رادیاتور آب هایلوکس 2001-2002-2003-2004
| 16119A | GASKET, THERMOSTAT GUIDE | ||
| 16119-75020 | 1 | $4.35 | |
| 16128A | PLATE, WATER PUMP THERMOSTAT GUIDE | ||
| 16128-75020 | 1 | $25.11 | |
| 16192-71010 | *** STD. PART | $2.81 | |
| 16261 | HOSE, WATER BY-PASS | ||
| 16261-75040 | شلنگ رادیاتور | 1 | $6.17 |
| 16261A | CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||
| 96135-51300 | 2 | $3.20 | |
| 16264 | شلنگ رادیاتور 2 | ||
| Not applicable | |||
| 16264A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||
| Not applicable | |||
| 16267 | HOSE, WATER BY-PASS, NO.3 | ||
| 16267-75010 | شلنگ رادیاتور 3 | 1 | $11.82 |
| 16267A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.3) | ||
| 96135-51300 | 2 | $3.20 | |
| 16268 | PIPE, WATER BY-PASS, NO.1 | ||
| 16268-75080 | لوله رادیاتور 1 | 1 | $47.40 |
| 16268G | GASKET(FOR WATER BY-PASS PIPE) | ||
| 17175-75010 | 1 | $3.00 | |
| 16278 | لوله رادیاتور 2 | ||
| Not applicable | |||
| 16281 | شلنگ رادیاتور 4 | ||
| Not applicable | |||
| 16281A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.4) | ||
| Not applicable | |||
| 16282 | شلنگ رادیاتور 5 | ||
| Not applicable | |||
| 16282A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.5) | ||
| Not applicable | |||
| 16283 | شلنگ رادیاتور 6 | ||
| Not applicable | |||
| 16283A | CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.6) | ||
| Not applicable | |||
| 16321 | INLET, WATER | ||
| 16321-0W010 | 1 | $37.24 | |
| 16325 | GASKET, WATER INLET HOUSING, NO.1 | ||
| 16325-76010 | 1 | $6.01 | |
| 16331 | OUTLET, WATER | ||
| 16331-0W010 | 1 | $33.57 | |
| 16331A | ترموستات | ||
| 90916-03120 | WAX TYPE (OPENING TEMPERATURE – FULLY OPEN TEMPERATURE) 82-95 | 1 | $41.74 |
| 16341 | GASKET, WATER OUTLET | ||
| 16341-75020 | 1 | $3.87 | |
| 16361 | پروانه | ||
| 16361-75020 | 1 | $91.65 | |
| 16381 | BAR, FAN BELT ADJUSTING | ||
| 16381-75050 | 1 | $18.19 | |
| 16385 | SLIDER, FAN BELT ADJUSTING | ||
| 16385-75030 | 1 | $9.92 | |
| 16400 | RADIATOR ASSY | ||
| 16400-75280 | رادیاتور آب | 1 | $456.08 |
| 16470 | TANK ASSY, RADIATOR RESERVE | ||
| 16470-75070 | مخزن ذخیره آب | 1 | $133.71 |
| 16470A | HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||
| Not applicable | |||
| 16470B | CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||
| Not applicable | |||
| 16470J | HOSE, NO.3(FOR RADIATOR RESERVE TANK) | ||
| Not applicable | |||
| 16470M | GROMMET | ||
| 90480-25025 | 1 | $10.52 | |
| 16470R | HOSE, NO.2(FOR RADIATOR RESERVE TANK) | ||
| Not applicable | |||
| 16471 | CAP SUB-ASSY, RESERVE TANK | ||
| 16405-75070 | درب مخزن رادیاتور | 1 | $18.82 |
| 16561 | SEAL, RADIATOR TO SUPPORT, NO.1 | ||
| 16561-54050 | PLANT NO.P11 | 1 | $37.16 |
| 16571 | HOSE, RADIATOR, INLET | ||
| 16571-75100 | شلنگ ورودی رادیاتور | 1 | $33.61 |
| 16571A | CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||
| 90467-37005 | 2 | $6.01 | |
| 16572 | HOSE, RADIATOR, OUTLET | ||
| 16572-75130 | شلنگ خروجی رادیاتور | 1 | $24.99 |
| 16572A | CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||
| 90467-37005 | 2 | $6.01 | |
| 16573B | HOSE, RADIATOR, NO.3 | ||
| 16573-75030 | شلنگ رادیاتور 3 | 1 | $27.20 |
| 16573C | CLAMP OR CLIP, RADIATOR HOSE, NO.3 | ||
| 90467-37005 | 2 | $6.01 | |
| 16577C | PIPE, RADIATOR | ||
| 16577-75020 | لوله رادیات | 1 | $114.54 |
| 16581 | CLAMP, HOSE(FOR WATER HOSE) | ||
| 16581-75010 | 1 | $10.36 | |
| 16711 | SHROUD, FAN | ||
| 16711-75100 | بادگیر رادیات | 1 | $139.61 |
| 16712 | SHROUD, FAN, NO.2 | ||
| 16712-75060 | 1 | $55.71 | |
| 16712A | CLIP | ||
| 90468-06092 | 2 | $1.70 | |
| 16715A | BRACKET, FAN SHROUD, NO.2 | ||
| Not applicable | |||
