87910-33860-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87910-33870-A0 | PHILIPPINE SPEC, WHITE PEARL CS., 077 | 1 | |
87910-33870-B0 | PHILIPPINE SPEC, DK.GRAY MC., 1G0 | 1 | |
87910-33870-B1 | PHILIPPINE SPEC, SILVER M.M., 1G1 | 1 | |
87910-33870-B2 | PHILIPPINE SPEC, MERCURY GRAY MC., 1H9 | 1 | |
87910-33870-C0 | PHILIPPINE SPEC, BLACK, 212 | 1 | |
87910-33870-C1 | PHILIPPINE SPEC, STARLIGHT BLACK GF., 217 | 1 | |
87910-33870-D0 | PHILIPPINE SPEC, RED MC.CS., 3R1 | 1 | |
87910-33870-E0 | PHILIPPINE SPEC, SABLE M.M., 4T5 | 1 | |
87910-33870-E1 | PHILIPPINE SPEC, SLEEK ECRU ME., 4U7 | 1 | |
87910-33870-G0 | PHILIPPINE SPEC, DEEP PERIDOT MC., 6V6 | 1 | |
87910-33870-J0 | PHILIPPINE SPEC, DK.BLUE MC. CC., 8U0 | 1 | |
87910-33870-J1 | PHILIPPINE SPEC, SILVERY BLUE ME., 8U9 | 1 | |
87910-33870-J2 | PHILIPPINE SPEC, LAPIS LAZULI MC., 8V3 | 1 | |
8791A | قاب آیینه راست | ||
8791A-53390-A0 | WHITE PEARL CS., 077 | 1 | |
8791A-53390-B0 | DK.GRAY MC., 1G0 | 1 | |
8791A-53390-B1 | SILVER M.M., 1G1 | 1 | |
8791A-53390-B2 | MERCURY GRAY MC., 1H9 | 1 | |
8791A-53390-C0 | BLACK, 212 | 1 | |
8791A-53390-C1 | STARLIGHT BLACK GF., 217 | 1 | |
8791A-53390-D0 | RED MC.CS., 3R1 | 1 | |
8791A-53390-E1 | SABLE M.M., 4T5 | 1 | |
8791A-53390-E3 | SLEEK ECRU ME., 4U7 | 1 | |
8791A-53390-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
8791A-53390-J1 | DK.BLUE MC. CC., 8U0 | 1 | |
8791A-53390-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
8791A-53390-J4 | SILVERY BLUE ME., 8U9 | 1 | |
87931 | OUTER MIRROR, RH | ||
87931-33730 | شیشه آیینه راست | 1 | $272.03 |
87931-33770 | PHILIPPINE SPEC | 1 | $243.13 |
87940 | آیینه چپ | ||
87940-33860-A0 | WHITE PEARL CS., 077 | 1 | |
87940-33860-B0 | DK.GRAY MC., 1G0 | 1 | |
87940-33860-B1 | SILVER M.M., 1G1 | 1 | |
87940-33860-B2 | MERCURY GRAY MC., 1H9 | 1 | |
87940-33860-C0 | BLACK, 212 | 1 | |
87940-33860-C1 | STARLIGHT BLACK GF., 217 | 1 | |
87940-33860-D0 | RED MC.CS., 3R1 | 1 | |
87940-33860-E0 | SABLE M.M., 4T5 | 1 | |
87940-33860-E1 | SLEEK ECRU ME., 4U7 | 1 | |
87940-33860-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
87940-33860-J0 | DK.BLUE MC. CC., 8U0 | 1 | |
87940-33860-J1 | SILVERY BLUE ME., 8U9 | 1 | |
87940-33860-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
87940-33870-A0 | PHILIPPINE SPEC, WHITE PEARL CS., 077 | 1 | |
87940-33870-B0 | PHILIPPINE SPEC, DK.GRAY MC., 1G0 | 1 | |
87940-33870-B1 | PHILIPPINE SPEC, SILVER M.M., 1G1 | 1 | |
87940-33870-B2 | PHILIPPINE SPEC, MERCURY GRAY MC., 1H9 | 1 | |
87940-33870-C0 | PHILIPPINE SPEC, BLACK, 212 | 1 | |
87940-33870-C1 | PHILIPPINE SPEC, STARLIGHT BLACK GF., 217 | 1 | |
87940-33870-D0 | PHILIPPINE SPEC, RED MC.CS., 3R1 | 1 | |
87940-33870-E0 | PHILIPPINE SPEC, SABLE M.M., 4T5 | 1 | |
87940-33870-E1 | PHILIPPINE SPEC, SLEEK ECRU ME., 4U7 | 1 | |
87940-33870-G0 | PHILIPPINE SPEC, DEEP PERIDOT MC., 6V6 | 1 | |
87940-33870-J0 | PHILIPPINE SPEC, DK.BLUE MC. CC., 8U0 | 1 | |
87940-33870-J1 | PHILIPPINE SPEC, SILVERY BLUE ME., 8U9 | 1 | |
87940-33870-J2 | PHILIPPINE SPEC, LAPIS LAZULI MC., 8V3 | 1 | |
8794A | قاب آیینه چپ | ||
8794A-53390-A0 | WHITE PEARL CS., 077 | 1 | |
8794A-53390-B0 | DK.GRAY MC., 1G0 | 1 | |
8794A-53390-B1 | SILVER M.M., 1G1 | 1 | |
8794A-53390-B2 | MERCURY GRAY MC., 1H9 | 1 | |
8794A-53390-C0 | BLACK, 212 | 1 | |
8794A-53390-C1 | STARLIGHT BLACK GF., 217 | 1 | |
8794A-53390-D0 | RED MC.CS., 3R1 | 1 | |
8794A-53390-E1 | SABLE M.M., 4T5 | 1 | |
8794A-53390-E3 | SLEEK ECRU ME., 4U7 | 1 | |
8794A-53390-G0 | DEEP PERIDOT MC., 6V6 | 1 | |
8794A-53390-J1 | DK.BLUE MC. CC., 8U0 | 1 | |
8794A-53390-J2 | LAPIS LAZULI MC., 8V3 | 1 | |
8794A-53390-J4 | SILVERY BLUE ME., 8U9 | 1 | |
87961 | شیشه آیینه چپ | ||
87961-33750 | PHILIPPINE SPEC | 1 | $292.32 |
87961-53300 | 1 | $267.14 | |
90179-06146 | *** STD. PART | $1.34 |
سپر جلو لکسوس es350 مدل 2010-2012
47749-50090 | *** STD. PART | $0.63 | |
52114A | BRACKET, FRONT BUMPER EXTENTION MOUNTING | ||
52114-33260 | قاب پلاک | 1 | |
52119A | سپر جلو | ||
52119-33973 | 1 | ||
52119-33975 | CLEARANCE SONER-WITH | 1 | |
52127D | COVER, FRONT BUMPER HOLE, RH | ||
52128-33911 | درپوش بکسل بند | 1 | |
52131A | REINFORCEMENT, FRONT BUMPER | ||
52021-33160 | دیاق سپر جلو | 1 | $195.27 |
52141D | STAY, FRONT BUMPER, RH | ||
52145-33050 | کشویی سپر جلو راست | 1 | $21.31 |
52142C | STAY, FRONT BUMPER, LH | ||
52146-33050 | کشویی سپر جلو چپ | 1 | $21.31 |
52162C | PIECE, FRONT BUMPER | ||
52161-16010 | 2 | $2.41 | |
52535C | RETAINER, FRONT BUMPER SIDE | ||
52535-30150 | 2 | $4.27 | |
52611 | ABSORBER, FRONT BUMPER ENERGY | ||
52611-33190 | فوم پشت سپر جلو | 1 | |
53113E | GRILLE, RADIATOR, LOWER NO.2 | ||
53113-33010 | توری داخل سپر | 1 | |
53119E | PROTECTOR, RADIATOR GRILLE | ||
53119-33141 | 2 | $12.45 | |
53141C | GARNISH, RADIATOR GRILLE | ||
53141-33100 | 1 | ||
53142C | GARNISH, RADIATOR GRILLE, NO.2 | ||
53142-33110 | 1 | ||
53879H | RETAINER, FRONT FENDER LINER | ||
53879-50020 | 4 | $7.71 |
خنک کن روغن لکسوس es350 مدل 2007-2008-2009
32907A | TUBE, OIL COOLER | ||
32907-33140 | 1 | $58.63 | |
32910 | COOLER ASSY, OIL | ||
32910-33090 | 1 | $419.53 | |
32921C | UNION(FOR OIL COOLER TUBE) | ||
90404-14027 | OUTLET | 1 | $10.32 |
90407-14032 | INLET | 1 | $12.38 |
32921G | RING, O(FOR OIL COOLER TUBE UNION) | ||
90301-11006 | 2 | $3.47 | |
32930 | ACCESSORY ASSY, OIL COOLER | ||
32930-33010 | 1 | $82.28 | |
32941 | HOSE, OIL COOLER INLET, NO.1 | ||
32941-33070 | 1 | $35.50 | |
32942 | HOSE, OIL COOLER OUTLET, NO.1 | ||
32942-33060 | 1 | $37.24 | |
32943A | HOSE, TRANSMISSION OIL COOLER, NO.2 | ||
32943-33100 | 1 | $29.97 |
لنت ترمز جلو لکسوس ES350 مدل 2007-2008-2009
350
04465 |
لنت جلو | ||
04465-33450 | MARK NBK PN562H | 1 | $118.78 |
04465-33470 | MARK NBK D6911H | 1 | |
04479 | CYLINDER KIT, DISC BRAKE, FRONT | ||
04478-33100 | لوازم سیلندر ترمز جلو | 1 | $62.44 |
04945 | SHIM KIT, ANTI SQUEAL, FRONT | ||
04945-33260 | شیم لنت | 1 | $33.92 |
04947 | FITTING KIT, DISC BRAKE, FRONT | ||
04947-33240 | خار لنت | 1 | $61.95 |
31478B | CAP, BLEEDER PLUG(FOR FRONT DISC BRAKE) | ||
31478-30010 | 2 | $2.21 | |
47547B | PLUG, BLEEDER(FOR FRONT DISC BRAKE) | ||
47547-20010 | 2 | $4.35 | |
47710A | BOLT, HEXAGON(FOR FRONT DISC BRAKE CALIPER) | ||
90105-12208 | *12-1.25PX29.5-23 | 4 | $2.02 |
47715A | PIN, FRONT DISC BRAKE CYLINDER SLIDE | ||
47715-52190 | 2 | $8.97 | |
47715D | PIN, FRONT DISC BRAKE CYLINDER SLIDE, NO.2 | ||
47715-33340 | 2 | $8.97 | |
47716 | PLATE, PAD SUPPORT, NO.1(FOR FRONT DISC BRAKE) | ||
47718-33340 | 2 | $7.79 | |
47717 | PLATE, PAD SUPPORT, NO.2(FOR FRONT DISC BRAKE) | ||
47719-33340 | 2 | $7.79 | |
47718A | PLATE, PAD SUPPORT, NO.3(FOR FRONT DISC BRAKE) | ||
47718-33340 | 2 | $7.79 | |
47719A | PLATE, PAD SUPPORT, NO.4(FOR FRONT DISC BRAKE) | ||
47719-33340 | 2 | $7.79 | |
47721 | MOUNTING, FRONT DISC BRAKE CYLINDER, RH | ||
47721-33340 | فکی سیلندر چرخ جلو راست | 1 | $126.72 |
47721A | BOLT(FOR FRONT DISC BRAKE CYLINDER MOUNTING) | ||
90105-08164 | PLANT NO.A32-1.00PX23-15 | 4 | $1.27 |
47722 | MOUNTING, FRONT DISC BRAKE CYLINDER, LH | ||
47722-33340 | فکی سیلندر چرخ جلو چپ | 1 | $126.72 |
47730 | CYLINDER ASSY, FRONT DISC BRAKE, RH | ||
47730-33340 | سیلندر چرخ جلو راست | 1 | $472.90 |
47731 | PISTON, FRONT DISC BRAKE | ||
47731-33340 | پیستون سیلندر چرخ جلو | 2 | $49.46 |
47731A | RING, SET(FOR FRONT DISC BRAKE PISTON) | ||
90522-76002 | 2 | $3.68 | |
47750 | CYLINDER ASSY, DISC BRAKE, LH | ||
47750-33340 | سیلندر چرخ جلو چپ | 1 | $472.90 |
47769 | BUSH, CYLINDER SLIDE, NO.1(FOR FRONT DISC BRAKE) | ||
47769-50010 | 2 | $5.30 | |
47771 | PLATE, PAD WEAR INDICATOR, NO.1 | ||
47771-53060 | 4 | $2.06 | |
47781 | COVER, DISC BRAKE DUST, FRONT RH | ||
47781-33040 | 1 | $31.51 | |
47781A | BOLT(FOR DUST COVER TO STEERING KNUCKLE ARM SETTING) | ||
90119-06227 | 8 | $0.79 | |
47782 | COVER, DISC BRAKE DUST, FRONT LH | ||
47782-33040 | 1 |
طبق لکسوس ES350 مدل 2007-2008-2009
کمک جلو لکسوس ES350 مدل 2007-2008-2009
کمک عقب لکسوس ES350 مدل 2007-2008-2009
Register to remember your car(s) and to set your preferences.
©2017 ToyoDIY
رادیاتور آب و موتور فن لکسوس es350 مدل 2007-2009
ستون لکسوس ES مدل 2015
53821B | BRACKET, FRONT FENDER, REAR RH | ||
53821-48030 | 1 | ||
58747A | PROTECTOR, QUARTER PANEL, REAR RH | ||
58747-33071 | 1 | ||
61043A | EXTENSION SUB-ASSY, FRONT BODY PILLAR, OUTER RH | ||
Not applicable | |||
61101 | داخل ستون جلو راست | ||
61101-33151 | 1 | ||
61103A | REINFORCEMENT SUB-ASSY, COWL SIDE, RH | ||
61103-33070 | 1 | ||
61108A | REINFORCE SUB-ASSY, FRONT BODY PILLAR, LOWER RH | ||
61108-33909 | 1 | ||
61131C | PILLAR, FRONT BODY, OUTER RH | ||
61131-33091 | ستون جلو راست | 1 | |
61201 | RAIL SUB-ASSY, ROOF SIDE, RH | ||
61201-33905 | کلاف داخلی سقف راست | 1 | |
61203 | RAIL SUB-ASSY, ROOF SIDE, INNER RH | ||
61203-33070 | دوبل کلاف داخلی سقف راست | 1 | |
61213B | RAIL, ROOF SIDE, OUTER NO.2 RH | ||
61213-33110 | کلاف سقف راست | 1 | |
61303 | REINFORCE SUB-ASSY, CENTER BODY PILLAR, UPPER RH | ||
61303-33909 | ستون وسط داخلی راست | 1 | |
61305 | REINFORCE SUB-ASSY, CENTER BODY PILLAR, LOWER RH | ||
61305-33905 | داخل رکاب راست | 1 | |
61311B | PILLAR, CENTER BODY, OUTER RH | ||
61311-33080 | ستون وسط راست | 1 | |
61343A | PILLAR, CENTER BODY, INNER RH | ||
61307-33090 | دوبل داخلی ستون وسط راست | 1 | |
61403C | REINFORCE SUB-ASSY, ROCKER, OUTER RH | ||
61403-33030 | انتهای رکاب راست | 1 | |
61607H | PANEL SUB-ASSY, QUARTER WHEEL HOUSE, INNER RH | ||
61607-33070 | دوبل گلگیر عقب راست | 1 | |
61611 | PANEL, QUARTER, RH | ||
61611-33250 | گلگیر عقب راست | 1 | |
61625G | EXTENSION, QUARTER PANEL, REAR RH | ||
61625-33080 | 1 | ||
61631A | PANEL, QUARTER WHEEL HOUSE, OUTER RH | ||
61631-33110 | سینی پشت گلگیر عقب راست | 1 | |
61697D | HOUSING, QUARTER PANEL END, RH | ||
61601-33360 | انتهای گلگیر عقب راست | 1 | |
61711 | PANEL, ROOF SIDE, OUTER RH | ||
61711-33110 | 1 | ||
61731B | PANEL, ROOF SIDE, INNER RH | ||
61731-33140 | 1 | ||
61735A | PANEL, ROOF SIDE, INNER REAR RH | ||
61735-33110 | 1 | ||
62939A | SILENCER, QUARTER VENT | ||
62939-32020 | 2 | $11.94 | |
64213 | EXTENSION, PACKAGE TRAY STRAINER, RH | ||
64201-33080 | 1 | ||
65565 | PATCH, SIDE PANEL REAR END, RH | ||
65565-33030 | BLIND SPOT MONITOR-WITH & WITH(REAR CROSS TRAFFIC ALERT) | 1 | |
65637 | LINER, REAR WHEEL HOUSE, RH | ||
65637-33060 | شلگیر عقب راست | 1 | |
90159-60422 | *** STD. PART |
53822B | BRACKET, FRONT FENDER, REAR LH | ||
53821-48030 | 1 | ||
58748A | PROTECTOR, QUARTER PANEL, REAR LH | ||
58748-33071 | 1 | ||
61102 | PANEL SUB-ASSY, COWL SIDE, LH | ||
61102-33171 | دوبل داخل ستون جلو چپ | 1 | |
61104B | REINFORCEMENT SUB-ASSY, COWL SIDE, LH | ||
61104-33070 | 1 | ||
61109A | REINFORCE SUB-ASSY, FRONT BODY PILLAR, LOWER LH | ||
61109-33908 | داخل ستون جلو چپ | 1 | |
61132B | PILLAR, FRONT BODY, OUTER LH | ||
61132-33090 | ستون جلو چپ | 1 | |
61202 | RAIL SUB-ASSY, ROOF SIDE, LH | ||
61202-33905 | کلاف داخلی سقف چپ | 1 | |
61204 | RAIL SUB-ASSY, ROOF SIDE, INNER LH | ||
61204-33070 | دوبل کلاف داخلی سقف چپ | 1 | |
61214B | RAIL, ROOF SIDE, OUTER NO.2 LH | ||
61214-33110 | کلاف سقف چپ | 1 | |
61304 | REINFORCE SUB-ASSY, CENTER BODY PILLAR, UPPER LH | ||
61304-33907 | داخل ستون وسط چپ | 1 | |
61306 | REINFORCE SUB-ASSY, CENTER BODY PILLAR, LOWER LH | ||
61306-33903 | رکاب داخلی راست | 1 | |
61312B | PILLAR, CENTER BODY, OUTER LH | ||
61312-33080 | ستون وسط چپ | 1 | |
61344A | PILLAR, CENTER BODY, INNER LH | ||
61308-33090 | دوبل داخل ستون وسط چپ | 1 | |
61404E | REINFORCE SUB-ASSY, ROCKER, OUTER LH | ||
61404-33030 | انتهای رکاب داخلی چپ | 1 | |
61608H | PANEL SUB-ASSY, QUARTER WHEEL HOUSE, INNER LH | ||
61608-33070 | دوبل داخلی گلگیر عقب چپ | 1 | |
61612 | PANEL, QUARTER, LH | ||
61612-33150 | گلگیر عقب چپ | 1 | |
61626G | EXTENSION, QUARTER PANEL, REAR LH | ||
61626-33080 | 1 | ||
61632A | PANEL, QUARTER WHEEL HOUSE, OUTER LH | ||
61632-33110 | داخل گلگیر عقب چپ | 1 | |
61698D | HOUSING, QUARTER PANEL END, LH | ||
61602-33240 | 1 | ||
61712 | PANEL, ROOF SIDE, OUTER LH | ||
61712-33101 | 1 | ||
61732B | PANEL, ROOF SIDE, INNER LH | ||
61732-33131 | 1 | ||
61736A | PANEL, ROOF SIDE, INNER REAR LH | ||
61736-33110 | 1 | ||
62939A | SILENCER, QUARTER VENT | ||
62939-32020 | 2 | $11.94 | |
64214 | EXTENSION, PACKAGE TRAY STRAINER, LH | ||
64202-33080 | 1 | ||
65566 | PATCH, SIDE PANEL REAR END, LH | ||
65565-33030 | BLIND SPOT MONITOR-WITH & WITH(REAR CROSS TRAFFIC ALERT) | 1 | |
65638-33060 | شلگیر عقب چپ |
داشبورد لکسوس ES مدل 2015
55306A | BRACE SUB-ASSY, INSTRUMENT PANEL, NO.1 | ||
55306-33140 | 1 | ||
55307E | BRACE SUB-ASSY, INSTRUMENT PANEL, NO.2 | ||
55307-33170 | 1 | ||
55315A | SPACER, INSTRUMENT PANEL, NO.1 | ||
55315-48160 | 2 | ||
55317A | PANEL, INSTRUMENT SIDE, RH | ||
55317-33110-A0 | IVORY, TRIM0* | 1 | |
55317-33110-C0 | BLACK, TRIM1*, 2* | 1 | |
55318C | PANEL, INSTRUMENT SIDE, LH | ||
55318-33100-A0 | IVORY, TRIM0* | 1 | |
55318-33100-C0 | BLACK, TRIM1*, 2* | 1 | |
55321B | BRACKET, INSTRUMENT PANEL, NO.1 | ||
55321-33130 | 1 | ||
55322A | BRACKET, INSTRUMENT PANEL, NO.2 | ||
55322-33120 | 1 | ||
55328 | PIN, INSTRUMENT PANEL, NO.1 | ||
55328-60090 | 4 | ||
55330B | REINFORCEMENT ASSY, INSTRUMENT PANEL | ||
55330-33400 | 1 | ||
55394B | BOLT, INSTRUMENT PANEL | ||
90119-08C98 | 3 | ||
55394C | BOLT, INSTRUMENT PANEL | ||
90119-08C99 | 2 | ||
55401E | داشبورد | ||
55401-33180-C3 | BLACK/IVORY, TRIM0* | 1 | |
55401-33180-C4 | BLACK/BLACK, TRIM1*, 2* | 1 | |
55401F | CLIP(FOR SAFETY PAD) | ||
52161-16010 | 3 | $2.41 | |
55458A | CAP, INSTRUMENT PANEL SAFETY PAD | ||
55458-22110 | 5 | ||
55981 | GARNISH, DEFROSTER NOZZLE, NO.1 | ||
55981-33130-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
73960A | AIR BAG ASSY, INSTRUMENT PANEL PASSENGER W/O DOOR | ||
73960-33150 |
55054 | STOPPER SUB-ASSY, GLOVE COMPARTMENT DOOR | ||
55054-33090 | 1 | ||
55303B | PANEL SUB-ASSY, INSTRUMENT, LOWER | ||
55303-33240-A0 | IVORY, TRIM0* | 1 | |
55303-33240-C0 | BLACK, TRIM1*, 2* | 1 | |
55345A | CLIP, INSTRUMENT PANEL, NO.1 | ||
90467-13082-A0 | MELLOW WHITE | 4 | $1.19 |
55346A | CLIP, INSTRUMENT PANEL, NO.2 | ||
90467-13082-A0 | MELLOW WHITE | 4 | $1.19 |
55374C | BRACKET, INSTRUMENT PANEL LOWER MOUNTING, NO.1 | ||
55374-33170 | 1 | ||
55403F | PANEL SUB-ASSY, INSTRUMENT PANEL FINISH | ||
55403-33060-A0 | IVORY, TRIM0* | 1 | |
55403-33060-C0 | BLACK, TRIM1*, 2* | 1 | |
55404D | PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH | ||
55404-33150 | 1 | ||
55405B | PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH, CENTER | ||
55405-33270 | 1 | ||
55408F | PANEL SUB-ASSY, INSTRUMENT PANEL SPEAKER, NO.1 | ||
55408-33060-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
55408-33070-C0 | AUDIO-EMVN & DVD & MARK LEVINSON & 15SPEAKER, BLACK, TRIM0*, 1*, 2* | 1 | |
55409F | PANEL SUB-ASSY, INSTRUMENT PANEL SPEAKER, NO.2 | ||
55409-33060-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
55409-33070-C0 | AUDIO-EMVN & DVD & MARK LEVINSON & 15SPEAKER, BLACK, TRIM0*, 1*, 2* | 1 | |
55432D | PANEL, INSTRUMENT PANEL FINISH, LOWER NO.1 | ||
55302-33230-A0 | IVORY, TRIM0* | 1 | |
55302-33230-C0 | BLACK, TRIM1*, 2* | 1 | |
55434B | PANEL, INSTRUMENT PANEL FINISH, LOWER CENTER | ||
55434-33090-A0 | IVORY, TRIM0* | 1 | |
55434-33090-C0 | BLACK, TRIM1*, 2* | 1 | |
55443A | COVER, INSTRUMENT PANEL BOX DOOR | ||
55443-33180 | 1 | ||
55446A | BASE, SWITCH HOLE, NO.1 | ||
55446-33220-A0 | IVORY, TRIM0* | 1 | |
55446-33220-C0 | BLACK, TRIM1*, 2* | 1 | |
55449D | BASE, SWITCH | ||
55449-33060-A0 | IVORY, TRIM0* | 1 | |
55449-33060-C0 | BLACK, TRIM1*, 2* | 1 | |
55450B | BOX ASSY, COIN | ||
55450-33100-A0 | IVORY, TRIM0* | 1 | |
55450-33100-C0 | BLACK, TRIM1*, 2* | 1 | |
55459D | COVER, INSTRUMENT, LOWER LH | ||
55459-33050 | 1 | ||
55475B | GARNISH, INSTRUMENT CLUSTER FINISH PANEL, CENTER | ||
55475-33090 | 1 | ||
55475-33100 | DOOR TRIM ORNAMENT-WOOD(BIRDSEYE MAPLE & ILLUMINATION) | 1 | |
55475-33110 | DOOR TRIM ORNAMENT-WOOD(BAMBOO & ILLUMINATION) | 1 | |
55501A | DOOR SUB-ASSY, GLOVE COMPARTMENT | ||
55501-33180-A0 | IVORY, TRIM0* | 1 | |
55501-33180-C0 | BLACK, TRIM1*, 2* | 1 | |
55510F | COVER ASSY, SPEAKER OPENING, NO.1 | ||
55510-33040-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
55510-33050-C0 | AUDIO-EMVN & DVD & MARK LEVINSON & 15SPEAKER, BLACK, TRIM0*, 1*, 2* | 1 | |
55538 | RETAINER,GLOVE COMPARTMENT | ||
55567-33040 | 1 | ||
55539 | COVER, SPARE SWITCH HOLE | ||
55539-48020 | X | $5.42 | |
55539C | COVER, SPARE SWITCH HOLE | ||
55539-33130-A0 | IVORY, TRIM0* | X | |
55539-33130-C0 | BLACK, TRIM1*, 2* | X | |
55539E | COVER, SPARE SWITCH HOLE | ||
Not applicable | |||
55557A | CUSHION, GLOVE COMPARTMENT DOOR CHECK | ||
55557-60050 | 2 | ||
55560A | LOCK ASSY, GLOVE COMPARTMENT DOOR | ||
55560-33130-A0 | IVORY, TRIM0* | 1 | |
55560-33130-C0 | BLACK, TRIM1*, 2* | 1 | |
55568B | PLATE, GLOVE COMPARTMENT DOOR FINISH | ||
55568-33010-A0 | IVORY, TRIM0* | 1 | |
55568-33010-C0 | BLACK, TRIM1*, 2* | 1 | |
55569 | COVER, GLOVE COMPARTMENT DOOR LOCK | ||
55569-33030-A0 | IVORY, TRIM0* | 1 | |
55569-33030-C0 | BLACK, TRIM1*, 2* | 1 | |
55607 | COVER SUB-ASSY, INSTRUMENT PANEL UNDER, NO.2 | ||
55607-33140 | 1 | ||
55650 | REGISTER ASSY, INSTRUMENT PANEL, NO.1 | ||
55650-33220 | دریچه کولر سمت راننده | 1 | |
55650-33230 | DOOR TRIM ORNAMENT-WOOD(BIRDSEYE MAPLE & ILLUMINATION) | 1 | |
55650-33240 | DOOR TRIM ORNAMENT-WOOD(BAMBOO & ILLUMINATION) | 1 | |
55660 | REGISTER ASSY, INSTRUMENT PANEL, NO.2 | ||
55660-33230 | دریچه کولر وسط | 1 | |
55670 | REGISTER ASSY, INSTRUMENT PANEL, NO.3 | ||
55670-33230 | دریچه کولر سمت شاگرد | 1 | |
55961 | NOZZLE, SIDE DEFROSTER, NO.1 | ||
55961-33090-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
55962 | NOZZLE, SIDE DEFROSTER, NO.2 | ||
55962-33110-C0 | BLACK, TRIM0*, 1*, 2* | 1 | |
73900 | ایربگ زیر سمت راننده | ||
73900-33060-A0 | IVORY, TRIM0* | 1 | |
73900-33060-C0 | BLACK, TRIM1*, 2* | 1 | |
73990 | ایربگ | ||
73990-33020-A0 | IVORY, TRIM0* | 1 | |
73990-33020-C0 | BLACK, TRIM1*, 2* | 1 | |
90119-06951 | *** STD. PART |
شیشه جلو لکسوس ES مدل 2015
53383B | SEAL, HOOD TO COWL TOP | ||
53383-33100 | 1 | ||
53383D | CLIP(FOR HOOD TO COWL TOP SEAL) | ||
90467-09050 | 2 | $1.27 | |
55701 | PANEL SUB-ASSY, COWL | ||
55701-33190 | 1 | ||
55702A | PANEL SUB-ASSY, COWL TOP, OUTER FRONT | ||
55702-33100 | 1 | ||
55717A | PANEL, COWL TOP SIDE, INNER RH | ||
55717-33070 | 1 | ||
55718B | PANEL, COWL TOP SIDE, INNER LH | ||
55718-33070 | 1 | ||
55723C | REINFORCEMENT, COWL TOP SIDE, RH | ||
55723-33081 | 1 | ||
55724A | REINFORCEMENT, COWL TOP SIDE, LH | ||
55724-33090 | 1 | ||
55737B | SEAL, HEATER AIR DUCT SPLASH SHIELD, NO.1 | ||
55737-33010 | 1 | ||
55751B | HOSE, COWL WATER EXTRACT, NO.1 | ||
55751-33040 | 1 | ||
55765 | BRACKET, HOOD DAMPER MOUNTING | ||
55765-44010 | 2 | $7.79 | |
55781E | LOUVER SUB-ASSY, COWL TOP VENTILATOR | ||
55708-33190 | 1 | ||
55781G | CLIP, COWL TOP VENTILATOR LOUVER | ||
67867-12150 | 3 | $2.93 | |
55783A | PAD, COWL TOP SILENCER | ||
55783-33110 | 2 | ||
56111 | شیشه جلو | ||
56101-33959 | B PACKAGE&INTERMITTENT WIPER-WITH(RAIN SENSOR & TIME ADJUSTMENT) | 1 | |
56101-33960 | 1 | ||
56101-33965 | B PACKAGE&MOON ROOF-WITH(GLASS ROOF)&INTERMITTENT WIPER-WITH(RAIN SENSOR & TIME ADJUSTMENT) | 1 | |
56114 | RETAINER, WINDSHIELD GLASS | ||
56114-22050 | 2 | $5.77 | |
56115A | STOPPER, WINDSHIELD GLASS, NO.1 | ||
56115-30100 | 2 | $2.49 | |
56116C | STOPPER, WINDSHIELD GLASS, NO.2 | ||
56116-22050 | 2 | $2.41 | |
56117D | زه دور شیشه | ||
56117-50140 | *D, L=628, B PACKAGE & MOON ROOF-WITH(GLASS ROOF) & INTERMITTENT WIPER-WITH(RAIN SENSOR & TIME ADJUSTMENT) | 1 | $16.65 |
56117-64010 | *D, L=2914 | 1 | $16.09 |
56117E | DAM, WINDOW GLASS ADHESIVE | ||
56117-50140 | *D, L=628, MOON ROOF-WITH(GLASS ROOF) & INTERMITTENT WIPER-WITH(RAIN SENSOR & TIME ADJUSTMENT) | 1 | $16.65 |
75533G | MOULDING, WINDSHIELD, OUTSIDE | ||
75533-33100 | زه دور شیشه | 1 | |
75533-33110 | B PACKAGE&MOON ROOF-WITH(GLASS ROOF)&INTERMITTENT WIPER-WITH(RAIN SENSOR & TIME ADJUSTMENT) | 1 | |
90119-06786 | *** STD. PART |
سینی جلو لکسوس ES مدل 2015
51465 | BRACE, RADIATOR SUPPORT, UPPER RH | ||
51465-33060 | 1 | ||
51466 | BRACE, RADIATOR SUPPORT, UPPER LH | ||
51466-33070 | 1 | ||
52141H | ARM, FRONT BUMPER, UPPER RH | ||
52141-33120 | 1 | ||
52142J | ARM, FRONT BUMPER, UPPER LH | ||
52142-33100 | 1 | ||
53174E | BRACKET, RADIATOR SUPPORT SIDE | ||
53174-33010 | 1 | ||
53201 | SUPPORT SUB-ASSY, RADIATOR | ||
53201-33191 | 1 | سینی جلو | |
53202 | SUPPORT SUB-ASSY, RADIATOR, RH | ||
53202-33101 | 1 | ||
53203 | SUPPORT SUB-ASSY, RADIATOR, LH | ||
53203-33160 | 1 | ||
53208A | SUPPORT SUB-ASSY, HOOD LOCK | ||
53208-33060 | 1 | ||
53211 | SUPPORT, RADIATOR, RH | ||
53211-33081 | 1 | ||
53212 | SUPPORT, RADIATOR, LH | ||
53212-33081 | 1 | ||
53213A | SUPPORT, RADIATOR, UPPER RH | ||
53213-33061 | 1 | ||
53214A | SUPPORT, RADIATOR, UPPER LH | ||
53214-33060 | 1 | ||
53216A | SUPPORT, RADIATOR, UPPER | ||
53216-33150 | 1 | سینی بالای رادیاتور | |
53259C | CLIP, RADIATOR SUPPORT TO FRAME SEAL | ||
90467-07217 | 9 | ||
53293C | DEFLECTOR, RADIATOR SIDE, RH | ||
53293-33110 | 1 | سینی بغل رادیاتور راست | |
53294C | DEFLECTOR, RADIATOR SIDE, LH | ||
53294-33110 | 1 | سینی بغل رادیاتور چپ | |
53295E | SEAL, COOL AIR INTAKE DUCT | ||
53295-33090 | 1 | ||
53301G | CUSHION, HOOD BUMPER | ||
90541-15033 | 2 | $5.02 | |
53701 | APRON SUB-ASSY, FRONT FENDER, RH | ||
53701-33180 | 1 | پالونی گلگیر جلو راست | |
53702 | APRON SUB-ASSY, FRONT FENDER, LH | ||
53702-33140 | 1 | پالونی گلگیر جلو چپ | |
53707C | EXTENSION SUB-ASSY, FRONT FENDER APRON, FRONT RH | ||
53707-33010 | 1 | ||
53711B | APRON, FRONT FENDER, FRONT RH | ||
53711-33080 | 1 | ||
53712B | APRON, FRONT FENDER, FRONT LH | ||
53712-33050 | 1 | ||
53714C | EXTENSION, FRONT FENDER APRON, FRONT LH | ||
53714-33030 | 1 | ||
53725D | REINFORCEMENT, FRONT SPRING SUPPORT, NO.2 RH | ||
53725-33020 | 1 | ||
53726B | REINFORCEMENT, FRONT SPRING SUPPORT, NO.2 LH | ||
53726-33020 | 1 | ||
53731D | MEMBER, FRONT APRON TO COWL SIDE, UPPER RH | ||
53731-33090 | 1 | ||
53732D | MEMBER, FRONT APRON TO COWL SIDE, UPPER LH | ||
53732-33080 | 1 | ||
53733D | MEMBER, FRONT APRON TO COWL SIDE, LOWER FRONT RH | ||
53733-33050 | 1 | ||
53734C | MEMBER, FRONT APRON TO COWL SIDE, LOWER FRONT LH | ||
53734-33050 | 1 | ||
53736 | SEAL, FRONT FENDER APRON, RH | ||
53736-33040 | 1 | $58.16 | |
53736A | CLIP(FOR FRONT FENDER APRON SEAL) | ||
90467-08180 | 2 | $2.21 | |
53737B | SEAL, FRONT FENDER APRON, LH | ||
53737-33020 | 1 | $46.85 | |
53821G | BRACKET, FRONT FENDER, REAR RH | ||
53821-33060 | 1 | ||
53822F | BRACKET, FRONT FENDER, REAR LH | ||
53822-33050 | 1 | ||
53823H | GUSET, FRONT FENDER, RH | ||
53823-33040 | 1 | ||
53824E | GUSSET, FRONT FENDER, LH | ||
53824-33040 | 1 | ||
55101 | PANEL SUB-ASSY, DASH | ||
55101-33441 | 1 | ||
55210 | INSULATOR ASSY, DASH PANEL | ||
55210-33250 | 1 | ||
55210A | CLIP | ||
90467-11127 | 2 | $1.94 | |
55210C | CLIP | ||
90467-13079 | 2 | $1.30 | |
55223A | INSULATOR, DASH PANEL, OUTER | ||
55223-33190 | 1 | ||
55239A | PLATE, DASH PANEL INSULATOR, NO.3 | ||
55239-33020 | 2 | $9.17 | |
57104D | MEMBER SUB-ASSY, FRONT CROSS | ||
57104-33061 | 1 | سینی زیر رادیات | |
57163A | REINFORCEMENT, FRONT CROSSMEMBER, NO.1 RH | ||
57163-33040 | 1 | $53.65 | |
57164A | REINFORCEMENT, FRONT CROSSMEMBER, NO.1 LH | ||
57164-33040 | 1 | $55.71 | |
57165F | REINFORCEMENT, FRONT CROSSMEMBER, NO.2 RH | ||
57165-33021 | 1 | ||
57166E | REINFORCEMENT, FRONT CROSSMEMBER, NO.2 LH |
جک و لولای کاپوت لکسوس ES مدل 2015
53410 | HINGE ASSY, HOOD, RH | ||
53410-33290 | لولای کاپوت راست | 1 | |
53420 | HINGE ASSY, HOOD, LH | ||
53420-33290 | لولای کاپوت چپ | 1 | |
53440A | SUPPORT ASSY, HOOD, RH | ||
53440-33100 | جک کاپوت راست | 1 | |
53450A | SUPPORT ASSY, HOOD, LH | ||
53450-33090 | جک کاپوت چپ | 1 | |
53497 | PAD, HOOD HINGE, NO.1 | ||
53497-20070 | T=2.0 | 4 | $2.77 |
53497-42010 | T=0.5 | 4 | $1.62 |
53510 | LOCK ASSY, HOOD | ||
53510-33400 | قفل کاپوت | 1 | |
53510A | SPRING, TENSION(FOR HOOD LOCK) | ||
90506-09055 | WD=0.9, CW=21 | 1 | $2.10 |
53510D | SPRING, TENSION(FOR HOOD LOCK) | ||
90506-12063 | WD=1.2, CW=8.5 | 1 | $2.10 |
53510E | SPRING, TENSION(FOR HOOD LOCK) | ||
90506-18067 | WD=1.8, CW=13 | 1 | $2.13 |
53601 | اهرم قفل کاپوت از داخل | ||
53601-30090-A0 | IVORY, TRIM0* | 1 | |
53601-30090-C0 | BLACK, TRIM1*, 2* | 1 | |
53614 | CLAMP, HOOD LOCK CONTROL CABLE | ||
90959-01369 | 2 | $2.33 | |
53630 | CABLE ASSY, HOOD LOCK CONTROL | ||
53630-33180 | سیم کاپوت | 1 | |
53630B | CLAMP(FOR HOOD LOCK CONTROL CABLE) | ||
90467-12009 | 1 | $4.27 | |
90119-06939 | *** STD. PART |
