صافی بنزین لندکروزر 2008-2011
| 23070 | VALVE ASSY, FUEL MAIN | ||
| 23070-38010 | ریگلاتور بنزین لندکروزر | 1 | $50.65 |
| 23221 | PUMP, FUEL | ||
| 23220-50270 | مغزی پمپ بنزین لندکروزر | 1 | $382.88 |
| 23225A | SPACER, FUEL PUMP | ||
| 23225-23010 | 1 | $2.89 | |
| 23280K | RING, O(FOR FUEL PRESSURE REGULATOR) | ||
| 90301-08019 | 1 | $3.29 | |
| 77017 | TUBE SUB-ASSY, FUEL AND EVAPORATION VENT | ||
| 77017-60550 | 1 | $62.39 | |
| 77018E | TUBE SUB-ASSY, FUEL TANK EVAPORATION VENT | ||
| 77018-60160 | NO.1:REFER ILLUST. | 1 | $23.37 |
| 77018-60170 | NO.2:REFER ILLUST. | 1 | $22.81 |
| 77020A | TUBE ASSY, FUEL SUCTION W/PUMP & GAGE | ||
| 77020-60390 | 1 | $863.57 | |
| 77024A | PLATE SUB-ASSY, FUEL SUCTION | ||
| 77024-60230 | صافی بنزین داخل باک لندکروزر | 1 | $85.99 |
| 77035 | CABLE SUB-ASSY, FUEL LID LOCK CONTROL | ||
| 77035-60140 | سیم قفل درب باک لندکروزر | 1 | $55.43 |
| 77035A | CLAMP (FOR FUEL LID LOCK CONTROL CABLE) | ||
| 90469-06005 | 5 | $1.82 | |
| 77100U | TANK SUB-ASSY, FUEL | ||
| 77001-60820 | باک اصلی لندکروزر | 1 | $815.61 |
| 77100Z | TANK SUB-ASSY, FUEL SUB | ||
| 77001-60830 | باک ذخیره لندکروزر | 1 | $453.61 |
| 77131C | SUB-TANK, FUEL, NO.1 | ||
| 77131-60120 | پایه فیلتر بنزین لندکروزر | 1 | $22.46 |
| 77144 | RETAINER, FUEL PUMP GAUGE | ||
| 77144-47020 | پیچ درب صافی بنزین لندکروزر | 1 | $44.48 |
| 77169A | GASKET, FUEL SUCTION TUBE SET | ||
| 77169-47030 | واشر صافی بنزین لندکروزر | 1 | $3.48 |
| 77169B | GASKET, FUEL SUCTION TUBE SET, NO.1 | ||
| 77169-32010 | لوله گلویی باک بنزین لندکروزر | 1 | $11.54 |
| 77201 | PIPE SUB-ASSY, FUEL TANK INLET | ||
| 77201-60B00 | 1 | $199.78 | |
| 77201-60B10 | GCC SPEC(EXCEPT SAUDI ARABIA) | 1 | $199.78 |
| 77204A | TUBE, FUEL TANK RETURN | ||
| 77204-60070 | 1 | $36.93 | |
| 77206C | TUBE SUB-ASSY, FUEL MAIN, NO.2 | ||
| 77206-60460 | 1 | $49.34 | |
| 77209C | TUBE SUB-ASSY, FUEL TANK MAIN | ||
| 77209-60470 | 1 | $18.50 | |
| 77213B | HOSE, FUEL TANK TO FILLER PIPE | ||
| 77213-60310 | 1 | $49.66 | |
| 77213E | HOSE, FUEL TANK TO FILLER PIPE | ||
| 77213-60320 | 1 | $34.28 | |
| 77241W | CLIP, TUBE JOINT | ||
| 77241-60320 | 3 | $1.07 | |
| 77269A | HOSE, FUEL TANK BREATHER | ||
| 95313-13020 | 1 | $12.30 | |
| 77272B | SUPPORT, BREATHER TUBE, NO.1 | ||
| 77205-60C00 | 1 | $13.96 | |
| 77277R | PROTECTOR, FUEL TANK FILLER PIPE | ||
| 77277-60130 | 1 | $66.34 | |
| 77278C | PROTECTOR, FUEL TANK FILLER PIPE, NO.2 | ||
| Not applicable | |||
| 77285D | CLAMP, FUEL TUBE, NO.1 | ||
| 77285-60840 | 1 | $11.66 | |
| 77285F | CLAMP, FUEL TUBE, NO.1 | ||
| 77197-60030 | 1 | $3.48 | |
| 77285G | CLAMP, FUEL TUBE, NO.1 | ||
| 77285-60870 | 1 | $5.69 | |
| 77291A | SHIELD, FUEL TANK FILLER PIPE | ||
| 77291-60120 | لوله ورودی باک بنزین لندکروزر | 1 | $39.06 |
| 77306 | اهرم باز کن درب باک لندکروزر | ||
| 77306-28060-C0 | BLACK, TRIM1* | 1 | $15.22 |
| 77306-28060-E0 | DK. BROWN, TRIM4* | 1 | $15.97 |
| 77310A | CAP ASSY, FUEL TANK | ||
| 77300-52030 | درب باک از داخل لندکروزر | 1 | $41.99 |
| 77316 | GASKET, FUEL TANK CAP | ||
| 77316-52040 | واشر درب باک لندکروزر | 1 | |
| 77350 | LID ASSY, FUEL FILLER OPENING | ||
| 77350-60090 | درب باک بیرونی لندکروزر | 1 | $71.64 |
| 77366 | SPRING, FUEL FILLER OPENING LID HINGE | ||
| 77360-35040 | 1 | $5.46 | |
| 77371L | RING, FUEL TANK FILLER PIPE SHIELD | ||
| 77371-35010 | 1 | $2.85 | |
| 77377 | RETAINER, FUEL FILLER OPENING LID LOCK | ||
| 77377-35010 | 1 | $3.91 | |
| 77391A | RING, FUEL INLET BOX | ||
| 77391-35020 | 1 | $3.84 | |
| 77419 | HOSE, FUEL, NO.3 | ||
| 77419-60020 | 1 | $14.04 | |
| 77512 | BRACKET, FUEL TANK, REAR | ||
| 77512-35140 | 4 | $4.27 | |
| 77601A | BAND SUB-ASSY, FUEL TANK, NO.1 | ||
| 77601-60310 | 1 | $76.86 | |
| 77603A | BAND SUB-ASSY, FUEL TANK, NO.2 | ||
| 77602-60110 | 1 | $88.33 | |
| 77603B | BAND SUB-ASSY, FUEL TANK, NO.2 RH | ||
| 77603-60040 | 1 | $59.35 | |
| 77604B | BAND SUB-ASSY, FUEL TANK, NO.2 LH | ||
| 77604-60040 | 1 | $59.35 | |
| 77606 | PROTECTOR SUB-ASSY, FUEL TANK, NO.1 | ||
| 77606-60170 | 1 | $467.72 | |
| 77611E | PIN, FUEL TANK BAND | ||
| 77653-35040 | 2 | $9.45 | |
| 77633 | STAY, FUEL TANK | ||
| 77633-60070 | 1 | $8.97 | |
| 77644 | BOLT, FUEL TANK | ||
| 77644-35030 | 2 | $2.17 | |
| 77697 | INSULATOR, FUEL TANK HEAT, NO.1 | ||
| 77697-60010 | 1 | $101.69 | |
| 77785 | HARNESS, FUEL PUMP | ||
| 77785-60010 | 1 | $21.63 | |
| 90105-06321 | *** STD. PART | $0.75 | |
| 90119-08A33 | *** STD. PART | $1.03 | |
| 90119-10816 | *** STD. PART | $1.54 | |
| 90159-50219 | *** STD. PART | $0.75 | |
| 90166-60003 | *** STD. PART | $0.79 | |
| 90179-08234 | *** STD. PART | $1.11 | |
| 90183-06019 | *** STD. PART | $0.99 | |
| 90189-06065 | *** STD. PART | $1.03 | |
| 90189-06171 | *** STD. PART | $0.95 | |
| 90269-06017 | *** STD. PART | $1.82 | |
| 90301-04013 | *** STD. PART | $3.01 | |
| 90301-15024 | *** STD. PART | $3.01 | |
| 90386-01004 | *** STD. PART | $1.94 | |
| 90460-22002 | *** STD. PART | $6.33 | |
| 90460-46005 | *** STD. PART | ||
| 90460-46006 | *** STD. PART | ||
| 90460-50008 | *** STD. PART | $7.51 | |
| 90468-14032 | *** STD. PART | $1.27 | |
| 90959-04001 | *** STD. PART | $7.99 | |
| 91621-J0612 | *** STD. PART | $0.79 | |
| 91651-B0820 | *** STD. PART | $1.34 | |
| 96133-41101 | *** STD. PART | ||
