19100P | شمع موتور کمری هیبرید و NX300 | ||
90919-01259 | FK16HR-A8, *107 | 4 | |
19500 | کویل کمری هیبرید و NX300 | ||
90919-02256 | *107 | 4 | |
90105-A0103 | *** STD. PART | $0.71 | |
91551-80625 | *** STD. PART | $0.75 | |
91551-A0625 | *** STD. PART | $0.75 |
![شمع کمری هیبرید](https://toyotacar-co.com/wp-content/uploads/2023/01/90919-01259TOYOTACAR.png)
25601 | PIPE SUB-ASSY, EGR, NO.1 | ||
25611-20040 | لوله EGR | 1 | $127.15 |
25602 | PIPE SUB-ASSY, EGR, NO.2 | ||
25612-20030 | لوله EGR | 1 | $81.45 |
25620 | VALVE ASSY, EGR | ||
25620-20020 | سوپاپ ورودی EGR | 1 | $353.07 |
25627 | GASKET, EGR VALVE | ||
25627-20010 | (J) | 1 | $1.23 |
25627C | GASKET(FOR EGR PIPE NO.2) | ||
25627-20010 | (J) | 2 | $1.23 |
25628 | GASKET, EGR INLET | ||
25628-20010 | (J) | 2 | $6.48 |
25681 | COOLER, EGR, NO.1 | ||
25681-20020 | خنک کن EGR | 1 | $274.19 |
25685 | GASKET, EGR COOLER, NO.1 | ||
25685-20010 | (J) | 1 | $14.67 |
25691 | BRACKET, EGR VACUUM MODULATOR | ||
25691-20030 | 1 | $6.33 |
21821-25180 | *** STD. PART | $1.30 | |
22210 | BODY ASSY, THROTTLE | ||
22210-20120 | دریچه گاز | 1 | $1,254.39 |
22215A | GASKET, IDLE SPEED CONTROL VALVE | ||
22215-20010 | واشر پایه دریچه سوخت | 1 | $4.55 |
22270 | VALVE ASSY, IDLE SPEED CONTROL(FOR THLOTTLE BODY) | ||
22270-20040 | استپر موتور | 1 | $440.32 |
22271 | GASKET, THROTTLE BODY | ||
22271-20010 | واشر دریچه گاز | 1 | $6.68 |
23232 | GASKET(FOR FUEL PUMP HOSE) | ||
23232-41081 | 2 | $2.21 | |
23250 | INJECTOR ASSY, FUEL | ||
23209-20010 | سوزن انزکتور | 6 | $288.74 |
23250B | RING, O(FOR FUEL INJECTOR) | ||
90301-07024 | 12 | $3.01 | |
23250C | GROMMET(FOR FUEL INJECTOR) | ||
90480-13005 | 6 | $3.80 | |
23270 | DAMPER ASSY, FUEL PRESSURE PULSATION | ||
23270-62011 | فشار شکن سوخت | 1 | $104.30 |
23291 | INSULATOR, INJECTOR VIBRATION | ||
23291-62010 | اورینگ سوزن انژکتور | 6 | $2.73 |
23801P | PIPE SUB-ASSY, FUEL, NO.1 | ||
23801-20160 | 1 | $60.81 | |
23802C | BOLT, UNION(FOR FUEL PIPE NO.2) | ||
90401-12015 | 1 | $2.89 | |
23802D | GASKET(FOR FUEL PIPE NO.2) | ||
90430-12026 | 2 | $1.15 | |
23807 | PIPE SUB-ASSY, FUEL DELIVERY | ||
23814-20021 | ریل سوخت | 1 | $66.94 |
23807V | SPACER, NO.1(FOR DELIVERY PIPE) | ||
90561-08020 | 4 | $3.68 | |
23815 | PIPE, FUEL DELIVERY, NO.2 | ||
23815-20021 | ریل سوخت | 1 | $66.94 |
23841B | CLAMP, FUEL PIPE, NO.1(FOR EFI) | ||
23841-28010 | 1 | $2.81 |
28011 | CLUTCH SUB-ASSY, STARTER | ||
28011-74070 | دنده استارت | 1 | $45.72 |
28100 | استارت | ||
28100-74260 | 12V 1.4KW | 1 | $511.01 |
28120 | YOKE ASSY, STARTER | ||
28120-66040 | بالشتک استارت | 1 | $238.01 |
28140 | HOLDER ASSY, STARTER BRUSH | ||
28140-74070 | زغال استارت | 1 | $26.92 |
28150 | SWITCH ASSY, MAGNET STARTER | ||
28150-74270 | اتوماتیک استارت | 1 | $107.44 |
28160 | ARMATURE ASSY, STARTER | ||
28160-74070 | آرمیچر استارت | 1 | $93.19 |
27020 | دینام | ||
27060-20260 | 12V 80A | 1 | $768.73 |
27330 | ROTOR ASSY, ALTERNATOR | ||
27330-74550 | آرمیچر دینام | 1 | $253.83 |
27357 | HOLDER, ALTERNATOR, W/RECTIFIER | ||
27357-22050 | دیود دینام | 1 | $106.79 |
27370 | HOLDER ASSY, ALTERNATOR BRUSH | ||
27370-75060 | زغال دینام | 1 | $24.67 |
27411 | PULLEY, ALTERNATOR | ||
27411-46080 | پولی دینام | 1 | $24.63 |
27700A | REGULATOR ASSY, GENERATOR | ||
27700-20050 | آفتامات دینام | 1 | $211.22 |
90179-06158 | *** STD. PART | $1.34 |
11265 | COVER, COIL & RESISTIVE CORD, UPR | ||
11265-20020 | قاب روی وایر | 1 | $31.63 |
19100P | شمع موتور | ||
90919-01194 | PK20TR11 | 6 | $18.34 |
90919-01195 | BKR6EKPB11 | 6 | $19.98 |
19500 | COIL ASSY, IGNITION | ||
90919-02215 | کویل | 3 | $186.66 |
19539 | HOLDER, RESISTIVE CODE, NO.4 | ||
19539-11040 | 3 | $5.18 | |
19901 | CORD SET, COIL & SPARK, W/RESISTIVE | ||
19037-20011 | مجموعه کامل وایر شمع | 1 | $72.82 |
19901B | CORD, SPARK PLUG RESISTIVE, NO.1 | ||
90919-15308 | وایر شمع شماره 1 | 1 | $23.84 |
19901C | CORD, SPARK PLUG RESISTIVE, NO.2 | ||
90919-15309 | وایر شمع شماره 2 | 1 | $24.42 |
19901D | CORD, SPARK PLUG RESISTIVE, NO.3 | ||
90919-15310 | وایر شمع شماره 3 | 1 | $25.85 |
19941 | CLAMP, RESISTIVE CORD, NO.1 | ||
19941-20010 | NO.1 | 1 | $1.19 |
19941-20020 | NO.2 | 1 | $5.46 |
19941A | CLAMP(FOR RESISTIVE CORD) | ||
19941-65040 | 1 | $4.27 | |
19942 | CLAMP, RESISTIVE CORD, NO.2 | ||
19942-20010 | 1 | $1.19 | |
19946 | CLAMP, RESISTIVE CORD, NO.3 | ||
19946-20010 | 1 | $7.55 | |
19947 | CLAMP, RESISTIVE CORD, NO.4 | ||
19947-20010 | 1 | $1.19 |
17303B | PIPE SUB-ASSY, AIR, NO.1 | ||
17303-20010 | (J) | 1 | $10.99 |
17308B | HOSE SUB-ASSY, VACUUM | ||
17308-0A030 | 1 | ||
17345D | HOSE, AIR, NO.5 | ||
17345-20010 | (J) | 1 | $14.91 |
17345E | CLAMP OR CLIP(FOR AIR HOSE, NO.5) | ||
96133-41500 | 2 | $3.87 | |
17346B | HOSE, AIR, NO.6 | ||
17346-20010 | (J) | 1 | $11.43 |
17346E | CLIP(FOR AIR HOSE NO.6) | ||
96132-51300 | 2 | $2.13 | |
17347B | HOSE, AIR, NO.7 | ||
17347-20010 | (J) | 1 | $11.43 |
17347E | CLIP(FOR AIR HOSE NO.7) | ||
96132-51300 | 2 | $2.13 | |
17650G | VALVE, DUTY VACUUM SWITCHING | ||
90910-12241 | 1 | $115.09 | |
23275A | VALVE, VACUUM CONTROL | ||
90925-03193 | 1 | $74.37 | |
23826 | HOSE, FUEL VAPOR FEED, NO.1 | ||
23826-0A070 | (L) | 1 | |
23826-20050 | (J) | 1 | $28.31 |
23826A | CLIP(FOR FUEL VAPOR FEED HOSE, NO.1) | ||
90466-11003 | 2 | $2.65 | |
23827D | HOSE, FUEL VAPOR FEED, NO.2 | ||
23827-20070 | 1 | $27.40 | |
25701 | VALVE SET, EMISSION CONTROL | ||
25701-20210 | 1 | $257.15 | |
25760 | HOSE ASSY, VACUUM TRANSMITTING | ||
25760-20030 | 1 | $42.42 | |
25860 | VALVE ASSY, VACUUM SWITCHING, NO.1 | ||
25860-62010 | 1 | $81.88 | |
25860A | VALVE, VACUUM SWITCHING, NO.1 | ||
90910-12174 | 1 | $99.71 |
17104 | MANIFOLD SUB-ASSY, EXHAUST, RH | ||
17141-20050 | منیفولد اگزوز دود سمت راست | 1 | $271.83 |
17105 | MANIFOLD SUB-ASSY, EXHAUST, LH | ||
17142-20050 | منیفولد اگزوز دود سمت چپ | 1 | $271.83 |
17111 | MANIFOLD, INTAKE | ||
17101-20010 | منیفولد هوا | 1 | $523.32 |
17118 | STAY, MANIFOLD | ||
17118-20020 | 1 | $7.47 | |
17125 | STAY, SURGE TANK, NO.1 | ||
17125-20010 | (J) | 1 | $30.29 |
17127 | GASKET, SURGE TANK COVER | ||
17127-62030 | (J) | 1 | $6.13 |
17129 | TANK, INTAKE AIR SURGE | ||
17109-20090 | مخزن ورودی هوا | 1 | $481.88 |
17139 | STAY, MANIFOLD, NO.2 | ||
17139-20010 | 1 | $11.23 | |
17152 | BOLT, STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||
90116-10149 | 2 | $2.13 | |
17152A | BOLT,STUD(FOR MANIFOLD TO EXHAUST PIPE) | ||
90116-10149 | 2 | $2.13 | |
17159 | BOLT, STUD(FOR MANIFOLD TO CYLINDER HEAD) | ||
90126-08013 | NO.2 | 4 | $3.48 |
90126-10030 | NO.1 | 12 | $1.50 |
17167 | INSULATOR, EXHAUST MANIFOLD HEAT, NO.1 | ||
17167-20050 | عایق حرارت گیر منیفولد دود | 1 | $59.03 |
17168 | INSULATOR, EXHAUST MANIFOLD HEAT, NO.2 | ||
17168-20050 | عایق حرارات گیر منیفولد دود | 1 | $44.48 |
17173 | GASKET, EXHAUST MANIFOLD TO HEAD | ||
17173-20010 | واشر منیفولد دود | 1 | $28.00 |
17173A | GASKET, EXHAUST MANIFOLD TO HEAD, LH | ||
17173-20010 | واشر منیفولد دود سمت چپ | 1 | $28.00 |
17176 | GASKET, AIR SURGE TANK TO INTAKE MANIFOLD | ||
17176-62030 | واشر منیفولد مخزن ورودی هوا | 1 | $10.74 |
17177 | GASKET, INTAKE MANIFOLD TO HEAD, NO.1 | ||
17177-20020 | واشر منیفولد هوا | 1 | $33.26 |
17178 | GASKET, INTAKE MANIFOLD TO HEAD, NO.2 | ||
17178-20020 | واشر منیفولد هوا | 1 | $31.90 |
17300 | VALVE ASSY, INTAKE AIR CONTROL | ||
17300-20020 | سوپاپ ورودی هوا | 1 | $283.76 |
17300A | PLUG, W/HEAD TAPER SCREW(FOR AIR CONTROL VALVE) | ||
90345-51006 | 1 | $1.23 | |
17315A | GASKET, INTAKE AIR CONTROL VALVE | ||
17315-62020 | 1 | $5.02 |
16361A | BELT, V(FOR FAN & ALTERNATOR) | ||
Not applicable | |||
44310A | تسمه هیدرولیک | ||
90080-91228 | L=880, (L) | 1 | |
90916-02580 | L=880, (J) | 1 | $37.40 |
88310A | تسمه دینام | ||
90089-91007 | L=1035 | 1 | |
16361 | FAN | ||
16361-0A161 | پروانه فن چپ | 1 | $81.52 |
16361B | FAN, NO.2 | ||
16361-0A171 | پروانه فن سمت راست | 1 | $104.61 |
16363 | MOTOR, COOLING FAN | ||
16363-0A190 | موتور فن چپ | 1 | |
16363A | MOTOR, COOLING FAN, NO.2 | ||
16363-0A200 | موتور فن راست | 1 | |
16400 | رادیاتور آب | ||
16400-0A370 | MARK 16400-0A370 | 1 | |
16400B | PLUG, RADIATOR DRAIN COCK | ||
23322-54010 | شیر تخلیه آب رادیات | 1 | $7.51 |
16400F | PACKING(FOR RADIATOR DRAIN COCK) | ||
16492-21050 | 1 | $3.24 | |
16470 | TANK ASSY, RADIATOR RESERVE | ||
16470-0H040 | مخزن ذخیره آب رادیات | 1 | $95.56 |
16470A | HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||
16472-0A050 | شلنگ مخزن ذخیره آب | 1 | |
16470B | CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||
90467-11085 | 2 | $0.91 | |
16471 | CAP SUB-ASSY, RESERVE TANK | ||
16471-03020 | درب مخزن ذخیره آب | 1 | |
16523A | CUSHION, RADIATOR SUPPORT | ||
16523-03020 | 2 | ||
16533 | SUPPORT, RADIATOR, UPPER | ||
16533-0H020 | 2 | ||
16535 | SUPPORT, RADIATOR, LOWER | ||
16535-0A040 | 2 | ||
16571 | HOSE, RADIATOR, INLET | ||
16571-0A060 | شلنگ بالای رادیاتور | 1 | |
16571A | CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||
90467-37005 | 2 | $6.01 | |
16572 | HOSE, RADIATOR, OUTLET | ||
16572-0A060 | شلنگ پایین رادیات | 1 | |
16572A | CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||
90467-37005 | 2 | $6.01 | |
16611 | BRACKET, RADIATOR RESERVE TANK | ||
16611-03040 | 1 | ||
16701 | SHROUD SUB-ASSY, FAN | ||
16711-0A190 | بادگیر رادیاتور | 1 |
16261G | HOSE, WATER BY-PASS, NO.1 | ||
16261-20010 | (J) | 1 | $22.77 |
16261H | CLIP(FOR WATER BY-PASS HOSE NO.1) | ||
90467-28007 | 2 | $4.51 | |
16264 | HOSE, WATER BY-PASS, NO.2 | ||
16264-20010 | (J) | 1 | $17.83 |
16264A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||
96135-51300 | (08/2002 – 04/2004) | 2 | $3.20 |
96137-41501 | (05/2004 – 07/2004) | 2 | $3.16 |
16267 | HOSE, WATER BY-PASS, NO.3 | ||
16267-20010 | (J) | 1 | $17.83 |
16267A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.3) | ||
96135-51300 | (08/2002 – 04/2004) | 2 | $3.20 |
96137-41501 | (05/2004 – 07/2004) | 2 | $3.16 |
16321 | INLET, WATER | ||
16321-20010 | (J) | 1 | $91.41 |
16322 | PIPE, WATER INLET | ||
16322-20020 | (J) | 1 | $42.42 |
16322A | RING, O(FOR WATER INLET) | ||
96761-35031 | 1 | $3.62 | |
16323 | HOUSING, WATER INLET | ||
16323-20010 | (J) | 1 | $159.53 |
16325 | GASKET, WATER INLET HOUSING, NO.1 | ||
16325-62010 | 1 | $6.37 | |
16331 | OUTLET, WATER | ||
16331-20070 | 1 | $114.70 | |
16331A | ترموستات | ||
90916-03084 | WAX TYPE (OPENING TEMPERATURE – FULLY OPEN TEMPERATURE) 82-95 (08/2002 – 07/2004) | 1 | $41.74 |
90916-03129 | WAX TYPE (OPENING TEMPERATURE – FULLY OPEN TEMPERATURE) 82-95 (09/2004 – ) | 1 | $41.60 |
16331F | CAP SUB-ASSY(FOR WATER OUTLET) | ||
16401-62090 | 1 | $27.56 | |
16384 | BRACKET, FAN BELT ADJUSTING BAR | ||
16384-20020 | 1 | $14.11 |
16100 | PUMP ASSY, ENGINE WATER | ||
16100-29085 | واتر پمپ | 1 | $168.94 |
16100G | BOLT, STUD(FOR WATER PUMP SET) | ||
90116-06144 | 3 | $0.91 | |
16271 | GASKET, WATER PUMP | ||
16271-20020 | واشر واتر پمپ | 1 | $9.96 |
11324A | PLATE, TIMING BELT | ||
11324-20010 | اویل پمپ | 1 | $1.70 |
15100 | PUMP ASSY, OIL | ||
15100-20020 | (J) | 1 | $184.62 |
15100C | SEAL(FOR OIL PUMP) | ||
90311-40022 | کاسه نمد سر میل لنگ | 1 | $10.64 |
15100R | SENSOR, CRANK POSITION | ||
90919-05012 | سنسور موقعیت میل لنگ | 1 | $123.43 |
15101 | BODY SUB-ASSY, OIL PUMP | ||
Not applicable | |||
15102 | ROTOR SET, OIL PUMP | ||
Not applicable | |||
15104 | STRAINER SUB-ASSY, OIL | ||
15104-20020 | توری اویل پمپ | 1 | $49.46 |
15104C | GASKET(FOR OIL STRAINER) | ||
15147-20010 | (J) | 1 | $3.12 |
15115 | COVER, OIL PUMP | ||
Not applicable | |||
15131 | VALVE, OIL PUMP RELIEF | ||
15131-42021 | 1 | $4.35 | |
15132 | SPRING, OIL PUMP RELIEF VALVE | ||
15132-20020 | (J) | 1 | $2.13 |
15133 | PLUG, OIL PUMP RELIEF VALVE | ||
15133-20010 | 1 | $4.11 | |
15134 | GASKET, OIL PUMP RELIEF VALVE | ||
15134-67010 | 1 | $2.57 |
13053 | CAMSHAFT SUB-ASSY, NO.3 | ||
13053-20010 | میل سوپاپ | 1 | $311.60 |
13054 | CAMSHAFT SUB-ASSY, NO.4 | ||
13054-20010 | میل سوپاپ | 1 | $311.60 |
13502 | IDLER SUB-ASSY, TIMING BELT, NO.2 | ||
13503-62030 | پولی هرزگرد تسمه تایم | 1 | $100.58 |
13505 | IDLER SUB-ASSY, TIMING BELT, NO.1 | ||
13505-20010 | هرزگرد تسمه تایم | 1 | $112.60 |
13511 | CAMSHAFT | ||
13501-20020 | میل سوپاپ | 1 | $311.60 |
13512 | CAMSHAFT, NO.2 | ||
13502-20010 | میل سوپاپ | 1 | $311.60 |
13515A | WASHER, PLATE(FOR DISTRIBUTOR DRIVE GEAR) | ||
90201-10098 | 1 | $2.13 | |
13523P | PULLEY, CAMSHAFT TIMING | ||
13523-20020 | پولی تسمه تایم | 2 | $40.64 |
13529 | GEAR, CAMSHAFT SUB | ||
13529-20900 | دهده سر میل سوپاپ | 1 | $44.08 |
13529A | WASHER, WAVE(FOR CAMSHAFT SUB GEAR) | ||
90206-42001 | 1 | $1.34 | |
13529B | RING, SHAFT SNAP(FOR CAMSHAFT SUB GEAR) | ||
90520-41004 | 1 | $3.68 | |
13529C | GEAR, CAMSHAFT SUB, NO.3 | ||
13529-20900 | دنده سر میل سوپاپ | 1 | $44.08 |
13529D | WASHER, WAVE(FOR CAMSHAFT SUB GEAR, NO.3) | ||
90206-42001 | 1 | $1.34 | |
13529E | RING, SHAFT SNAP(FOR CAMSHAFT SUB GEAR, NO.3) | ||
90520-41004 | 1 | $3.68 | |
13540 | TENSIONER ASSY, CHAIN, NO.1 | ||
13540-20021 | سفت کن تسمه تایم | 1 | $83.11 |
13553 | COVER, CHAIN TENSIONER DUST | ||
13553-20010 | TYPE A:REFER TO ILLUSTRATION | 1 | $1.30 |
13553-62020 | TYPE B:REFER TO ILLUSTRATION | 1 | $4.74 |
13556 | SHAFT, TIMING BELT IDLER | ||
13556-62010 | 1 | $15.22 | |
13568 | BELT, TIMING | ||
13568-29025 | تسمه تایم | 1 | $67.67 |
13579 | WASHER, CAMSHAFT TIMING GEAR BOLT | ||
13579-50020 | (08/2004 – ) | 1 | $6.76 |
13579-62010 | (08/2002 – 07/2004) | 1 | $27.04 |
13579A | WASHER, CAMSHAFT TIMING GEAR BOLT, NO.3 | ||
13579-50020 | (08/2004 – ) | 1 | $6.76 |
13579-62010 | (08/2002 – 07/2004) | 1 | $27.04 |
13584 | BRACKET, TIMING BELT IDLER | ||
13584-20011 | 1 | $38.59 | |
13711 | VALVE, INTAKE | ||
13711-20020 | سوپاپ هوا | 12 | $27.17 |
13711A | لاستیک سوپاپ | ||
90913-02101 | NO.2, (J) | 12 | $9.61 |
90913-02112 | NO.1, (J) | 12 | $9.61 |
13711B | SPRING, COMPRESSION(FOR INNER) | ||
90501-31010 | فنر سوپاپ | 24 | $6.84 |
13715 | VALVE, EXHAUST | ||
13715-20020 | سوپاپ دود | 12 | $68.70 |
13734 | SEAT, VALVE SPRING | ||
13734-20010 | 24 | $0.87 | |
13741 | RETAINER, VALVE SPRING | ||
13741-20020 | (08/2002 – 07/2004) | 24 | $3.04 |
13741-20021 | (06/2005 – ) | 24 | $2.97 |
13741A | LOCK, VALVE SPRING RETAINER | ||
90913-03028 | 48 | $1.34 | |
13751 | LIFTER, VALVE | ||
13751-46740 | استکان تایپیت | 24 | $19.69 |
11011 | WASHER SET, CRANKSHAFT THRUST | ||
11011-20020 | بغل یاتاقان | 1 | $42.42 |
11711 | BEARING, CRANKSHAFT | ||
11071-20020 | یاتاقان ثابت | 2 | |
11071-20020-01 | MARK 1, NO.2, (J):REFER R/M | 2 | $20.31 |
11071-20020-02 | MARK 2, NO.2, (J):REFER R/M | 2 | $20.31 |
11071-20020-04 | MARK 4, NO.2, (J):REFER R/M | 2 | $20.31 |
11071-20020-05 | MARK 5, NO.2, (J):REFER R/M | 2 | $20.31 |
11071-20020-06 | MARK 6, NO.2, (J):REFER R/M | 2 | $20.28 |
11071-20020-07 | MARK 7, NO.2, (J):REFER R/M | 2 | $20.28 |
11071-20021-01 | MARK1, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-02 | MARK2, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-03 | MARK3, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-04 | MARK4, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-05 | MARK5, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-06 | MARK6, NO.2, REFER R/M | 2 | $24.40 |
11071-20021-07 | MARK7, NO.2, REFER R/M | 2 | $24.40 |
11701-20020 | یاتاقان ثابت | 2 | |
11701-20020-01 | MARK 1, NO.1, (J):REFER R/M | 2 | $23.05 |
11701-20020-02 | MARK 2, NO.1, (J):REFER R/M | 2 | $23.05 |
11701-20020-03 | MARK 3, NO.1, (J):REFER R/M | 2 | $23.08 |
11701-20020-04 | MARK 4, NO.1, (J):REFER R/M | 2 | $23.08 |
11701-20020-05 | MARK 5, NO.1, (J):REFER R/M | 2 | $23.08 |
11701-20020-06 | MARK 6, NO.1, (J):REFER R/M | 2 | $23.08 |
11701-20020-07 | MARK 7, NO.1, (J):REFER R/M | 2 | $23.08 |
11701-20030-01 | MARK1, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-02 | MARK2, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-03 | MARK3, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-04 | MARK4, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-05 | MARK5, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-06 | MARK6, NO.1, REFER R/M | 2 | $26.00 |
11701-20030-07 | MARK7, NO.1, REFER R/M | 2 | $26.00 |
13011 | رینگ موتور | ||
13011-20023 | STD, ENGINE NO.=0XXXXXX-4XXXXXX | 1 | $302.19 |
13041 | BEARING, CONNECTING ROD | ||
13041-20010 | یاتاقان متحرک | 6 | |
13041-20010-01 | REFER TO REPAIR MANUAL, MARK 1 | 6 | $17.36 |
13041-20010-02 | REFER TO REPAIR MANUAL, MARK 2 | 6 | $17.36 |
13041-20010-03 | REFER TO REPAIR MANUAL, MARK 3 | 6 | $17.36 |
13041-20010-04 | REFER TO REPAIR MANUAL, MARK 4 | 6 | $17.36 |
13041-20011-01 | MARK1 | 6 | $19.05 |
13041-20011-02 | MARK2 | 6 | $19.05 |
13041-20011-03 | MARK3 | 6 | $19.05 |
13041-20011-04 | MARK4 | 6 | $19.05 |
13101 | پیستون | ||
13101-20041 | STD, ENGINE NO.=0XXXXXX-47XXXXX, RH | 3 | $95.41 |
13301-20031 | STD, ENGINE NO.=0XXXXXX-47XXXXX, LH | 3 | $95.41 |
13101A | RING, HOLE SNAP(FOR PISTON PIN) | ||
90520-22025 | 12 | $2.89 | |
13201 | شاطون | ||
13201-29165 | (08/2004 – 11/2004) | 6 | $174.17 |
13201-29525 | (12/2003 – 07/2004) | 6 | $174.17 |
13201A | BUSH(FOR CONNECTING ROD SMALL END) | ||
90999-73119 | 6 | $12.49 | |
13265 | BOLT, CONNECTING ROD | ||
13265-28010 | پیچ شاطون | 12 | $4.35 |
13405 | FLYWHEEL SUB-ASSY | ||
Not applicable | |||
13405A | PIN, STRAIGHT(FOR FLYWHEEL) | ||
Not applicable | |||
13405B | BOLT, FLYWHEEL SETTING | ||
Not applicable | |||
13411 | CRANKSHAFT | ||
13401-20030 | میل لنگ | 1 | $1,412.02 |
13453 | GEAR, FLYWHEEL RING | ||
Not applicable | |||
13471 | پولی میل لنگ | ||
13408-0A010 | (L) | 1 | $334.01 |
13408-20010 | (J) | 1 | $334.01 |
13471A | KEY, CRANKSHAFT(FOR CRANKSHAFT PULLEY SET) | ||
95161-30516 | 2 | $1.46 | |
13471C | BOLT(FOR CRANKSHAFT PULLEY SET) | ||
90119-16004 | 1 | $7.83 | |
13521P | PULLEY, CRANKSHAFT TIMING | ||
13521-20020 | دنده سر میل لنگ | 1 | $57.76 |
13567 | GUIDE, TIMING BELT, NO.2 | ||
13567-62010 | 1 | $4.39 |
12204 | شیر درب سوپاپ | ||
12204-20040 | TYPE B:REFER TO ILLUSTRATION (08/2002 – 07/2004) | 1 | $17.51 |
12204-20060 | TYPE B:REFER TO ILLUSTRATION (12/2004 – 12/2004) | 1 | $21.94 |
12204A | GROMMET(FOR VENTILATION SYSTEM) | ||
Not applicable | |||
12261 | لوله هواگیری | ||
12261-20011 | (08/2002 – 07/2004) | 1 | $12.34 |
12261-20090 | (12/2004 – 08/2005) | 1 | $14.00 |
12261-20091 | (09/2005 – ) | 1 | $13.96 |
12261A | CLIP OR CLAMP(FOR VENTILATION HOSE) | ||
90467-14017 | بست | 2 | $1.38 |
12262 | HOSE, VENTILATION, NO.2 | ||
12262-20020 | لوله هواگیری | 1 | $17.36 |
12262A | بست | ||
96134-41900 | NO.2 | 1 | $2.33 |
96134-51700 | NO.1 | 1 | $2.61 |
12307 | ABSORBER SUB-ASSY, ENGINE MOUNTING | ||
12307-20021 | کمک موتور | 1 | $139.61 |
12311A | BRACKET, ENGINE MOUNTING, FRONT(FOR TRANSVERSE ENGINE) | ||
12311-0A030 | پایه دسته موتور جلو | 1 | |
12313 | پایه دسته موتور بالا راست | ||
12313-0A020 | (L) | 1 | $54.84 |
12313-20020 | (J) | 1 | $54.84 |
12315A | BRACKET, ENGINE MOUNTING, RH(FOR TRANSVERSE ENGINE) | ||
12315-20020 | پایه دسته موتور راست | 1 | $52.39 |
12316 | BRACKET, ENGINE MOUNTING, NO.2 RH | ||
12316-62020 | 1 | $60.69 | |
12317 | STAY, ENGINE MOUNTING, RH | ||
12317-20010 | 1 | $7.99 | |
12321A | BRACKET, ENGINE MOUNTING, REAR(FOR TRANSVERSE ENGINE) | ||
12321-0A040 | پایه دسته موتور عقب | 1 | $168.23 |
12322 | BRACKET, ENGINE MOUNTING, REAR NO.2 | ||
12322-0A030 | 1 | $46.54 | |
12325A | BRACKET, ENGINE MOUNTING, LH(FOR TRANSVERSE ENGINE) | ||
Not applicable | |||
12327A | STAY, ENGINE MOUNTING, NO.2 RH | ||
Not applicable | |||
12361 | INSULATOR, ENGINE MOUNTING, FRONT | ||
12361-20090 | دسته موتور جلو | 1 | $129.60 |
12363A | دسته موتور بالا راست | ||
12363-0A030 | (L) | 1 | $71.48 |
12363-20020 | (J) | 1 | $71.48 |
12371A | INSULATOR, ENGINE MOUNTING, REAR | ||
12371-0A030 | بوش دسته موتور عقب | 1 | $105.13 |
12372A | INSULATOR, ENGINE MOUNTING, LH(FOR TRANSVERSE ENGINE) | ||
12372-0A030 | دسته موتور چپ | 1 | |
12380 | INSULATOR ASSY, ENGINE MOUNTING, REAR | ||
12380-0A060 | دسته موتور عقب کامل | 1 | $185.31 |
12381 | STABILIZER, ENGINE MOUNTING | ||
12381-20010 | موجگیر دسته موتور | 1 | $60.29 |
12392 | INSULATOR, ENGINE MOUNTING HEAT, FRONT LH | ||
Not applicable | |||
12392A | INSULATOR, ENGINE MOUNTING HEAT, REAR | ||
12392-20030 | 1 | $14.83 | |
12393 | INSULATOR, ENGINE MOUNTING HEAT, FRONT | ||
Not applicable | |||
12511 | BRACKET, ALTERNATOR, NO.1 | ||
12511-20020 | 1 | $147.47 | |
12512A | BRACKET, ALTERNATOR, NO.2 | ||
12512-20010 | 1 | $10.79 | |
12514 | BAR, ALTERNATOR BELT ADJUSTING | ||
12514-20010 | (J) | 1 | $22.02 |
12514A | SLIDER, FAN BELT ADJUSTING | ||
16385-20010 | 1 | $7.87 | |
12515 | BOLT, ALTERNATOR THROUGH | ||
12515-20010 | 1 | $5.2 |
11319 | GASKET, TIMING BELT COVER, NO.3 | ||
11319-20010 | 5 | $6.25 | |
11322A | COVER, TIMING BELT, NO.1 | ||
11302-20040 | سینی موتور 1 | 1 | $50.73 |
11322B | COVER, TIMING BELT, NO.2 | ||
11303-20040 | سینی موتور 2 | 1 | $106.79 |
11322C | COVER, TIMING BELT, NO.3 | ||
11323-20030 | سینی موتور 3 | 1 | $130.47 |
11328A | GASKET, TIMING BELT COVER, NO.1 | ||
11328-20020 | واشر سینی جلو موتور | 1 | $6.25 |
11329A | GASKET, TIMING BELT OR CHAIN COVER, NO.2 | ||
11329-20010 | واشر سینی جلو موتور | 1 | $6.25 |
11381 | RETAINER, ENGINE REAR OIL SEAL | ||
11381-20010 | (J) | 1 | $51.52 |
11381A | SEAL, ENGINE REAR OIL | ||
90080-31053 | کاسه نمد ته میل لنگ | 1 | $33.17 |
90311-92008 | (J) | 1 | $55.71 |
11401 | بلوک سیلندر | ||
11401-29516 | (J) | 1 | $2,716.25 |
11415 | COCK SUB-ASSY, WATER DRAIN(FOR CYLINDER BLOCK) | ||
90910-09095 | 1 | $14.11 | |
11415A | PLUG, WATER DRAIN COCK(FOR CYLINDER BLOCK) | ||
90910-09087 | 1 | $4.31 | |
11416 | BOLT(FOR CRANKSHAFT BEARING CAP SET) | ||
90910-02114 | 16 | $3.87 | |
11421 | BOLT, STUD(FOR OIL PAN) | ||
90116-06098 | 2 | $1.11 | |
11432R | PLUG, W/HEAD STRAIGHT SCREW, NO.1(FOR CYLINDER BLOCK) | ||
90341-16013 | 1 | $6.84 | |
11432S | PLUG, W/HEAD STRAIGHT SCREW, NO.2(FOR CYLINDER BLOCK) | ||
90341-16013 | 1 | $6.84 | |
11432T | PLUG, W/HEAD STRAIGHT SCREW, NO.3(FOR CYLINDER BLOCK) | ||
90341-20013 | 1 | $7.71 | |
11432U | GASKET, STRAIGHT SCREW PLUG NO.1(FOR CYLINDER BLOCK) | ||
90430-16009 | 1 | $1.07 | |
11432V | GASKET, STRAIGHT SCREW PLUG NO.2(FOR CYLINDER BLOCK) | ||
90430-16009 | 1 | $1.07 | |
11432W | GASKET, STRAIGHT SCREW PLUG NO.3(FOR CYLINDER BLOCK) | ||
90430-20004 | 1 | $1.34 | |
11434B | PIN, STRAIGHT(FOR CLUTCH HOUSING SET) | ||
90250-10113 | L=22, OD=10 | 2 | $1.34 |
11434C | PIN, STRAIGHT (FOR CYLINDER HEAD SET) | ||
90250-04097 | L=12, OD=4.0 | 1 | $0.55 |
11434D | PIN, STRAIGHT(FOR ENGINE REAR OIL SEAL) | ||
90250-04097 | L=12, OD=4.0 | 2 | $0.55 |
11434J | PIN, RING (FOR CYLINDER HEAD SET) | ||
90253-16001 | 4 | $4.19 | |
11434K | PIN, STRAIGHT(FOR WATER PUMP) | ||
90250-04097 | 2 | $0.55 | |
11434L | PIN, STRAIGHT(FOR ENGINE MOUNTING) | ||
90250-04097 | 2 | $0.55 | |
11434P | PIN, STRAIGHT(FOR OIL PUMP SET) | ||
90250-04097 | L=12, OD=4.0 | 2 | $0.55 |
11434T | PIN, RING(FOR TIMING BELT IDLER BRACKET SET) | ||
90253-11021 | 1 | $2.13 | |
11434Y | PIN, STRAIGHT(FOR OIL PAN) | ||
90250-04097 | 2 | $0.55 | |
11452 | GUIDE, OIL LEVEL GAGE | ||
11452-20020 | جای گیج روغن | 1 | $18.19 |
11452B | RING, O(FOR OIL LEVEL GAGE GUIDE) | ||
96721-19010 | 1 | $2.11 | |
11492C | PLATE, WATER SEAL | ||
11492-20010 | 1 | $9.69 | |
12101 | PAN SUB-ASSY, OIL | ||
12111-20032 | کارتل آلومینیومی زیر موتور | 1 | $348.52 |
12101A | PLUG(FOR OIL PAN DRAIN) | ||
90341-12012 | 1 | $4.94 | |
12101B | GASKET(FOR OIL PAN DRAIN PLUG) | ||
90430-12031 | 1 | $1.11 | |
12102A | PAN SUB-ASSY, OIL, NO.2 | ||
12102-20010 | کارتل آهنی روغن موتور | 1 | $217.30 |
12121 | PLATE, OIL PAN BAFFLE, NO.1 | ||
12121-20021 | (J) | 1 | $32.66 |
15301 | GAGE SUB-ASSY, OIL LEVEL | ||
15301-20021 | گیج روغن | 1 | $13.48 |
11101 | HEAD SUB-ASSY, CYLINDER | ||
11101-29410 | سرسیلندر راست | 1 | $1,569.72 |
11101A | BOLT(FOR CYLINDER HEAD SET) | ||
90910-02117 | پیچ سرسیلندر | 16 | $8.34 |
11101B | WASHER, PLATE(FOR CYLINDER HEAD SET) | ||
90201-11031 | 16 | $1.98 | |
11102 | HEAD, CYLINDER, LH | ||
11102-29040 | سرسیلندر چپ | 1 | $1,569.72 |
11102A | SENSOR, CAMSHAFT POSITION | ||
90919-05013 | سنسور موقعیت میل سوپاپ | 1 | $135.45 |
11115 | GASKET, CYLINDER HEAD | ||
11115-20041 | واشر سرسیلندر | 1 | $43.70 |
11115-20042 | (08/2004 – ) | 1 | $43.70 |
11116 | GASKET, CYLINDER HEAD, NO.2 | ||
11116-20041 | واشر سرسیلندر چپ | 1 | $43.70 |
11116-20042 | (08/2004 – ) | 1 | $43.70 |
11116A | PLUG, TIGHT, NO.1 | ||
Not applicable | |||
11116B | PLUG, TIGHT, NO.2 | ||
Not applicable | |||
11117E | PLUG, W/HEAD STRAIGHT SCREW, NO.1 | ||
90341-24013 | 2 | $12.73 | |
11117F | PLUG, W/HEAD STRAIGHT SCREW, NO.2 | ||
90341-24013 | 2 | $12.73 | |
11117H | GASKET(FOR WATER HOLE) | ||
90430-24246 | 2 | $1.34 | |
11117J | GASKET(FOR CYLINDER HEAD SCREW PLUG) | ||
90430-24246 | 2 | $1.34 | |
11122 | گاید سوپاپ | ||
11122-20020 | STD | 6 | $10.95 |
11123-20020 | O/S 0.05 | 6 | $10.95 |
11122B | گاید سوپاپ | ||
11122-20020 | STD | 6 | $10.95 |
11123-20020 | O/S 0.05 | 6 | $10.95 |
11126 | گاید سوپاپ دود | ||
11126-20020 | STD | 6 | $10.95 |
11127-20020 | O/S 0.05 | 6 | $10.95 |
11126B | گاید سوپاپ دود | ||
11126-20020 | STD | 6 | $10.95 |
11127-20020 | O/S 0.05 | 6 | $10.95 |
11131 | SEAT, INTAKE VALVE | ||
11131-62050 | STD | 6 | $11.23 |
11132-62050 | O/S 0.03 | 6 | $11.23 |
11131A | SEAT, INTAKE VALVE, NO.2 | ||
11131-62050 | STD | 6 | $11.23 |
11132-62050 | O/S 0.03 | 6 | $11.23 |
11135 | SEAT, EXHAUST VALVE | ||
11135-20040 | STD | 6 | $11.23 |
11136-20040 | O/S 0.03 | 6 | $11.23 |
11135A | SEAT, EXHAUST VALVE, NO.2 | ||
11135-20040 | STD | 6 | $11.23 |
11136-20040 | O/S 0.03 | 6 | $11.23 |
11151B | SEAL, OIL(FOR CAMSHAFT SETTING) | ||
90311-38034 | (J) | 2 | $10.71 |
11155A | PIN, RING W/HEAD | ||
90253-10004 | 19 | $3.60 | |
11155B | PIN, RING | ||
90253-10004 | 19 | $3.60 | |
11159A | BOLT(FOR HEAD TO CAMSHAFT BEARING CAP) | ||
90119-07009 | 20 | $1.11 | |
11159C | BOLT(FOR HEAD TO CAMSHAFT BEARING CAP) | ||
90119-07009 | 20 | $1.11 | |
11181 | PLATE, CYLINDER HEAD, REAR | ||
Not applicable | |||
11183 | PLUG, SEMICIRCULAR | ||
11183-20010 | ENGINE NO.=0XXXXXX-4XXXXXX | 4 | $7.83 |
11193 | GASKET, SPARK PLUG TUBE | ||
11193-62040 | (08/2004 – 10/2004) | 3 | $3.52 |
11193-70010 | (08/2002 – 07/2004) | 3 | $3.52 |
11193A | GASKET, SPARK PLUG TUBE, LH | ||
11193-70010 | 3 | $3.52 | |
11201 | درب سوپاپ | ||
11201-20070 | ENGINE NO.=0XXXXXX-4XXXXXX | 1 | $276.64 |
11201-20090 | 1 | $250.07 | |
11202 | درب سوپاپ چپ | ||
11202-20031 | ENGINE NO.=0XXXXXX-4XXXXXX | 1 | $276.64 |
11209 | COVER SUB-ASSY, V-BANK | ||
11209-20011 | کاور موتور | 1 | $71.92 |
11213 | GASKET, CYLINDER HEAD COVER | ||
11213-20020 | واشر درب سوپاپ | 1 | $26.68 |
11214 | GASKET, CYLINDER HEAD COVER, NO.2 | ||
11214-20010 | واشر درب سوپاپ | 1 | $26.68 |
12108 | CAP SUB-ASSY, OIL FILLER | ||
12180-20030 | درب روغن موتور | 1 | $18.27 |
12108A | GASKET(FOR OIL FILLER CAP) | ||
12195-20020 | 1 | $3.32 | |
12281A | HANGER, ENGINE, NO.1 | ||
12281-20030 | (J) | 1 | $28.90 |
12282D | HANGER, ENGINE, NO.2 | ||
12282-20020 | X | $19.06 |
04111 | واشر کامل | ||
04111-20292 | (08/2004 – 05/2006) | 1 | $374.32 |
04111-20340 | (12/2003 – 07/2004) | 1 | $374.32 |
04112 | واشر نیمه کامل | ||
04112-20281 | (08/2004 – 05/2006) | 1 | $301.07 |
04112-20320 | (12/2003 – 07/2004) | 1 | $301.07 |
