تسمه دینام GT86 SU003-02202
برچسب: لوازم یدکی GT86
رینگ و قالپاق و مهره چرخ GT86
| 42601 | WHEEL, DISC | ||
| SU003-00757 | 17X7J, *, TYPE B:REFER ILLUST. | 4 | |
| 42601A | WHEEL, DISC (FOR SPARE) | ||
| SU003-00757 | 17X7J, *, TYPE B:REFER ILLUST. | 1 | |
| 42601C | NUT, HUB (FOR AXLE) | ||
| SU003-00765 | مهره چرخ | 20 | |
| 42607 | VALVE SUB-ASSY, TIRE PRESSURE MONITOR | ||
| Not applicable | |||
| 42611G | VALVE (FOR TUBELESS TIRE) | ||
| SU003-00447 | 4 | ||
| 42611U | CAP, TIRE VALVE | ||
| Not applicable | |||
| SU003-00755 | *** STD. PART | ||
| SU003-02897 | *** STD. PART | ||
| SU003-02902 | *** STD. PART | ||
| SU003-02943 | *** STD. PART |
| 42601A | WHEEL, DISC (FOR SPARE) | ||
| SU003-00757 | 17X7J, *, TYPE B:REFER ILLUST. | 1 | |
| 42601C | NUT, HUB (FOR AXLE) | ||
| SU003-00765 | 20 | ||
| 42611J | VALVE (FOR TUBELESS TIRE SPARE) | ||
| SU003-00447 | 1 |
| 42603 | ORNAMENT SUB-ASSY, WHEEL HUB | |
| SU003-00797 | قالپاق تو رینگی GT86 | 4 |
سر سیلندر GT86 مدل 2013
| 11101V | BOLT(FOR CYLINDER HEAD SET SUB) | ||
| SU003-00117 | پیچ سرسیلندر | 12 | |
| 11103C | HOUSING SUB-ASSY, CAMSHAFT, RH | ||
| SU003-04235 | 1 | ||
| 11103D | BOLT(FOR CAMSHAFT HOUSING TO CYLINDER HEAD, RH) | ||
| SU003-04265 | 9 | ||
| 11103G | SPACER, OIL, RH | ||
| SU003-00816 | 1 | ||
| 11115 | GASKET, CYLINDER HEAD | ||
| SU003-00112 | واشر سرسیلندر | 1 | |
| 11151E | BOLT(FOR CAMSHAFT BEARING CAP TO HOUSING RH, NO.1) | ||
| SU003-04264 | 25 | ||
| 11191A | GASKET(FOR SPARK PLUG TUBE) | ||
| SU003-00100 | 2 | ||
| 15044 | PIPE SUB-ASSY, CAMSHAFT OIL FEED | ||
| SU003-00308 | 1 | ||
| 15678D | FILTER, OIL CONTROL VALVE, RH | ||
| SU003-00299 | 2 | ||
| SU003-00309 | *** STD. PART | ||
| SU003-02155 | *** STD. PART | ||
| SU003-02184 | *** STD. PART | ||
| SU003-02193 | *** STD. PART | ||
| SU003-02196 | *** STD. PART | ||
| SU003-02197 | *** STD. PART | ||
| SU003-04084 | *** STD. PART | ||
 |
|||
| 11101V | BOLT(FOR CYLINDER HEAD SET SUB) | ||
| SU003-00117 | 12 | ||
| 11104A | HOUSING SUB-ASSY, CAMSHAFT, LH | ||
| SU003-04237 | 1 | ||
| 11104B | BOLT(FOR CAMSHAFT HOUSING TO CYLINDER HEAD, LH) | ||
| SU003-04265 | 9 | ||
| 11104E | CASE ASSY, PUMP DRIVE | ||
| SU003-00330 | 1 | ||
| 11104F | SPACER, OIL, LH | ||
| SU003-00816 | 1 | ||
| 11116 | GASKET, CYLINDER HEAD, NO.2 | ||
| SU003-00099 | 1 | ||
| 11153A | BOLT(FOR CAMSHAFT BEARING CAP TO HOUSING LH, NO.1) | ||
| SU003-04264 | 25 | ||
| 11193A | GASKET, SPARK PLUG TUBE, LH | ||
| SU003-00100 | 2 | ||
| 13751A | LIFTER, VALVE | ||
| SU003-00277 | 1 | ||
| 15678E | FILTER, OIL CONTROL VALVE, LH | ||
| SU003-00299 | 2 | ||
| SU003-02134 | *** STD. PART | ||
| SU003-02184 | *** STD. PART | ||
| SU003-02197 | *** STD. PART | ||
 |
|||
| 11101 | HEAD SUB-ASSY, CYLINDER | ||
| SU003-00111 | 1 | ||
| 11102 | HEAD, CYLINDER, LH | ||
| SU003-00115 | 1 | ||
| 11117A | PLUG, W/HEAD TAPER SCREW, NO.1 | ||
| SU003-00303 | 2 | ||
| 11117B | PLUG, W/HEAD TAPER SCREW, NO.2 | ||
| SU003-00303 | 3 | ||
| 11122 | BUSH, INTAKE VALVE GUIDE | ||
| SU003-04238 | 4 | ||
| 11122B | BUSH, INTAKE VALVE GUIDE, NO.2 | ||
| SU003-04238 | 4 | ||
| 11126 | BUSH, EXHAUST VALVE GUIDE | ||
| SU003-04239 | 4 | ||
| 11126B | BUSH, EXHAUST VALVE GUIDE, NO.2 | ||
| SU003-04239 | 4 | ||
| SU003-02150 | *** STD. PART | ||
 |
|||
| 11201 | COVER SUB-ASSY, CYLINDER HEAD | ||
| SU003-00279 | 1 | ||
| 11202 | COVER SUB-ASSY, CYLINDER HEAD, LH | ||
| SU003-00282 | 1 | ||
| 11213 | GASKET, CYLINDER HEAD COVER | ||
| SU003-00280 | 1 | ||
| 11214 | GASKET, CYLINDER HEAD COVER, NO.2 | ||
| SU003-00281 | 1 | ||
| SU003-02197 | *** STD. PART | ||
 |
|||
| 11101Y | HEAD & VALVE SET, CYLINDER, RH | ||
| SU003-00103 | 1 | ||
| 11102B | HEAD & VALVE SET, CYLINDER, LH | ||
| SU003-00104 | 1 | ||
 |
|||
| 11102A | SENSOR, CAMSHAFT POSITION | ||
| SU003-00413 | NO.2 | 1 | |
| SU003-00414 | NO.1 | 3 | |
| SU003-00184 | *** STD. PART | ||
| SU003-00185 | *** STD. PART | ||
| SU003-04259 | *** STD. PART | ||
 |
|||
موتور کامل و نیم موتور GT86 مدل 2013
| 11000 | ENGINE ASSY, PARTIAL | ||
| SU003-05254 | موتور کامل | 1 | |
| 12000 | ENGINE ASSY | ||
| SU003-00087 | DESTINATION CODE=EB | 1 | |
| SU003-00092 | DESTINATION CODE=ES | 1 | |
 |
|||
| 11400 | BLOCK ASSY, SHORT | ||
| SU003-00093 | نیم موتور | 1 | |
 |
|||
باک GT86 مدل 2013
| 77023 | FILTER SUB-ASSY, FUEL SUCTION TUBE | ||
| SU003-01105 | درجه داخل باک | 1 | |
| 77023B | FILTER SUB-ASSY, FUEL SUCTION TUBE, NO.2 | ||
| SU003-01081 | 1 | ||
| 77100 | TANK ASSY, FUEL | ||
| SU003-01014 | باک بنزین | 1 | |
| 77144 | RETAINER, FUEL PUMP GAUGE | ||
| SU003-01023 | 2 | ||
| 77166 | CUSHION, FUEL TANK PROTECTOR | ||
| SU003-01042 | 3 | ||
| 77169A | GASKET, FUEL SUCTION TUBE SET | ||
| SU003-01019 | 2 | ||
| 77197A | CLAMP, EVAPORATION VENT TUBE, NO.2 | ||
| SU003-01036 | 1 | ||
| 77204C | TUBE SUB-ASSY, FUEL TANK MAIN, NO.2 | ||
| SU003-01084 | 1 | ||
| 77209F | TUBE SUB-ASSY, FUEL TANK MAIN | ||
| SU003-01085 | 1 | ||
| 77211B | CLAMP (FOR FUEL FILLER PIPE) | ||
| SU003-01030 | 1 | ||
| 77213B | HOSE, FUEL TANK TO FILLER PIPE | ||
| SU003-01101 | 1 | ||
| 77226A | TUBE, FUEL TANK BREATHER, NO.6 | ||
| SU003-01099 | 1 | ||
| 77229C | CLAMP, BREATHER TUBE | ||
| SU003-01024 | 1 | ||
| 77404 | HOSE SUB-ASSY, FUEL TANK VENT | ||
| SU003-01100 | 1 | ||
| 77606 | PROTECTOR SUB-ASSY, FUEL TANK, NO.1 | ||
| SU003-01070 | 1 | ||
| 77651A | CUSHION, FUEL TANK, NO.1 | ||
| SU003-01047 | 6 | ||
| 77652A | CUSHION, FUEL TANK, NO.2 | ||
| SU003-01045 | 4 | ||
| SU003-01015 | *** STD. PART | ||
| SU003-01016 | *** STD. PART | ||
| SU003-04078 | *** STD. PART | ||
| SU003-04167 | *** STD. PART | ||
 |
|||
اسپویلر سپر ها و بال GT86 مدل 2013
| 71196A | CLIP | ||
| SU003-02984 | 9 | ||
| 76851A | COVER, FRONT SPOILER, RH | ||
| SU003-04184 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-04185 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-04186 | ORANGE METALLIC, H8R | 1 | |
| SU003-04188 | LIGHTNING RED, C7P | 1 | |
| SU003-04189 | STERLING SILVER M, D6S | 1 | |
| SU003-04190 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-04191 | SATIN WHITE PEARL, 37J | 1 | |
| 76852A | COVER, FRONT SPOILER, LH | ||
| SU003-04192 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-04193 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-04194 | ORANGE METALLIC, H8R | 1 | |
| SU003-04196 | LIGHTNING RED, C7P | 1 | |
| SU003-04197 | STERLING SILVER M, D6S | 1 | |
| SU003-04198 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-04199 | SATIN WHITE PEARL, 37J | 1 | |
| 76853B | COVER, FRONT SPOILER, CENTER | ||
| SU003-04176 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-04177 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-04178 | ORANGE METALLIC, H8R | 1 | |
| SU003-04180 | LIGHTNING RED, C7P | 1 | |
| SU003-04181 | STERLING SILVER M, D6S | 1 | |
| SU003-04182 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-04183 | SATIN WHITE PEARL, 37J | 1 | |
| 76857 | RETAINER, FRONT SPOILER SIDE, RH | ||
| SU003-04200 | 1 | ||
| 76858 | RETAINER, FRONT SPOILER SIDE, LH | ||
| SU003-04201 | 1 | ||
| 76917D | CLIP | ||
| SU003-02964 | 6 | ||
| 76917E | CLIP | ||
| SU003-02989 | 2 | ||
| SU003-01514 | *** STD. PART | ||
| SU003-03352 | *** STD. PART | ||
| SU003-04226 | *** STD. PART | ||
 |
|||
| 76793C | BRACKET, REAR SPOILER, NO.2 RH | ||
| SU003-03949 | 1 | ||
| 76794C | BRACKET, REAR SPOILER, NO.2 LH | ||
| SU003-03950 | 1 | ||
| 76867 | RETAINER, REAR SPOILER SIDE, RH | ||
| SU003-03971 | 1 | ||
| 76868 | RETAINER, REAR SPOILER SIDE, LH | ||
| SU003-03972 | 1 | ||
| 76871B | COVER, REAR SPOILER | ||
| SU003-03954 | 1 | ||
| 76879B | CLIP, REAR SPOILER, NO.2 | ||
| SU003-04055 | 14 | ||
| 76889 | CLIP, REAR SPOILER, NO.2 | ||
| SU003-02963 | 4 | ||
| 76889D | CLIP, REAR SPOILER, NO.2 | ||
| SU003-02988 | 4 | ||
| 76897A | SPOILER,REAR SIDE RH | ||
| SU003-03955 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-03956 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-03957 | ORANGE METALLIC, H8R | 1 | |
| SU003-03959 | LIGHTNING RED, C7P | 1 | |
| SU003-03960 | STERLING SILVER M, D6S | 1 | |
| SU003-03961 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-03962 | SATIN WHITE PEARL, 37J | 1 | |
| 76898A | SPOILER,REAR SIDE LH | ||
| SU003-03963 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-03964 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-03965 | ORANGE METALLIC, H8R | 1 | |
| SU003-03967 | LIGHTNING RED, C7P | 1 | |
| SU003-03968 | STERLING SILVER M, D6S | 1 | |
| SU003-03969 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-03970 | SATIN WHITE PEARL, 37J | 1 | |
| 76973D | COVER, REAR UNDER SIDE, RH | ||
| SU003-03952 | 1 | ||
| 76974D | COVER, REAR UNDER SIDE, LH | ||
| SU003-03953 | 1 | ||
| SU003-03352 | *** STD. PART | ||
| SU003-04223 | *** STD. PART | ||
 |
|||
| 71196 | CLIP(FOR REAR SPOILER) | ||
| SU003-02982 | 2 | ||
| 76085A | CAP(FOR REAR SPOILER) | ||
| SU003-01986 | 4 | ||
| 76871 | SPOILER, REAR | ||
| SU003-04233 | OPTION CODE=5U&DESTINATION CODE=K4, BLACK, 37J, 61K, C7P, D4S, D6S, E8H, H8R | 1 | |
| SU003-04234 | DESTINATION CODE=ES&OPTION CODE=NW, BLACK, 37J, 61K, C7P, D4S, D6S, E8H, H8R | 1 | |
| 76879 | CLIP, REAR SPOILER, NO.1 | ||
| SU003-05744 | 2 | ||
| SU003-04269 | *** STD. PART | ||
 |
|||
| 76085A | CAP(FOR REAR SPOILER) | ||
| SU003-01986 | 4 | ||
| 76791 | BRACKET, REAR SPOILER, NO.1 RH | ||
| SU003-03382 | 1 | ||
| 76792B | BRACKET, REAR SPOILER, NO.1 LH | ||
| SU003-03383 | 1 | ||
| 76871 | SPOILER, REAR | ||
| SU003-04233 | OPTION CODE=5U&DESTINATION CODE=K4, BLACK, 37J, 61K, C7P, D4S, D6S, E8H, H8R | 1 | |
| SU003-04234 | DESTINATION CODE=ES&OPTION CODE=NW, BLACK, 37J, 61K, C7P, D4S, D6S, E8H, H8R | 1 | |
| 76893A | COVER, REAR SPOILER, RH | ||
| SU003-03384 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-03385 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-03386 | ORANGE METALLIC, H8R | 1 | |
| SU003-03387 | LIGHTNING RED, C7P | 1 | |
| SU003-03388 | STERLING SILVER M, D6S | 1 | |
| SU003-03389 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-03390 | SATIN WHITE PEARL, 37J | 1 | |
| 76894 | COVER, REAR SPOILER, LH | ||
| SU003-03391 | GALAXY BLUE SILICA, E8H | 1 | |
| SU003-03392 | DARK GRAY METALLIC, 61K | 1 | |
| SU003-03393 | ORANGE METALLIC, H8R | 1 | |
| SU003-03394 | LIGHTNING RED, C7P | 1 | |
| SU003-03395 | STERLING SILVER M, D6S | 1 | |
| SU003-03396 | CRYSTAL BLACK SILICA, D4S | 1 | |
| SU003-03397 | SATIN WHITE PEARL, 37J | 1 | |
| SU003-02795 | *** STD. PART | ||
| SU003-02853 | *** STD. PART | ||
| SU003-04269 | *** STD. PART | ||
 |
|||
سیستم کی لس GT86 مدل 2013
| 69051 | CYLINDER & KEY SET, DOOR LOCK, RH | ||
| Not applicable | |||
| 69052 | CYLINDER & KEY SET, DOOR LOCK, LH | ||
| SU003-01443 | 1 | ||
| 69055A | CYLINDER & KEY SET, LUGGAGE COMPARTMENT LOCK | ||
| SU003-01429 | 1 | ||
| 69057A | CYLINDER & KEY SET, IGNITION SWITCH LOCK | ||
| Not applicable | |||
| 69503 | CYLINDER SET, LOCK | ||
| SU003-01421 | 1 | ||
| 69563A | PAD, LUGGAGE COMPARTMENT DOOR LOCK CYLINDER | ||
| SU003-04945 | 1 | ||
| 88027 | LABEL, KEY LESS | ||
| Not applicable | |||
| 89070E | TRANSMITTER ASSY, DOOR CONTROL | ||
| Not applicable | |||
| 89071B | MODULE SET, TRANSMITTER SUB-ASSY, DOOR CONTROL | ||
| Not applicable | |||
| 8907A | SWITCH SET, TRANSMITTER | ||
| Not applicable | |||
| 89751A | COVER, TRANSMITTER HOUSING | ||
| Not applicable | |||
| 89752A | CASE, TRANSMITTER HOUSING | ||
| Not applicable | |||
| 89785B | TRANSMITTER, TRANSPONDER KEY MASTER | ||
| Not applicable | |||
 |
|||
درب GT86 مدل 2013
| 67001 | PANEL SUB-ASSY, FRONT DOOR, RH | ||
| SU003-01558 | درب راست | 1 | |
| 67001A | CUSHION, FRONT DOOR PANEL | ||
| SU003-04136 | 4 | ||
| 67002 | PANEL SUB-ASSY, FRONT DOOR, LH | ||
| SU003-01559 | درب چپ | 1 | |
| 68610B | CHECK ASSY, FRONT DOOR, RH | ||
| SU003-01567 | ترمز درب راست | 1 | |
| 68620 | CHECK ASSY, FRONT DOOR, LH | ||
| SU003-01567 | ترمز درب چپ | 1 | |
| SU003-00051 | *** STD. PART | ||
| SU003-02825 | *** STD. PART | ||
| SU003-02909 | *** STD. PART | ||
| SU003-04644 | *** STD. PART | ||
 |
|||
| 62616 | STOPPER, FRONT DOOR SASH | ||
| SU003-04118 | 2 | ||
| 67403F | FRAME SUB-ASSY, FRONT DOOR, REAR LOWER RH | ||
| SU003-01608 | 1 | ||
| 67404F | FRAME SUB-ASSY, FRONT DOOR, REAR LOWER LH | ||
| SU003-01609 | 1 | ||
| 67469 | PROTECTOR, FRONT DOOR GUIDE | ||
| SU003-01625 | 1 | ||
| 67811C | COVER, FRONT DOOR HOLE | ||
| SU003-01604 | RH | 1 | |
| SU003-01605 | LH | 1 | |
| 67831 | COVER, FRONT DOOR SERVICE HOLE, RH | ||
| SU003-01610 | 1 | ||
| 67832 | COVER, FRONT DOOR SERVICE HOLE, LH | ||
| SU003-01611 | 1 | ||
| 68160C | WEATHERSTRIP ASSY, FRONT DOOR GLASS, OUTER RH | ||
| SU003-04334 | 1 | ||
| 68210C | WEATHERSTRIP ASSY, FRONT DOOR GLASS, OUTER LH | ||
| SU003-04335 | 1 | ||
| SU003-00051 | *** STD. PART | ||
| SU003-01624 | *** STD. PART | ||
| SU003-02874 | *** STD. PART | ||
| SU003-02894 | *** STD. PART | ||
| SU003-02920 | *** STD. PART | ||
 |
|||
| 68101 | GLASS SUB-ASSY, FRONT DOOR, RH | ||
| SU003-G0001 | شیشه درب جلو راست | 1 | |
| 68102 | GLASS SUB-ASSY, FRONT DOOR, LH | ||
| SU003-G0002 | شیشه درب جلو چپ | 1 | |
| 68125 | GLASS, FRONT DOOR FIX WINDOW, RH | ||
| SU003-G0010 | شیشه لچکی راست | 1 | |
| 68126 | GLASS, FRONT DOOR FIX WINDOW, LH | ||
| SU003-G0011 | شیشه لچکی چپ | 1 | |
 |
|||
| 67861 | WEATHERSTRIP, FRONT DOOR, RH | ||
| SU003-01631 | 1 | ||
| 67862 | WEATHERSTRIP, FRONT DOOR, LH | ||
| SU003-01632 | 1 | ||
| 67867C | RETAINER, FRONT DOOR WEATHERSTRIP, RH | ||
| SU003-04052 | 13 | ||
| 67868C | RETAINER, FRONT DOOR WEATHERSTRIP, LH | ||
| SU003-04050 | 13 | ||
| 67869B | CLIP, FRONT DOOR WEATHERSTRIP | ||
| SU003-04054 | 4 | ||
| 67869E | CLIP, FRONT DOOR WEATHERSTRIP | ||
| SU003-04053 | 2 | ||
| 68165 | WEATHERSTRIP, DOOR REAR CORNER, RH | ||
| SU003-04601 | 1 | ||
| 68166 | WEATHERSTRIP, DOOR REAR CORNER, LH | ||
| SU003-04602 | 1 | ||
 |
|||
درب صندوق GT86 مدل 2013
| 64401 | PANEL SUB-ASSY, LUGGAGE COMPARTMENT DOOR | ||
| SU003-01454 | DESTINATION CODE=E3&OPTION CODE=NW | 1 | |
| SU003-01455 | DESTINATION CODE=ES&OPTION CODE=NW | 1 | |
| SU003-01458 | OPTION CODE=5U&DESTINATION CODE=K4 | 1 | |
| 64459 | CUSHION, LUGGAGE COMPARTMENT DOOR | ||
| SU003-01472 | 2 | ||
| 64461 | WEATHERSTRIP, LUGGAGE COMPARTMENT DOOR | ||
| SU003-01469 | 1 | ||
| 64469 | CUSHION, LUGGAGE COMPARTMENT DOOR, NO.2 | ||
| Not applicable | |||
| 64510 | HINGE ASSY, LUGGAGE COMPARTMENT DOOR, RH | ||
| SU003-01460 | 1 | ||
| 64520 | HINGE ASSY, LUGGAGE COMPARTMENT DOOR, LH | ||
| SU003-01461 | 1 | ||
| 64530A | SUPPORT ASSY, LUGGAGE COMPARTMENT DOOR | ||
| SU003-01462 | DESTINATION CODE=E3&OPTION CODE=JW | 2 | |
| SU003-01463 | DESTINATION CODE=ES&OPTION CODE=NW | 2 | |
| SU003-01464 | OPTION CODE=5U&DESTINATION CODE=K4 | 2 | |
| 64554 | STOPPER, LUGGAGE DOOR BALANCER | ||
| SU003-01471 | 2 | ||
| 64620E | STRIKER ASSY, LUGGAGE COMPARTMENT DOOR | ||
| SU003-01467 | DESTINATION CODE=ES&OPTION CODE=NW | 1 | |
| SU003-01468 | OPTION CODE=5U&DESTINATION CODE=K4 | 1 | |
| 64650 | CLOSER ASSY, LUGGAGE DOOR | ||
| SU003-01465 | 1 | ||
| 64660 | CABLE ASSY, LUGGAGE CLOSER | ||
| SU003-01406 | 1 | ||
| SU003-00025 | *** STD. PART | ||
| SU003-01413 | *** STD. PART | ||
| SU003-02789 | *** STD. PART | ||
| SU003-02806 | *** STD. PART | ||
| SU003-02898 | *** STD. PART | ||
| SU003-02980 | *** STD. PART | ||
 |
|||
گلگیر عقب و ستون GT86 مدل 2013
| PANEL, COWL TOP SIDE, RH | |||
| SU003-01255 | 1 | ||
| 55714C | PANEL, COWL TOP SIDE, LH | ||
| SU003-01256 | 1 | ||
| 61037A | REINFORCEMENT SUB-ASSY, CENTER BODY PILLAR, RH | ||
| SU003-01257 | دوبل وسط راست | 1 | |
| 61038A | REINFORCEMENT SUB-ASSY, CENTER BODY PILLAR, LH | ||
| SU003-01258 | دوبل وسط چپ | 1 | |
| 61108A | REINFORCE SUB-ASSY, FRONT BODY PILLAR, LOWER RH | ||
| SU003-01259 | دوبل پایینی راست | 1 | |
| 61109A | REINFORCE SUB-ASSY, FRONT BODY PILLAR, LOWER LH | ||
| SU003-01260 | دوبل پایینی چپ | 1 | |
| 61131 | PILLAR, FRONT BODY, UPPER OUTER RH | ||
| SU003-01245 | 1 | ||
| 61132 | PILLAR, FRONT BODY, UPPER OUTER LH | ||
| SU003-01246 | 1 | ||
| 61201 | RAIL SUB-ASSY, ROOF SIDE, RH | ||
| SU003-01261 | 1 | ||
| 61202 | RAIL SUB-ASSY, ROOF SIDE, LH | ||
| SU003-01262 | 1 | ||
| 61403C | REINFORCE SUB-ASSY, ROCKER, OUTER RH | ||
| SU003-01270 | 1 | ||
| 61404E | REINFORCE SUB-ASSY, ROCKER, OUTER LH | ||
| SU003-01271 | 1 | ||
| 61431 | PANEL, ROCKER, OUTER REAR RH | ||
| SU003-01251 | OPTION CODE=MU | 1 | |
| SU003-01253 | OPTION CODE=5L | 1 | |
| 61432 | PANEL, ROCKER, OUTER REAR LH | ||
| SU003-01252 | OPTION CODE=MU | 1 | |
| SU003-01254 | OPTION CODE=5U | 1 | |
| 61611 | گلگیر عقب راست | ||
| SU003-01247 | OPTION CODE=MU | 1 | |
| SU003-01249 | OPTION CODE=5U | 1 | |
| 61612 | گلگیر عقب چپ | ||
| SU003-01248 | OPTION CODE=MU | 1 | |
| SU003-01250 | OPTION CODE=5U | 1 | |
| 61613E | PANEL, QUARTER, INNER RH | ||
| SU003-01263 | کلاف سقف داخلی راست | 1 | |
| 61614E | PANEL, QUARTER, INNER LH | ||
| SU003-01264 | کلاف سقف داخلی چپ | 1 | |
| 61617A | PANEL, QUARTER INNER, REAR RH | ||
| SU003-01265 | 1 | ||
| 61618A | PANEL, QUARTER, INNER REAR LH | ||
| SU003-01266 | 1 | ||
| 61627E | EXTENSION, QUARTER PANEL, REAR LOWER RH | ||
| SU003-01267 | 1 | ||
| 61628D | EXTENSION, QUARTER PANEL, REAR LOWER LH | ||
| SU003-01268 | 1 | ||
| 62155B | PAD, QUARTER PANEL | ||
| SU003-02952 | 2 | ||
| SU003-01987 | *** STD. PART | ||
 |
|||
کنسول GT86 مدل 2013
| 55620A | CUSHION(FOR CUP HOLDER) | ||
| SU003-03213 | قاب هولدر | 1 | |
| 55620B | HOLDER, INSTRUMENT PANEL CUP | ||
| SU003-03208 | 1 | ||
| 58810J | باکس کنسول | ||
| SU003-03188 | DESTINATION CODE=ES&OPTION CODE=NW | 1 | |
| SU003-03189 | DESTINATION CODE=ES&OPTION CODE=NH | 1 | |
| 58815F | CARPET, CONSOLE BOX | ||
| SU003-03212 | 1 | ||
| 58818A | COVER, CONSOLE BOX, FR | ||
| SU003-03206 | 1 | ||
| 58836B | PAD, CONSOLE BOX SILENCER, NO.1 | ||
| SU003-03209 | 2 | ||
| 58941A | COVER, PARKING BRAKE HOLE | ||
| SU003-03201 | 1 | ||
| 58995A | BRACKET, CONSOLE BOX MOUNTING, NO.1 | ||
| SU003-03214 | 1 | ||
| 58996A | BRACKET, CONSOLE BOX MOUNTING, NO.2 | ||
| SU003-03215 | 1 | ||
| SU003-00013 | *** STD. PART | ||
| SU003-00064 | *** STD. PART | ||
| SU003-00068 | *** STD. PART | ||
| SU003-02919 | *** STD. PART | ||
 |
|||
داشبورد GT86 مدل 2013
| 55312A | CLIP, INSTRUMENT PANEL | ||
| SU003-02967 | X | ||
| 55317A | PANEL, INSTRUMENT SIDE, RH | ||
| SU003-01924 | 1 | ||
| 55318C | PANEL, INSTRUMENT SIDE, LH | ||
| SU003-01925 | 1 | ||
| 55408F | PANEL SUB-ASSY, INSTRUMENT PANEL SPEAKER, NO.1 | ||
| SU003-01951 | 1 | ||
| 55409F | PANEL SUB-ASSY, INSTRUMENT PANEL SPEAKER, NO.2 | ||
| SU003-01952 | 1 | ||
| 55434E | CAP | ||
| SU003-02961 | 1 | ||
| 55435A | PANEL, INSTRUMENT PANEL FINISH, END RH | ||
| SU003-01970 | 1 | ||
| 55436A | PANEL, INSTRUMENT PANEL FINISH, END LH | ||
| SU003-01971 | 1 | ||
| 55606 | COVER SUB-ASSY, INSTRUMENT PANEL UNDER, NO.1 | ||
| SU003-01983 | 1 | ||
| 55607 | COVER SUB-ASSY, INSTRUMENT PANEL UNDER, NO.2 | ||
| SU003-01922 | 1 | ||
| SU003-00064 | *** STD. PART | ||
| SU003-02931 | *** STD. PART | ||
 |
|||
| 55061 | REGISTER SUB-ASSY, INSTRUMENT PANEL, NO.1 | ||
| SU003-01942 | 1 | ||
| 55062 | REGISTER SUB-ASSY, INSTRUMENT PANEL, N0.2 | ||
| SU003-01943 | 1 | ||
| 55312A | CLIP, INSTRUMENT PANEL | ||
| SU003-02967 | X | ||
| 55349A | CUSHION, INSTRUMENT PANEL | ||
| SU003-01968 | 1 | ||
| 55403 | HOOD SUB-ASSY, METER | ||
| SU003-01959 | 1 | ||
| 55405B | PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH, CENTER | ||
| SU003-01912 | 1 | ||
| 55422 | ORNAMENT, INSTRUMENT PANEL METER, UPPER | ||
| SU003-01958 | 1 | ||
| 55461A | ORNAMENT, INSTRUMENT PANEL | ||
| SU003-01934 | 1 | ||
| 55650B | BEZEL, INSTRUMENT PANEL REGISTER | ||
| SU003-01916 | 2 | ||
| 55670A | REGISTER ASSY, INSTRUMENT PANEL, CENTER | ||
| SU003-01945 | 1 | ||
| 55981 | GARNISH, DEFROSTER NOZZLE, NO.1 | ||
| SU003-01948 | 1 | ||
| 55982 | GARNISH, DEFROSTER NOZZLE, NO.2 | ||
| SU003-01949 | 1 | ||
| 55983 | GARNISH, DEFROSTER NOZZLE, NO.3 | ||
| SU003-01950 | 1 | ||
| SU003-02915 | *** STD. PART | ||
 |
|||
| 55044B | PANEL SUB-ASSY, INSTRUMENT PANEL FINISH, UPPER | ||
| SU003-01919 | 1 | ||
| 55045C | PANEL SUB-ASSY, INSTRUMENT PANEL FINISH, UPPER | ||
| SU003-01920 | 1 | ||
| 55302C | PANEL SUB-ASSY, INSTRUMENT | ||
| SU003-01906 | 1 | ||
| 55303B | PANEL SUB-ASSY, INSTRUMENT, LOWER | ||
| SU003-01908 | 1 | ||
| 55309C | REINFORCEMENT SUB-ASSY, INSTRUMENT PANEL, CENTER | ||
| SU003-01967 | 1 | ||
| 55312A | CLIP, INSTRUMENT PANEL | ||
| SU003-02967 | X | ||
| 55406B | PANEL SUB-ASSY, INSTRUMENT CLUSTER FINISH, LOWER CENTER | ||
| SU003-01914 | 1 | ||
| 55474C | GARNISH, INSTRUMENT CLUSTER FINISH PANEL, NO.1 | ||
| SU003-01929 | 1 | ||
| 55475A | GARNISH, INSTRUMENT CLUSTER FINISH PANEL, NO.2 | ||
| SU003-01930 | 1 | ||
| 55503B | CUSHION(FOR GLOVE COMPARTMENT) | ||
| SU003-01956 | 2 | ||
| 55510A | CUSHION(FOR GLOVE COMPARTMENT DOOR) | ||
| SU003-04310 | 2 | ||
| 55550 | DOOR ASSY, GLOVE COMPARTMENT | ||
| SU003-01955 | 1 | ||
| 55557C | DAMPER, GLOVE COMPARTMENT DOOR | ||
| SU003-01972 | 1 | ||
| 55558 | REINFORCEMENT, GLOVE COMPARTMENT DOOR | ||
| SU003-01965 | 1 | ||
| SU003-01974 | *** STD. PART | ||
| SU003-02866 | *** STD. PART | ||
| SU003-02915 | *** STD. PART | ||
 |
|||
| 55315A | SPACER, INSTRUMENT PANEL, NO.1 | ||
| SU003-02991 | 2 | ||
| 55330B | REINFORCEMENT ASSY, INSTRUMENT PANEL | ||
| SU003-01977 | 1 | ||
| 55394B | BOLT, INSTRUMENT PANEL | ||
| SU003-02856 | 2 | ||
| 55394C | BOLT, INSTRUMENT PANEL | ||
| SU003-02855 | 2 | ||
| SU003-00980 | *** STD. PART | ||
| SU003-02915 | *** STD. PART | ||
 |
|||
| 55449D | BASE, SWITCH | ||
| SU003-02498 | 1 | ||
| 55539B | COVER, SPARE SWITCH HOLE, NO.2 | ||
| SU003-02447 | X | ||
 |
|||
| 73900 | AIR BAG ASSY, INSTRUMENT PANEL, LOWER NO.1 | ||
| SU003-03433 | 1 | ||
| 73960A | AIR BAG ASSY, INSTRUMENT PANEL PASSENGER W/O DOOR | ||
| SU003-03427 | 1 | ||
| SU003-00008 | *** STD. PART | ||
| SU003-00051 | *** STD. PART | ||
 |
|||
| 55522B | COVER, RADIO TUNER OPENING | ||
| SU003-02639 | 1 | ||
| SU003-00062 | *** STD. PART | ||
 |
|||
اصلاعات فنی GT 86
فروشگاه تویوتا کار عرضه کننده قطعات موتوری تویوتا GT86 -لوازم بدنه GT86 -گیریبکس و جلوبندی و لوازم الکتریکی -کامپیوتر GT86 میباشد جهت سفارش با شماره های 36610186-021 یا 36610182-021 تماس حاصل فرمایید.
لوازم یدکی تویوتا GT86
مشخصات فنی :
خودرو |
|
| نام خودرو | تویوتا GT86 |
| کشور سازنده |
 ژاپن
|
| سال (طراحی) | 2013 |
مشخصات فنی |
|
| موتور | 4 سیلندر 16 سوپاپه |
| حجم موتور | 1998سی سی |
| حداکثر قدرت | 200 اسب بخار در 7000 دور در دقیقه |
| حداکثر گشتاور | 205 نیوتن متر در 6400 دور در دقیقه |
| جعبه دنده | 6 دنده اتوماتیک |
| شتاب 0 تا 100 | 7.6 ثانیه |
| حداکثر سرعت | 230 کیلومتر در ساعت |
| وزن | 1670 کیلوگرم |
| اندازه (میلیمتر) | 4240 طول – 1775 عرض – 1425 ارتفاع |
| فاصله بین دو محور | 2570 میلیمتر |
مصرف سوخت و استانداردها |
|
| مصرف سوخت داخل شهر | 9.6 لیتر در هر صد کیلومتر |
| مصرف سوخت خارج از شهر | 5.7 لیتر در هر صد کیلومتر |
| مصرف سوخت ترکیبی | 7.1 لیتر در هر صد کیلومتر |
| حجم باک | 50 لیتر |
| استاندارد آلایندگی | یورو 5 |
| استاندارد امنیت | EURONCAP 5 |
| میزان تولید CO2 | 164 گرم در هر کیلومتر |
تجهیزات و امکانات |
|
| ترمز و پایداری | ABS – VSC – ESP – ESC – TCS |
| کیسه هوا | کیسه هوای سرنشینان جلو – کیسه هوای پردهای و جانبی – کیسه هوا مخصوص زانوی راننده |
| سیستم صوتی | قابلیت پخش CD با ورودی USB، AUX و iPod به همراه 6 بلندگو و سیستم بلوتوث |
| دیگر تجهیزات | انتقال نیرو به چرخهای عقب (RWD) – گیربکس 6 سرعته دستی (یا گیربکس 6 سرعته خودکار به صورت سفارشی) – روکش چرمی فرمان – پدال آلومینیومی – رینگ 16 اینچی – چراغهای مهشکن در جلو و عقب – تجهیزات سفارشی: سیستم ورود بدون کلید – سیستم استارت دکمهای – سیستم LSD – سیستم تهویه مطبوع خودکار – روکش چرمی صندلیها – کیلومتر شمار دیجیتالی – شیفترهای تعویض دنده – کروز کنترل – رینگ 17 اینچی – چراغهای زنونی در جلو – سیستم شستشوی چراغهای جلو – بال عقب – نویگیشن |
