دسته: لوازم گیربکس و جلوبندی کمری

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04438F گردگیر پلوس کامل راست
04427-06150 (02/2004 – 07/2004) 1
04438-33090 (08/2002 – 01/2004) 1 $115.05
04438G BOOT KIT, FRONT DRIVE SHAFT INBOARD JOINT, RH
04437-06060 گردگیر پلوس داخلی سمت راست 1
41336D COVER, FRONT DRIVE SHAFT DUST, RH
41336-06070 (02/2004 – 07/2004) 1
41336-12020 (08/2002 – 01/2004) 1 $5.38
43030 JOINT ASSY, FRONT DRIVE INBOARD, RH
43030-09050 مشعلی پلوس و سه شاخ پلوس سمت راست 1
43030B RING, HOLE SNAP (FOR FRONT DRIVE INBOARD JOINT RH)
43425-06020 1
43425-06060 W(ABS) 1
43247B DEFLECTOR, FRONT WHEEL BEARING DUST, RH NO.2
43247-06050 W(ABS) 1
43247-06060 1
43410 پلوس کامل سمت شاگرد
43410-06380 W(ABS) (08/2004 – ) 1
43410-06520 W(ABS) (02/2004 – 07/2004) 1
43410-06530 (02/2004 – 07/2004) 1
43410-33202 W(ABS) (08/2002 – 01/2004) 1 $770.42
43410-33212 (08/2002 – 01/2004) 1 $793.51
43410C بلبرینگ مشعلی پلوس سمت شاگرد
90080-36200 (02/2004 – 07/2004) 1
90363-41002 (08/2002 – 01/2004) 1 $108.77
43410N RING, HOLE SNAP (FOR FRONT DRIVE SHAFT RH)
43425-06050 (02/2004 – 07/2004) 1
90520-38015 (08/2002 – 01/2004) 1 $2.65
43447C CLAMP (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
42345-06200 (02/2004 – 07/2004) 1
42345-48030 (08/2002 – 01/2004) 1 $5.42
43447D CLAMP, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
42345-06210 (02/2004 – 07/2004) 1
42345-44020 (08/2002 – 01/2004) 1 $8.22
43448C CLAMP (FOR FRONT AXLE INBOARD JOINT BOOT RH)
42345-06120 1
42345-06190 W(ABS) (02/2004 – 07/2004) 1
42345-14010 (08/2002 – 01/2004) 1 $8.58
43448E CLAMP, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH)
42345-06130 1
42345-06180 W(ABS) (02/2004 – 07/2004) 1
90949-01340 (08/2002 – 01/2004) 1 $3.12
43457 BRACKET, DRIVE SHAFT BEARING
Not applicable
43457A BOLT (FOR DRIVE SHAFT BEARING BRACKET SETTING NO.1)
90119-10461 *10-1.25PX19.8-8.3 1 $1.46
43457B RING, HOLE SNAP (FOR DRIVE SHAFT BEARING BRACKET)
90521-78002 1 $3.68
43457D BOLT(FOR DRIVE SHAFT BEARRING BRACKET SETTING NO.2)
Not applicable
43458 COVER, FRONT DRIVE SHAFT DUST
43458-06030 (02/2004 – 07/2004) 1
43458-12010 (08/2002 – 01/2004) 1 $10.67
43460 پلوس چرخ نیمه کامل سمت شاگرد
43470-09U10 (08/2004 – 05/2006) 1
43470-39346 (08/2002 – 07/2004) 1 $577.60
43470-39366 W(ABS) 1 $560.75
43474D DAMPER, FRONT DRIVE SHAFT, RH
Not applicable
43474F CLAMP (FOR FRONT DRIVE SHAFT DAMPER RH

04438H گردگیر پلوس کامل چپ
04428-06170 (08/2004 – 05/2006) 1
04438-33090 (08/2002 – 07/2004) 1 $115.05
04438J BOOT KIT, FRONT DRIVE SHAFT INBOARD JOINT, LH
04438-06250 گردگیر پلوس سمت گیربکس چپ 1
41336E COVER, FRONT DRIVE SHAFT DUST, LH
41336-06080 (08/2004 – ) 1
41336-17020 (08/2002 – 07/2004) 1 $27.04
43040 JOINT ASSY, FRONT DRIVE INBOARD, LH
43040-09050 مشعلی پلوس با سه شاخ پلوس چپ 1
43247C DEFLECTOR, FRONT WHEEL BEARING DUST, LH NO.2
43247-06050 W(ABS) 1
43247-06060 1
43412B RING, SHAFT SNAP (FOR FRONT DRIVE INNER SHAFT INNER LH)
43425-06020 (08/2004 – ) 1
90520-26028 (08/2002 – 07/2004) 1 $2.93
43420 پلوس کامل چپ
43420-06580 (08/2004 – ) 1
43420-33192 (08/2002 – 07/2004) 1 $705.73
43420-48042 W(ABS) 1 $685.14
43420G RING, HOLE SNAP (FOR FRONT DRIVE SHAFT LH)
43425-06010 (08/2004 – ) 1
90521-33002 (08/2002 – 07/2004) 1 $2.65
43447E CLAMP (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
42345-06200 1
42345-48030 W(ABS) 1 $5.42
43447F CLAMP, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
42345-06210 1
42345-44020 W(ABS) 1 $8.22
43448F CLAMP (FOR FRONT AXLE INBOARD JOINT BOOT LH)
42345-06120 (08/2004 – ) 1
42345-14010 (08/2002 – 07/2004) 1 $8.58
43448G CLAMP, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
42345-06130 (08/2004 – ) 1
90949-01340 (08/2002 – 07/2004) 1 $3.12
43470 پلوس نیمه کامل چرخ سمت راننده
43470-09U10 (08/2004 – 05/2006) 1
43470-39346 (08/2002 – 07/2004) 1 $577.60
43470-39366 W(ABS) 1 $560.75
43474E DAMPER, FRONT DRIVE SHAFT, LH
43474-06070 1
43474G CLAMP (FOR FRONT DRIVE SHAFT DAMPER LH)
42345-06110 1

45

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
31126 گردگیر دو شاخ کلاچ
31126-20080 1 $17.67
31204  دوشاخ  کلاچ
31204-20111 1 $98.05
31210 دیسک کلاچ
31210-33021 1 $189.16
31230 بلبرینگ کلاچ
31230-20191 1 $42.76
31232A CLIP, RELEASE BEARING HUB
31232-20031 1 $2.25
31236B SUPPORT, RELEASE FORK
31236-20070 1 $14.35
31250 صفحه کلاچ
31250-33031 1

42

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
1126 BOOT, CLUTCH RELEASE FORK
31126-32010 گردگیر دو شاخ کلاچ 1 $14.91
31204 FORK SUB-ASSY, CLUTCH RELEASE
31204-20100 دو شاخ کلاچ 1 $44.87
31210 دیسک کلاچ
31210-28060 (08/2002 – 07/2004) 1 $189.19
31210-33040 (09/2005 – ) 1 $220.22
31230 BEARING ASSY, CLUTCH RELEASE
31230-20170 بلبرینگ کلاچ 1 $68.15
31232A CLIP, RELEASE BEARING HUB
31232-20020 1 $2.02
31236B SUPPORT, RELEASE FORK
31236-20060 1 $11.27
31250 صفحه کلاچ
31250-28180 (08/2002 – 07/2004) 1 $204.38
31250-28181 (11/2005 – ) 1 $208.29

37

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
3504F سر دنده
33504-YC010-B1 DK.CHARCOAL, TRIM1* 1
33504-YC010-E1 SANDAL WOOD, TRIM4* 1
33506F RETAINER SUB-ASSY, CONTROL SHIFT LEVER (FOR FLOOR SHIFT)
33571-06010 1
33524F BRACKET, CONTROL LEVER HOUSING SUPPORT (FOR FLOOR SHIFT)
33524-28020 1 $34.20
33527B BUSH (FOR CONTROL SHIFT LEVER)
33557-33010 1 $13.60
33530F LEVER ASSY, SHIFT (FOR FLOOR SHIFT)
33530-33120  لیور دنده 1 $107.86
33534E CRANK, SELECTING BELL, NO.2
33534-28090 1 $44.08
33534F BUSH (FOR SELECTING BELLCRANK NO.2)
90386-12022 2 $3.24
33534G WASHER, PLATE (FOR SELECTING BELLCRANK NO.2)
90201-08028 1 $0.87
33557A COVER, SELECTING BELLCRANK DUST, NO.1
33557-32010 1 $6.44
33558 COVER, SELECTING BELLCRANK DUST, NO.2
33558-10030 1 $5.42
33574B RETAINER, SHIFT CABLE GROMMET, NO.2
33574-33040 1 $8.18
33608 SUPPORT SUB-ASSY, SELECTING BELLCRANK
33608-12031 1 $25.90
33821 CABLE TRANSMISSION CONTROL SHIFT (FOR FLOOR SHIFT)
33820-06170  سیم لیور دنده 1
33821B GROMMET, NO.2 (FOR TRANSMISSION CONTROL CABLE)
90480-01602 1 $7.79
33821C WASHER, PLATE (FOR TRANSMISSION CONTROL CABLE)
90201-08077 OD=30 2 $1.54
33822 CABLE TRANSMISSION CONTROL SELECT (FOR FLOOR SHIFT)
33822-06010 1

40

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
42304 CARRIER SUB-ASSY, REAR AXLE, RH
42304-06030 1
42304-06040 W(ABS) 1 $172.42
42304D BOLT (FOR REAR AXLE CARRIER RH)
90901-05001 2 $9.21
42304E NUT (FOR REAR AXLE CARRIER RH)
90178-15001 2 $1.86
42305 CARRIER SUB-ASSY, REAR AXLE, LH
42305-06030 1
42305-06040 W(ABS) 1 $172.42
42305A BOLT (FOR REAR AXLE CARRIER LH)
90901-05001 2 $9.21
42305B NUT (FOR REAR AXLE CARRIER LH)
90178-15001 2 $1.86
48231A SPRING, COIL, REAR RH
48231-06360 1 $116.35
48231B SPRING, COIL, REAR LH
48231-06360 1 $116.35
48258B INSULATOR, REAR COIL SPRING, LOWER RH
48258-06020 1 $19.18
48258C INSULATOR, REAR COIL SPRING, LOWER LH
48258-06020 1 $19.18
48341A BUMPER, REAR SPRING, NO.1 RH
48341-32053 1 $13.48
48341B BUMPER, REAR SPRING, NO.1 LH
48341-32053 1 $13.48
48530 کمک عقب راست
48530-09A70 MARK 48530-06320 1 $163.48
48530-09G80 MARK 48530-06450 1 $163.48
48540 کمک عقب چپ
48540-09480 MARK 48540-06320 1 $163.48
48540-09630 MARK 48540-06450 1 $163.48
48703C NUT(FOR REAR SUSPENSION ARM)
90179-14019 4 $2.13
48703E BOLT(FOR REAR SUSPENSION ARM)
90901-09001 BENCH TYPE REAR SEAT BACK, W/TONNEAU COVER-1.50PX260-26, BODY SIDE 2 $30.96
90901-19001 BENCH TYPE REAR SEAT BACK, W/TONNEAU COVER-1.50PX260-26, CARRIER SIDE 2 $15.89
48703H WASHER, NO.1(FOR REAR SUSPENSION ARM)
90201-14017 6 $3.04
48703J WASHER, NO.2(FOR REAR SUSPENSION ARM)
48715-06020 1
48710A ARM ASSY, REAR SUSPENSION, NO.1 RH
48710-06030  مندل عقب راست 1 $153.72
48720A ARM ASSY, REAR SUSPENSION, NO.1 LH
48710-06030  مندل عقب چپ 1 $153.72
48730F ARM ASSY, REAR SUSPENSION, NO.2 RH
48730-06030  مندل عقب ریگلاژ راست 1 $182.38
48740F ARM ASSY, REAR SUSPENSION, NO.2 LH
48740-06020  مندل عقب ریگلاژ چپ 1
48750G NUT(FOR REAR SUSPENSION SUPPORT)
90178-08007 6 $1.27
48750H SUPPORT ASSY, REAR SUSPENSION, RH
48750-06080 1
48750J NUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER RH)
94182-11400 1 $6.01
48750K COLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER RH)
90387-15027 1 $5.18
48753B COVER, REAR SUSPENSION SUPOPORT, NO.1 RH
48753-06020 1
48753C COVER, REAR SUSPENSION SUPOPORT, NO.1 LH
48753-06020 1
48760B SUPPORT ASSY REAR SUSPENSION, LH
48760-06080 1
48760C NUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER LH)
94182-11400 1 $6.01
48760D COLLAR(FOR REAR SUPPORT TO REAR SHOCK ABSORBER LH)
90387-15027 1 $5.18
48780A ROD ASSY, STRUT, REAR
48780-YC010 2
48780B BOLT(FOR STRUT ROD)
90119-12131 4 $4.03
48780C NUT(FOR STRUT ROD)
90179-12063 BODY SIDE 2 $2.65
90179-12091 CARRIER SIDE 2 $1.54
48812 موجگیر عقب
48812-AA010 PINK PAINTED 1 $177.80
48812-YC041 WHITE PAINTED 1
48818 BUSH, STABILIZER, REAR
48818-06100  لاستیک چاکدار عقب 2 $11.62
48830D LINK ASSY, REAR STABILIZER, RH
48830-33010  سیبک موجگیر عقب راست 1 $76.46
48832A BRACKET, REAR STABILIZER BAR, NO.1
48832-06040 2
48840A LINK ASSY, REAR STABILIZER, LH
48830-33010  سیبک موجگیر عقب چپ 1 $76.46
90179-10183 *** STD. PART $1.07
91651-60818 *** STD. PART $1.70

27

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
48131 SPRING, FRONT COIL, RH
48131-06690  فنر لول جلو راست 1
48132 SPRING, FRONT COIL, LH
48131-06690  فنر لول جلو چپ 1
48157B INSULATOR, FRONT COIL SPRING, UPPER RH
48157-06070  گردگیر سر کمک راست 1
48157C INSULATOR, FRONT COIL SPRING, UPPER LH
48157-06070  گردگیر سر کمک چپ 1
48158B INSULATOR, FRONT COIL SPRING, LOWER RH
48158-06040  گردگیر زیر فنر لول 1
48158C INSULATOR, FRONT COIL SPRING, LOWER LH
48158-06040  گردگیر زیر فنر لول 1
48331B BUMPER, FRONT SPRING, RH
48331-33021 1 $13.52
48331C BUMPER, FRONT SPRING, LH
48331-33021 1 $13.52
48471B SEAT, FRONT COIL SPRING, UPPER RH
48471-06020 1
48471C SEAT, FRONT COIL SPRING, UPPER LH
48471-06020 1
48510 کمک جلو راست
48510-09B10 MARK 48510-06380 1 $145.37
48510-09M20 MARK 4851006570 1 $145.37
48520 کمک جلو چپ
48520-09A40 MARK 48520-06380 1 $145.37
48520-09E70 MARK 48520-06570 1 $145.37
48603 SUPPORT SUB-ASSY, FRONT SUSPENSION, RH
48603-06041  توپی سر کمک راست 1 $98.25
48603A NUT(FOR FRONT SUSPENSION SUPPORT)
90179-10095 6 $1.62
48603B BEARING(FOR FRONT SUSPENSION SUPPORT RH)
90903-63014 1 $72.00
48609 SUPPORT SUB-ASSY, FRONT SUSPENSION, LH
48609-06111  توپی سر کمک چپ 1 $98.25
48609C BEARING(FOR FRONT SUSPENSION SUPPORT LH)
90903-63014 1 $72.00
48810 LINK ASSY, FRONT STABILIZER, LH
48810-33010  سیبک موجگیر چپ 1 $88.52
48811 BAR, STABILIZER, FRONT
48811-06130  موجگیر جلو 1
48815 BUSH, FRONT STABILIZER BAR, NO.1
48815-06070  لاستیک چاکدار 2
48820B LINK ASSY, FRONT STABILIZER, RH
48820-33020  سیبک موجگیر جلو راست 1 $88.52
48824A BRACKET, FRONT STABILIZER, NO.1 RH
48824-06050 1
48829A BRACKET, FRONT STABILIZER, NO.1 LH
48824-06050 1
90179-10183 *** STD. PART $1.07
90179-14015 *** STD. PART $1.19
91611-60822 *** STD. PART $1.34

41

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
43211 سگدست راست
43211-06081 1 $276.64
43211-06091 W(ABS) 1
43211K BOLT (FOR STEERING KNUCKLE RH)
90105-17008 OD=17 2 $5.89
90105-17009 OD=15.9, TYPE B:REFER ILLUST. 1 $5.89
90105-17010 OD=15, TYPE C:REFER ILLUST. 1 $5.89
90105-17011 OD=14, TYPE D:REFER ILLUST. 1 $4.98
43211L NUT (FOR STEERING KNUCKLE RH)
90178-17001 2 $2.21
43212 سگدست چپ
43212-06081 1
43212-06091 W(ABS) 1
43212D BOLT (FOR STEERING KNUCKLE LH)
90105-17008 OD=17 2 $5.89
90105-17009 OD=15.9, TYPE B:REFER ILLUST. 1 $5.89
90105-17010 OD=15, TYPE C:REFER ILLUST. 1 $5.89
90105-17011 OD=14, TYPE D:REFER ILLUST. 1 $4.98
43212E NUT (FOR STEERING KNUCKLE LH)
90178-17001 2 $2.21
43330K سیبک طبق پایین راست
43330-39435 TYPE B:REFER TO ILLUSTRATION 1 $76.33
43330L NUT, CASTLE (FOR FRONT LOWER BALL JOINT RH)
90171-14003 1 $1.62
43340A سیبک طبق پایین چپ
43330-39435 TYPE B:REFER TO ILLUSTRATION 1 $76.33
43340B NUT, CASTLE (FOR FRONT LOWER BALL JOINT LH)
90171-14003 1 $1.62
48068 ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 RH
48068-06090  طبق پایین راست 1 $210.93
48068A BOLT(FOR FRONT SUSPENSION LOWER ARM)
90105-12122 NO.1 2 $2.13
90105-14081 NO.2 2 $4.03
90105-14084 NO.3 4 $5.10
48068C NUT(FOR FRONT SUSPENSION LOWER ARM)
90179-12052 BALL JOINT SIDE 4 $1.62
90179-14048 BODY SIDE 2 $1.54
48069 ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 LH
48069-06090  طبق پایین چپ 1 $210.93
48655D BUSH, FRONT LOWER ARM, NO.2 RH
48655-06060  بوش گرد طبق پایین 1 $36.06
48655E BUSH, FRONT LOWER ARM, NO.2 LH
48655-06060  بوش گرد طبق پایین 1 $36.06
48657A STOPPER, FRONT LOWER ARM BUSH
48657-06030 2
95381-03225 *** STD. PART $0.91




34

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04466 لنت عقب
04466-32030 MARK AK PA544 1 $60.63
04479A CYLINDER KIT, DISC BRAKE, REAR
04479-33200  لوازم سیلندر چرخ عقب 1 $119.07
04946 SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)
04946-32080  شیم لنت 1 $29.85
04948 FITTING KIT, DISC BRAKE, REAR
04948-32040 1 $30.68
31478C CAP, BLEEDER PLUG(FOR REAR DISC BRAKE)
31478-30010 2 $2.21
47547C PLUG, BLEEDER(FOR REAR DISC BRAKE)
47547-20010 2 $4.35
47715C PIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)
47715-32020 SUB 2 $13.76
47715-32030 MAIN 2 $13.76
47716A PLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)
47716-32060 4 $4.03
47717A PLATE, PAD SUPPORT, NO.2(FOR REAR DISC BRAKE)
47717-32060 4 $4.03
47721C MOUNTING, REAR DISC BRAKE CYLINDER, RH
47721-33110 1 $84.77
47722A MOUNTING, REAR DISC BRAKE CYLINDER, LH
47722-33110  فکی سیلندر چرخ عقب 1 $84.77
47730B CYLINDER ASSY, REAR DISC BRAKE, RH
47730-33160  سیلندر چرخ عقب راست 1 $408.77
47731B PISTON, REAR DISC BRAKE
47731-33040  پیستون سیلندر چرخ عقب 2 $23.72
47731C RING, SET(FOR REAR DISC BRAKE PISTON)
90522-43003 2 $1.27
47750A CYLINDER ASSY, DISC BRAKE, REAR LH
47750-33160  سیلندر چرخ عقب چپ 1 $408.77
47771A PLATE, PAD WEAR INDICATOR(FOR REAR DISC BRAKE)
47771-32030 2 $2.10
47775D BOOT, BUSH DUST(FOR REAR DISC BRAKE)
47775-32050 2 $5.22
47779A BUSH, CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)
47779-32030 2 $2.02
47810A BOLT, HEXAGON(FOR REAR CALIPER)
90119-10939 4 $0.99

18

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04465 لنت جلو
04465-33290 MARK NBK PN540H 1 $93.21
04479 لوازم سیلندر چرخ جلو
04479-06040 لوازم سیلندر چرخ جلو 1 $58.00
04945 SHIM KIT, ANTI SQUEAL, FRONT
04945-06060  شیم لنت 1 $69.39
04947 FITTING KIT, DISC BRAKE, FRONT
04947-06042 1 $31.12
31478B CAP, BLEEDER PLUG(FOR FRONT DISC BRAKE)
31478-30010 2 $2.21
47547B PLUG, BLEEDER(FOR FRONT DISC BRAKE)
47547-20010 2 $4.35
47710A BOLT, HEXAGON(FOR FRONT DISC BRAKE CALIPER)
90105-12208 *12-1.25PX29.5-23 4 $2.02
47715A PIN, FRONT DISC BRAKE CYLINDER SLIDE
47715-06060 2 $9.88
47715B BOLT(FOR FRONT DISC BRAKE CYLINDER SLIDE)
90080-10075 4 $1.27
47715D PIN, FRONT DISC BRAKE CYLINDER SLIDE, NO.2
47715-06070 2 $9.88
47716 PLATE, PAD SUPPORT, NO.1(FOR FRONT DISC BRAKE)
47716-06050 2 $7.83
47717 PLATE, PAD SUPPORT, NO.2(FOR FRONT DISC BRAKE)
47716-06050 2 $7.83
47721 MOUNTING, FRONT DISC BRAKE CYLINDER, RH
47721-06040 1 $200.65
47722 MOUNTING, FRONT DISC BRAKE CYLINDER, LH
47721-06040 1 $200.65
47730 CYLINDER ASSY, FRONT DISC BRAKE, RH
47730-06040  سیلندر ترمز چرخ جلو راست 1 $408.77
47731 PISTON, FRONT DISC BRAKE
47731-06040  پیستون سیلندر چرخ 2 $44.87
47731A RING, SET(FOR FRONT DISC BRAKE PISTON)
90080-52086 2 $2.06
47750 CYLINDER ASSY, DISC BRAKE, LH
47750-06040  سیلندر ترمز چرخ جلو چپ 1 $408.77
47769 BUSH, CYLINDER SLIDE, NO.1(FOR FRONT DISC BRAKE)
47769-06020 2 $5.30
47771 PLATE, PAD WEAR INDICATOR, NO.1
47771-06020 2 $4.39
47775 BOOT, BUSH DUST(FOR FRONT DISC BRAKE)
47775-02040 4 $9.61
47781 COVER, DISC BRAKE DUST, FRONT RH
47781-YC021 1
47781A BOLT(FOR DUST COVER TO STEERING KNUCKLE ARM SETTING)
90109-06134 8 $1.03
25

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
44610 BOOSTER ASSY, BRAKE
44610-06220  بوستر ترمز 1
44730 VALVE ASSY, VACUUM CHECK(FOR BRAKE)
44730-10010 1 $40.45
44772 HOSE, CHECK VALVE TO CONNECTOR TUBE
44772-06110 1
44772B HOSE, CHECK VALVE TO BRAKE BOOSTER
44772-06080 1
44774 HOSE, UNION TO CONNECTOR TUBE
44774-06050 1
44777 CONNECTOR, VACUUM HOSE, NO.1
44770-06070 1
44783 CLAMP, VACUUM HOSE
44783-28010 1 $8.30
44785 GASKET, BRAKE BOOSTER
44785-YA020 1
47264D CLEVIS, BRAKE MASTER CYLINDER PUSH ROD
47264-12060 1 $6.17
90179-06083 *** STD. PART $5.02
90179-06158 *** STD. PART $1.34
90179-08038 *** STD. PART $0.99
90385-07003 *** STD. PART $1.82
90467-16014 *** STD. PART $2.57
90561-06012 *** STD. PART $1.62
90949-01C79 *** STD. PART $4.98
91611-60618 *** STD. PART $1.38
91651-60625 *** STD. PART $0.91
93381-16010 *** STD. PART $1.19
94120-41000 *** STD. PART $0.91
96133-41500 *** STD. PART $3.87

38

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04493 لوازم پمپ ترمز
04493-06090 1
04493-06100 W(ABS) 1
47201 پمپ ترمز
47201-06110 1
47201-06180 W(ABS) 1
47202 RESERVOIR SUB-ASSY, BRAKE MASTER CYLINDER
47220-06080  مخزن پمپ ترمز 1
47210J GASKET(FOR MASTER CYLINDER)
90029-43001 W(ABS) 1 $1.27
90430-06104 1 $0.91
47210T BOLT(FOR BRAKE MASTER CYLINDER)
90109-06077 1 $2.69
47230 CAP ASSY, BRAKE MASTER CYLINDER RESERVOIR FILLER
47230-04040  درب مخزن پمپ ترمز 1
47255 GROMMET, MASTER CYLINDER RESERVOIR
47255-16010 2 $11.74
47265 BOOT, MASTER CYLINDER
47265-20050 1 $7.27
47275 GASKET, BRAKE MASTER CYLINDER
47275-12020 1 $1.34
47287 LABEL, BRAKE FLUID INFORMATION
Not applicable
47299 STRAINER, BRAKE MASTER CYLINDER RESERVOIR
47299-20060 1 $2.81
90149-40021 *** STD. PART $0.99
90179-08204 *** STD. PART $1.11

51

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
44200 LINK ASSY, POWER STEERING
44200-33411  جعبه فرمان 1 $1,861.92
44250 GEAR ASSY, POWER STEERING(FOR RACK & PINION)
Not applicable
45046 END SUB-ASSY, TIE ROD, RH
45046-29255  سیبک فرمان راست 1 $64.04
45046A NUT, CASTLE(FOR TIE ROD END)
90171-12028 2 $1.94
45047 END SUB-ASSY, TIE ROD, LH
45046-29255  سیبک فرمان چپ 1 $64.04
45503 END SUB-ASSY, STEERING RACK
45503-39135  قرقری فرمان 2 $167.04
45503B WASHER, CLAW(FOR STEERING RACK END)
90214-14002 OD=37 2 $1.34
45535 BOOT, STEERING RACK, NO.1
45535-07010 (L)گردگیر جعبه فرمان 1 $15.22
45535-33020 (J) 1 $15.22
45535B CLIP(FOR STEERING RACK BOOT)
90080-46153 (L) 2 $1.15
90467-19021 2 $1.46
45535D CLAMP(FOR STEERING RACK BOOT NO.1)
90460-58006 1 $6.56
45536 BOOT, STEERING RACK, NO.2
45535-07010 (L)گردگیر جعبه فرمان 1 $15.22
45535-33020 (J) 1 $15.22
45536A CLAMP(FOR STEERING RACK BOOT NO.2)
90460-58006 1 $6.56
04445-33090 لوازم جعبه فرمان
90179-14049 *** STD. PART $1.94
65

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
44327A GASKET, PRESSURE PORT, NO.1
44327-30030 1 $2.97
44348A HOSE, OIL RESERVOIR TO PUMP, NO.1
44348-06220  شلنگ مخزن به پمپ هیدرولیک 1
44402 COOLER SUB-ASSY, POWER STEERING OIL, NO.1
44402-06060  خنک کن روغن جعبه فرمان 1
44406 TUBE SUB-ASSY, RETURN
44406-06140 1
44410 TUBE ASSY, PRESSURE FEED
44410-06190  شلنگ فشار قوی پمپ به جعبه فرمان 1
44412D HOSE, RETURN, NO.1
44412-8Y005 1
44412E HOSE, RETURN, NO.2
44412-8Y004 1
44416 TUBE, RETURN(FOR STEERING GEAR OUTLET)
44416-06140 1
44416E BOLT, UNION(FOR RETURN TUBE)
96341-41603 1 $10.40
9008Y-00011 *** STD. PART
90119-10906 *** STD. PART $3.95
90179-06299 *** STD. PART $0.79
90179-08061 *** STD. PART $0.91
90464-00661 *** STD. PART $2.73
90467-16019 *** STD. PART $3.12
90467-21010 *** STD. PART $3.60
91611-B0825 *** STD. PART $1.11
91631-J0612 *** STD. PART $0.79

64

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04446 GASKET KIT, POWER STEERING PUMP
04446-06060  لوازم پمپ هیدرولیک 1 $27.16
44303A SHAFT SUB-ASSY, W/PULLEY
44303-06040  پولی پمپ هیدرولیک 1
44305 CAP SUB-ASSY, VANE PUMP OIL RESERVOIR
44305-06030 (L)درب مخزن هیدرولیک 1 $22.93
44305-32020 (J) 1 $22.62
44320 PUMP ASSY, VANE
44310-06130  پمپ هیدرولیک 1
44330A SPRING, COMPRESSION(FOR FLOW CONTROL VALVE)
90501-T0001 1
44337 UNION, POWER STEERING SUCTION PORT
44337-06060 1
44360 RESERVOIR ASSY, VANE PUMP OIL
44360-06010 (L)مخزن پمپ هیدرولیک 1 $199.11
44360-33020 (J) 1 $218.09
44369A BRACKET, OIL RESERVOIR, NO.1
44390-06010 1 $38.15
90080-11505 *** STD. PART
90119-06870 *** STD. PART $1.03
90540-09004 *** STD. PART $4.31
90560-06014 *** STD. PART $7.91

52

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
43246A DEFLECTOR, FRONT WHEEL BEARING DUST, NO.1 RH
43246-YC010 W(ABS) 1
43246-YC020 1 $10.56
43246B DEFLECTOR, FRONT WHEEL BEARING DUST, NO.1 LH
43246-YC010 W(ABS) 1
43246-YC020 1 $10.56
43501C HUB SUB-ASSY, FRONT AXLE, RH
43502-YC020  توپی چرخ جلو راست 1
43501D BOLT, HUB (FOR FRONT AXLE RH)
90089-11034  پیچ چرخ 5
43501E BEARING (FOR FRONT AXLE HUB RH)
90080-36177 (L)بلبرینگ چرخ جلو راست 1 $141.86
90369-43008 (J) 1 $141.86
43501G RING, HOLE SNAP (FOR FRONT AXLE HUB RH)
90521-88001 1 $7.00
43502C HUB SUB-ASSY, FRONT AXLE, LH
43502-YC020  توپی چرخ جلو چپ 1
43502D BOLT, HUB (FOR FRONT AXLE LH)
90089-11034  پیچ چرخ 5
43502E BEARING (FOR FRONT AXLE HUB LH)
90080-36177 (L)بلبرینگ چرخ جلو چپ 1 $141.86
90369-43008 (J) 1 $141.86
43502G RING, HOLE SNAP (FOR FRONT AXLE HUB LH)
90521-88001 1 $7.00
43510L NUT (FOR STEERING KNUCKLE RH)
90178-22001 1 $2.25
43512 DISC, FRONT
43512-33042  دیسک چرخ جلو 2 $150.36
43520C NUT (FOR STEERING KNUCKLE LH)
90178-22001 1 $2.25
43525B CAP, FRONT WHEEL ADJUSTING LOCK, RH
43525-YB010 1 $3.20
43525C CAP, FRONT WHEEL ADJUSTING LOCK, LH
43525-YB010 1 $3.20
95381-04030 *** STD. PART $0.83

28

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
04438F گردگیر پلوس کامل راست
04427-06110 (11/2003 – 07/2004) 1
04438-06280 (08/2004 – 05/2006) 1
04438G گردگیر پلوس داخلی راست
04437-06060 (11/2003 – 07/2004) 1
04438-06250 (08/2004 – 05/2006) 1
41336D COVER, FRONT DRIVE SHAFT DUST, RH
41336-06070 1
43030 JOINT ASSY, FRONT DRIVE INBOARD, RH
43030-09020  پلوس و سه شاخ پلوس راست 1
43030B RING, HOLE SNAP (FOR FRONT DRIVE INBOARD JOINT RH)
43425-06020 1
43247B DEFLECTOR, FRONT WHEEL BEARING DUST, RH NO.2
43247-06050 W(ABS) 1
43247-06060 1
43410 SHAFT ASSY, FRONT DRIVE, RH
43410-06390  پلوس کامل راست 1 $897.58
43410C BEARING (FOR FRONT DRIVE SHAFT)
90080-36200  بلبرینگ پلوس 1
43410N RING, HOLE SNAP (FOR FRONT DRIVE SHAFT RH)
43425-06050 1
43447C CLAMP (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
42345-06170 1
43447D CLAMP, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT RH)
42345-06160 1
43448C CLAMP (FOR FRONT AXLE INBOARD JOINT BOOT RH)
42345-06120 1
43448E CLAMP, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT RH)
42345-06130 1
43457 BRACKET, DRIVE SHAFT BEARING
43457-06010 1
43457A BOLT (FOR DRIVE SHAFT BEARING BRACKET SETTING NO.1)
90119-10461 *10-1.25PX19.8-8.3 1 $1.46
43457B RING, HOLE SNAP (FOR DRIVE SHAFT BEARING BRACKET)
90521-78002 1 $3.68
43457D BOLT(FOR DRIVE SHAFT BEARRING BRACKET SETTING NO.2)
90105-10381 3 $1.30
43458 COVER, FRONT DRIVE SHAFT DUST
43458-06030 1
43460 SHAFT ASSY, FRONT DRIVE OUTBOARD JOINT, RH
43460-09R50  پلوس چرخ راست 1
43474D DAMPER, FRONT DRIVE SHAFT, RH
43474-06030 1
43474F CLAMP (FOR FRONT DRIVE SHAFT DAMPER RH)
42345-06110 1

04438H گردگیر پلوس کامل چپ
04438-06280 W(ABS) 1
04438J BOOT KIT, FRONT DRIVE SHAFT INBOARD JOINT, LH
04438-06250  گردگیر پلوس داخلی چپ 1
41336E COVER, FRONT DRIVE SHAFT DUST, LH
41336-06050 1 $27.04
43040 JOINT ASSY, FRONT DRIVE INBOARD, LH
43040-09030  پلوس و سه شاخ پلوس چپ 1
43247C DEFLECTOR, FRONT WHEEL BEARING DUST, LH NO.2
43247-06050 W(ABS) 1
43247-06060 1
43412B RING, SHAFT SNAP (FOR FRONT DRIVE INNER SHAFT INNER LH)
43425-06020 1
43420 SHAFT ASSY, FRONT DRIVE, LH
43420-06390  پلوس کامل چپ 1 $764.26
43420G RING, HOLE SNAP (FOR FRONT DRIVE SHAFT LH)
43425-06010 1
43447E CLAMP (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
42345-06170 1
43447F CLAMP, NO.2 (FOR FRONT AXLE OUTBOARD JOINT BOOT LH)
42345-06160 1
43448F CLAMP (FOR FRONT AXLE INBOARD JOINT BOOT LH)
42345-06120 1
43448G CLAMP, NO.2 (FOR FRONT AXLE INBOARD JOINT BOOT LH)
42345-06130 1
43470 SHAFT ASSY, FRONT DRIVE OUTBOARD JOINT, LH
43470-09U00  پلوس چرخ چپ 1
43474E DAMPER, FRONT DRIVE SHAFT, LH
43474-06040 1
43474G CLAMP (FOR FRONT DRIVE SHAFT DAMPER LH)
42345-06110 1

36

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
42601 رینگ چرخ
42611-YC130 15X6JJ, TYPE D:REFER TO ILLUSTRATION 4 $174.17
42601A رینگ یدک
42611-YC130 15X6JJ, TYPE D:REFER TO ILLUSTRATION 1 $174.17
42601C مهره چرخ
90942-01007 TYPE A:REFER TO ILLUSTRATION 20 $5.26
42611G VALVE (FOR TUBELESS TIRE)
90942-05004 4 $10.79
42611J VALVE (FOR TUBELESS TIRE SPARE)
90942-05004 1 $10.79
42652 لاستیک
42652-06571 205/65R15 94Y, BRIDGESTONE COMPANY LIMITED 4
42652-06610 205/65R15 94V, DUNLOP RUBBER COMPANY (JAPAN) LIMITED 4
42652-06630 205/65R15 94V, THE YOKOHAMA RUBBER COMPANY LIMITED 4
42652A لاستیک یدک
42652-06571 205/65R15 94Y, BRIDGESTONE COMPANY LIMITED 1
42652-06610 205/65R15 94V, DUNLOP RUBBER COMPANY (JAPAN) LIMITED 1
42652-06630 205/65R15 94V, THE YOKOHAMA RUBBER COMPANY LIMITED 1

64

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
42311U BOLT, HUB (FOR REAR AXLE RH)
90089-11034 پیچ چرخ 5
42312E BOLT, HUB (FOR REAR AXLE LH)
90089-11034  پیچ چرخ 5
42421E BOLT (FOR REAR AXLE BEARING CASE RH)
90105-10124  پیچ توپی چرخ 4 $2.77
42421F RING, O (FOR REAR AXLE BEARING CASE RH)
90301-63006 1 $4.76
42422A BOLT (FOR REAR AXLE BEARING CASE LH)
90105-10124  پیچ توپی چرخ 4 $2.77
42422B RING, O (FOR REAR AXLE BEARING CASE LH)
90301-63006 1 $4.76
42431 DISC, REAR
42431-33010  دیسک چرخ عقب 2 $136.18
42450A بلبرینگ و توپی چرخ عقب راست
42410-06090 (L) (07/2003 – 07/2004) 1
42410-06091 (L) (11/2004 – ) 1 $388.81
42410-33040 (J) 1 $407.31
42450B بلبرینگ و توپی چرخ عقب چپ
42410-06090 (L) (07/2003 – 07/2004) 1
42410-06091 (L) (11/2004 – ) 1 $388.81
42410-33040 (J) 1 $407.31
42491 PLUG, SHOE ADJUSTING HOLE (FOR PARKING BRAKE)
47491-06010 2
43517 ROTOR, SKID CONTROL, REAR
43517-12021  دنده ای بی اس 2 $17.72

27

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
35210 SOLENOID ASSY, CLUTCH CONTROL, NO.1
35210-21010  سلونوئید گیربکس 1 1 $191.95
35220 SOLENOID ASSY, CLUTCH CONTROL, NO.2
35220-21010  سلونوئید گیربکس 2 1 $191.95
35230 SOLENOID ASSY, TRANSMISSION 3WAY, NO.2
35230-21010  سلونوئید 1 $307.40
35240 SOLENOID ASSY, AUTOMATIC TRANSMISSION 3WAY
35240-21010  سلونوئید 1 $307.40
35290A SOLENOID ASSY, LINE PRESSURE CONTROL
35290-21010  سلونوئید 1 $203.14
35330 STRAINER ASSY, VALVE BODY OIL
35330-06010  فیلتر گیربکس 1 $98.05
35339 GASKET, OIL STRAINER
90301-32010 1 $3.58
35410 BODY ASSY, TRANSMISSION VALVE
35410-48011  ساعت گیربکس 1 $1,611.61
35418 VALVE, MANUAL
35418-21011 1 $63.62
35424C PISTON, C-1 ACCUMULATOR
35424-21010 1 $58.16
35424D SPRING, COMPRESSION (FOR C-1 ACCUMULATOR PISTON)
90501-22039 1 $4.35
35424E RING, O (FOR C-1 ACCUMULATOR PISTON)
90301-27008 UPPER 1 $3.58
90301-30007 LOWER 1 $3.58
35426D PISTON, C-3 ACCUMULATOR
35406-21010 1 $42.42
35426E SPRING, COMPRESSION (FOR C-3 ACCUMULATOR PISTON)
90905-01035 1 $5.18
35426F RING, O (FOR C-3 ACCUMULATOR PISTON)
90301-30007 1 $3.58
35427K PISTON, B-3 ACCUMULATOR
35427-21010 1 $49.46
35427L SPRING, COMPRESSION (FOR B-3 ACCUMULATOR PISTON)
90501-22038 INNER 1 $3.84
90501-25053 OUTER 1 $4.35
35427M RING, O (FOR B-3 ACCUMULATOR PISTON)
90301-28008 1 $3.58
35482-21020 *** STD. PART $2.85
82125J WIRE, TRANSMISSION
82125-28180  سیم کشی گیربکس 1 $44.72
82125L RING, O(FOR TRANSMISSION WIRE)
90301-21009 1 $3.15
90105-05023 *** STD. PART $0.55
90105-06028 *** STD. PART $0.83
90105-06070 *** STD. PART $1.54
90105-06071 *** STD. PART $1.54
91511-C0625 *** STD. PART $0.99
91611-60620 *** STD. PART $1.34




46

دسته بندی ها: لوازم گیربکس و جلوبندی کمری, لوازم یدکی کمری
32000 CONVERTER ASSY, TORQUE
32000-33090  توربین گیربکس 1 $1,865.00
32101 GEAR SUB-ASSY, DRIVE PLATE & RING
32101-28040  فلایویل 1 $267.11
32101A BOLT(FOR DRIVE PLATE & TORQUE CONVERTER SETTING)
90109-09001 *9-1.25PX12.4-7.3, GREEN 1 $1.03
90119-09025 *9-1.25PX12.4-8.4, YELLOW 5 $1.03
32101C BOLT, HEXAGON(FOR DRIVE PLATE SETTING)
90105-12184 *12-1.25PX22-16 8 $1.54
32116 SPACER, DRIVE PLATE, FRONT
32116-20050 1 $19.06
32117 SPACER, DRIVE PLATE, REAR
32117-20060 1 $25.54
35035 اویل پمپ گیربکس
35035-21020 1 $427.83
35035-28010 MARK AT 1 $444.47
35301A SEAL, OIL (FOR FRONT OIL PUMP)
90311-38083  کاسه نمد اویل پمپ گیربکس 1 $10.48
35301B RING, O (FOR FRONT OIL PUMP BODY)
90301-99099 1 $7.80
35301F BOLT (FOR FRONT OIL PUMP SETTING)
90105-08050 PLANT NO.A32-1.25PX28-28 7 $1.23
35307F BOLT (FOR STATOR SHAFT)
90148-60027 11 $0.83
35321 دنده اویل پمپ گیربکس
35321-21060 T=10.690-10.699 1 $78.56
35321-21070 T=10.700-10.709 1 $78.56
35321-21080 T=10.710-10.720 1 $78.56
35321-21090 T=10.721-10.730 1 $78.56
35321-21100 T=10.731-10.740 1 $78.56
35321-28060 T=10.715, MARK 1 1 $78.56
35321-28070 T=10.715, MARK 2 1 $78.56
35321-28080 T=10.715, MARK 3 1 $78.56
35321-28090 T=10.715, MARK 4 1 $78.56
35321-28100 T=10.715, MARK 5 1 $78.56
35322 دنده درایو اویل پمپ گیربکس
35322-21060 T=10.690-10.699 1 $72.31
35322-21070 T=10.700-10.709 1 $72.31
35322-21080 T=10.710-10.720 1 $72.31
35322-21090 T=10.721-10.730 1 $72.31
35322-21100 T=10.731-10.740 1 $72.31
35322-28060 T=10.715, MARK 1 1 $72.31
35322-28070 T=10.715, MARK 2 1 $72.31
35322-28080 T=10.715, MARK 3 1 $72.31
35322-28090 T=10.715, MARK 4 1 $72.31
35322-28100 T=10.715, MARK 5 1 $72.31
35370 SHAFT ASSY, STATOR
35370-21020  شفت خروجی گیربکس 1 $419.53
35370-28010 MARK M 1 $419.53
35617 RING, CLUTCH DRUM OIL SEAL

30
